Hidraulinės lakštinės žirklės, pjovimo storis 5–7 mm pirkti naudotą (177)

Būklė: naujas, Bernardo Hydraulic Guillotine Shear HSB 2000 x 6 Cutting length: 2,000 mm Max. sheet thickness*: 6 mm Cutting angle: 1° 45‘ Motorised backgauge: 0 – 600 mm Strokes / min: 12 Kjdeqpfwyepfx Ap Eelt Number of hold-downs: 8 pcs. Table height: 800 mm Support arms: 3 pcs. Oil tank: 100 litres Motor power: 7.5 kW Length: 2,800 mm Depth: 2,800 mm Height: 1,670 mm Weight approx.: 3,925 kg * Material strength 400 N/mm² Scope of delivery: • Adjustable cutting gap • Cutting line illumination • Motorised NC backgauge • Front sheet supports • Side gauge • Angle stop • Safety guard with photocells • E21S control • Foot pedal with emergency stop • High-quality tool steel blades

Būklė: naudotas, Gamybos metai: 1990, Sheet width: 3050 mm Sheet thickness: 6 mm Frame width: 3460 mm Table height: 800 mm Pressure: 220 bar Cutting angle adjustment: 0.5–3° Hold-downs: 18 Back gauge (adjustable): 750 mm Front gauge (adjustable): 1000 mm Kledpeynbc Uofx Ap Eet Main motor: 7.5 kW Oil capacity: 300 l Total power requirement: 7.5 kW Machine weight approx.: 4.5 t Space requirements approx.: 3.7 x 2.0 x 1.8 m Cutting angle adjustment: manual Blade gap adjustment: manual Angle stop

Būklė: naujas, Sheet length: 6125 mm Sheet thickness: 6.0 mm Total power requirement: 11 kW Weight approx.: 22,000 kg Dimensions (LxWxH): 6910 x 3610 x 2780 mm Our powerful brand KKI CNC GUILLOTINE SHEAR, swing beam design, Model AS 6006, provides everything you need for perfect cutting. CNC swing beam guillotine shear KKI Thanks to its robust and durable mechanical and hydraulic components, precise ball-screw rear gauge, and user-friendly CNC control system, Dener guillotine shears are highly efficient production machines. Shears for sheet thicknesses from 6 mm to 20 mm and cutting lengths from 3 to 6 meters are part of our standard portfolio. Of course, higher sheet thicknesses and longer cutting lengths can be provided upon customer request. Dener guillotine shears owe their long service life to their particularly robust, fully-welded frame construction. The entire machine body, cutting beam, and backgauge are resistant to torsion and deformation, ensuring the highest cut quality. By entering sheet thickness and material type, the CNC control automatically calculates the required cutting angle and gap. Our strong brand KKI CNC GUILLOTINE SHEAR, model AS 6006, offers everything required for perfect cutting. Technological Advantages: - Fast and precise cuts - Sturdy, durable frame construction - Automatic blade gap adjustment - Simple operation - Low maintenance costs - High safety standards - Use of components from renowned manufacturers - Low unit costs Our strong brand KKI CNC GUILLOTINE SHEAR, swing beam design, model AS 6006, offers everything you need for perfect cutting. With our patented blade support system, the upper blade can be finely adjusted and stabilized, ensuring precise, high-quality cuts and preventing so-called banana cuts. Technical Data: - Sheet thickness: 6 mm - Cutting length: 6,125 mm - Cutting angle: 0.5 – 2.5° Kledpfx Ajd Ehh Hsp Eot - Number of hold-downs: 31 - Backgauge: 1,000 mm via CNC - Motor power: 11 kW - Cutting speed (0.5–2.5°): 14–6 (cuts/min) - Throat: 350 mm - Oil tank: 475 liters - Length: 6910 mm - Width: 2200 / 3610 mm - Height: 2780 mm - Weight: 22,000 kg • Swing beam design • CNC control system for: - Backgauge - Cutting angle - Blade gap - Cutting length • Ball screws for backgauge • Ball transfers in the table • Side gauge 1,500 mm • 2 support arms, each 1,000 mm • Cutting line illumination • Fingershield, foldable up to 1,000 mm Optional pneumatic sheet support, EURO 12,650 We have many references available!

Būklė: naujas, Sheet length: 4120 mm Sheet thickness: 6.0 mm Total power requirement: 11 kW Weight approx.: 8,000 kg Dimensions (LxWxH): 4,890 x 2,750 x 1,820 mm Our robust brand KK kletzer NC GUILLOTINE SHEAR, oscillating cut design Model BS offers everything you need for sheet cutting. Technological advantages: - Fast and precise cuts - Stable, durable frame construction - Simple operation - Low maintenance costs - High safety standard - Use of components from renowned manufacturers - Low unit costs Technical data: Sheet thickness: 6 mm Cutting length: 4,160 mm Cutting angle: 1.33° Number of hold-downs: 19 Backgauge: 1,000 mm (CNC controlled) Motor power: 11 kW Cutting speed: 14 cuts/min Throat depth: 150 mm Hydraulic tank: 240 litres Length: 4,890 mm Width: 2,050 / 2,745 mm Height: 1,820 mm Weight: 8,000 kg • Robust oscillating cut design Adjustment of blade gap via the control system - Backgauge - Blade gap - Cutting length • Ball screw drive for the backgauge • Ball transfer table • Side stop, 1,500 mm • 2 support arms, each 1,000 mm • Cutting line illumination • 1,000 mm foldