Įrankių bandymų mašina

OERLIKON-KLINGELNBERG R30

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 1997, Grinding diameter: 80 - 250 mm Grinding length: 600 mm Dcodpfx Abeu D I Tle Ssb Centre height: 175 mm Longitudinal travel: 750 mm Workpiece speeds: 6 - 600 rpm Grinding spindle speed: 1,500 - 3,600 rpm Cross travel – automatic and manual: 320 mm Control: Kelco 80 Total power requirement: kW Machine weight approx.: 4.4 t Space required approx.: 3.1 x 2.1 x 2.0 m

Sąlyga: naudotas, TECHNICAL DATA - Grinding diameter: 0.1 – 10 [mm] - Max. stroke: 10 [mm] - Working stroke: 0–10 [mm] - Working grinding wheel dimensions: 150 x 50 x 50 [mm] - Driven grinding wheel dimensions: 100 x 50 x 40 [mm] - Driven grinding wheel diameter: 100 [mm] Dsdpfxjuhb N Ss Ab Sjcb - Working grinding wheel speed: 4,500 [rpm] - Driven grinding wheel speed: 20–50 [rpm] - Power: 6 [kW] - Minimum pressure: 5.6 [bar] - Dimensions: 1,300 x 1,100 [mm] - Weight: 700 [kg]

Sąlyga: visiškai atnaujintas (naudotas), Gamybos metai: 2004, matavimo diapazonas X ašis: 900 mm, matavimo diapazonas Y ašis: 2 000 mm, matavimo diapazonas Z ašis: 600 mm, Mitutoyo koordinatinė matavimo mašina Crysta Apex C9206 Matavimo diapazonai: 900x2000x600 mm Matavimo neapibrėžtis: 1,7 + 3L/1000µm Mašinos dangtis (Y ašis) pažeistas arba perdirbtas (už papildomą mokestį), Mechanika tvarkinga. Matavimo programinė įranga MCOSMOS-1 V3.5 su naudotu W10 kompiuteriu arba pasirinktinai už papildomą kainą: - Mitutoyo MCOSMOS 4.2 Geopak + MCAT100S arba naujas - EasyCMM I++ Server ir Inca Professional Matavimo galvutė Renishaw PH10T su pasirinktu matavimo davikliu: - Renishaw TP200 - Renishaw TP20 Dcodpfx Abjf S Tmvo Sjb Papildomos parinktys už papildomą mokestį: - Skenuojantis matavimo daviklis SP25M su PH10M - Keičiamų zondų stovas - Naujas PH10M+ ir TP200 (atnaujinimas) - Naujas Windows 11 kompiuteris - MCOSMOS neprisijungus licencija MCAT1000P - Bilz pneumatinė vibracijos slopinimo sistema Papildomai galima įrengimo ir kalibravimo paslauga (kelionės išlaidos papildomai) Į kainą įskaičiuota 3 mėn. garantija (be kelionės išlaidų)

Gamybos metai: 1979, Sąlyga: paruoštas naudoti (naudotas), Max. Schleifdurchmesser: 300 mm, Max. Schleiflänge: 1.950 mm, Max. Werkstücklänge: 2.000 mm Max. Vorschubgeschwindigkeit: 1–30 m/min Kühlmittelzufuhr: 100 l/min Stufenlos regelbarer Drehzahlbereich: 2.000–6.000 U/min Dcjdpfx Ashq Uigeb Ssb Spindel: 88 mm Spitzenhöhe: 150 mm Schleifscheiben: 100–250 mm Spindelleistung: 3,5 kW Gesamtleistung Schleifmaschine: 15 kW – 380 V – 50 Hz

Sąlyga: naudotas, Surface Grinding Machine BLOHM Type HFS 6 Serial No.: 10493 Year of Manufacture: 1973 Electro-magnetic chuck 600 x 300 mm Grinding length 600 mm Grinding width 400 mm Table longitudinal travel max. 650 mm Cross travel 350 mm Distance spindle center - table surface max. 600 mm Distance spindle center - magnetic chuck max. 517 mm Table clamping area 1020 x 300 mm Grinding wheel diameter 300 mm Dcsdpfjd Hbafjx Ab Sob Grinding wheel width 50 mm Grinding wheel bore 76 mm Table longitudinal feed 2–30 m/min, stepless Table cross feed 2–65 mm, stepless, electric Cross rapid traverse 3 m/min Vertical feed 0.001 – 0.020 mm per feed pulse Vertical rapid traverse 0.250 m/min Grinding wheel speed 1400 / 2800 rpm Motor power hydraulic pump 2.2 kW Motor power grinding spindle 5 / 6 kW Electrical connection 380 Volt, 50 Hz Total connected load 11 kW - Automatic depth infeed - Hydraulic table longitudinal movement - Grinding wheel dressing unit on the spindle head - Electromagnetic plate, construction height 83 mm - Side-mounted coolant unit with magnetic filter in the filter housing - Recirculating grinding spindle lubrication - Freestanding electrical cabinet (800 x 500 mm) - Swiveling control panel - Operating manual and spare parts list Space requirements L x W x H: 3000 x 2200 x 2100 mm Weight of surface grinding machine: 3000 kg Weight of control cabinet: 200 kg Good condition

Sąlyga: naudotas, TECHNINIAI DUOMENYS - Atstumas tarp centrų: 1000 [mm] - Centrų aukštis: 175 [mm] - X/Z eiga: 285/1150 [mm] - X ašies programuojamas padavimo greitis: [mm/min] - Skiriamoji geba: 0,0001 [mm] - Z ašies programuojamas padavimo greitis: [mm/min] - Skiriamoji geba: 0,0001 [mm] Dedpfsxt U Rhex Ab Sscb ŠLIFAVIMO DISKO LAIKIKLIO VERPTUVĖS KUMPELIS - Orientacija: 0/30 [laipsnių] * Šlifavimo disko matmenys: 500x63 [mm] DETALIŲ LAIKYMO VERPTUVĖ - Kūgio tipas: ISO50 - GALINĖ ATRAMA ELEKTROS TIEKIMAS - Maitinimo įtampa: 400 [V] DARBO VALANDOS - Darbo valandos: 28230 [val.] PRIEDAI - Valdymas: FANUC Oi-TD - Elektroninis rankenėlis - Automatinis deimantinis atnaujinimo įrenginys - Aušinimo skysčio talpa * su popieriniu filtru

Gamybos metai: 2018, Sąlyga: paruoštas naudoti (naudotas), Burri Werkzeugmaschinen generaliai atnaujintas Reishauer dantų paviršių šlifavimo staklės yra prieinamos. Šlifavimo ašies apsukos: 3500 aps./min, pjovimo greitis: 63 m/s, didžiausias krumpliaračio skersmuo: 360 mm, modulio ribos: 0,1-7, dantų skaičius: 6-600, didžiausias ruošinio aukštis: 160 mm, didžiausias nuolydžio kampas: +/-45°, didžiausias ruošinio svoris: apie 60 kg. Min. disko pamatinės apskritimo skersmuo: 250 mm, šlifavimo disko matmenys X/Y/Z: 350 mm/104 mm/160 mm, šlifavimo sraigto skersmens intervalas: 270 mm-350 mm, maks. šlifavimo plotis: 175 mm, maks. ruošinio sukimosi dažnis: 800 aps./min. Komplektacijoje: profiliravimo įrenginiai, balansavimo įranga, vibracijos kontrolės sistema, kompaktiška filtravimo sistema, aušinimo agregatas, aušinimo vandens šilumokaitis, robotizuota automatizacija ir transportavimo vežimėliai. Yra dokumentacija. Galima apžiūra vietoje. Dcjdsw Rqwaspfx Ab Sjb

Sąlyga: naudotas, Gamybos metai: 2002, Grinding diameter 350 mm Grinding length 1000 mm Centre height 175 mm Space requirement approx. 3.6 / 3.5 m Photos show identical machine with centre height 225 mm Base machine: Kellenberger Kel-Varia UR175-1000 Kelco 120 Grinding head UR with T1-T2-T3 Standard equipment: - T1: grinding wheel diameter 500 mm - T2: grinding wheel diameter 400 mm - B-axis infinitely variable, high-resolution - Marposs measuring system for tool measurement - Active longitudinal positioning - GAP control on T1 and T2 by ELASO, contactless integration in the control interface - Semi-automatic balancing by ELASO, integrated in the control interface - Tailstock with manual retraction - Workpiece spindle head MK5 with short taper mount DIN 55026 - Internal grinding attachment, belt driven Options available at extra cost: - New high-precision workpiece spindle head with torque drive - Internal grinding attachment for high-frequency spindles, 120 mm diameter - HF internal grinding spindle Fischer MFM-1224/42/31 D-21 - HF spindle with HSK interface, 24,000 rpm with integrated GAP sensor (lead time applies) - CNC-controlled C-axis - Non-circular (polygon) grinding - Hydrostatic lead screw in X - New hydrostatic unit with only 1 pump and accumulator for improved energy efficiency - Monitoring of water content in the hydrostatic system - Extraction system Further options available on request Mechanical overhaul: - Complete machine overhauled in accordance with Kellenberger test protocol - New easy-maintenance enclosure - New paintwork Electrical overhaul: - New, modern CNC CYLINDRICAL GRINDER CONTROL with BEMA grinding interface - Newly built control cabinet - New drive technology - Replacement of all electrical wiring, pressure switches, etc. - New absolute glass scales in X and Z axes - New absolute rotary encoder (for B-axis) Control system: The grinding software consists of a basic license and various optional modules depending on the machine’s equipment. Basic software features: - External and internal oscillation grinding - External and internal plunge grinding - External and internal face oscillation grinding - External and internal face plunge grinding - External and internal cylindrical oscillation grinding - External and internal radius grinding, radius dressed on the wheel - Semi-automatic oscillation grinding - Workpiece zero setting - Wheel zero setting - Measurement of dressing diamonds - 2 form diamonds - 1 form diamond or dressing roll (dressing roll required) - Form roll (dressing roll required) - 3 flat dressing units - Corrections - Z-position measurement (probe required) - GAP contact (touching device required) OPTIONS available at extra cost: Profile plunge grinding software: - External and internal profile plunge grinding with profile wheel Profile grinding software: - External and internal profile grinding with straight wheel Thread grinding software: - Single- and multi-start external and internal thread grinding with profile dressed on the wheel - Dressing of single- and multi-rib wheels - Flank angle freely selectable Trapezoidal thread grinding software: - Additional dressing of trapezoidal threads possible External and internal non-round plunge grinding: - External and internal non-round oscillation grinding Dsdpfx Aouxfucjb Sscb Non-round grinding software: Precondition for non-round grinding is equipping the workpiece spindle with a high-resolution rotary encoder to enable operation as a C-axis. The non-round...

Sąlyga: geras (naudotas), Gamybos metai: 1986, 1 used universal cylindrical grinding machine Type: SA 5 /630 Dodpfx Ajul Agbjb Socb Year of manufacture: 1986 Centre height: 140 mm Swing over bed: 280 mm Centre distance: 630 mm Table speed: 0.05 – 6 m/min Coolant system Weight: 4.5 t Technical data subject to change/errors excepted.

Gamybos metai: 1978, Sąlyga: labai geros būklės (naudotas), mašinos/transporto priemonės numeris: 2751, General / Technical Data: Hydraulic Horizontal Internal Broaching Machine in technically good condition Manufacturer: Karl Klink Model: RIW 6.3 Machine No.: 2751 Year of manufacture: 1978 Weight: 2.3 t Tensile force: 6.3 t Broaching speeds: hydraulically infinitely variable from 1 m/min to 7 m/min Return speed: hydraulically infinitely variable from 7 m/min to 25 m/min Maximum stroke: 1320 mm Maximum workpiece diameter: max. 420 mm Table opening: Ø 80 mm Dimensions (W x D x H): approx. 5,700 mm x 600 mm x 1,900 mm Power supply: 380 Volt / 50 Hz / 4 kW Accessories / Special features: - Coolant / lubricant unit Dsdpfx Aboiw Dlko Sjcb - Without automatic tool feeder - Oil and chip tray (approx. 2,000 mm) Note: The machine is ideal for machining keyways. Upon request, broaching tools and arbors can be supplied. The machine is available for demonstration under power in our warehouse.
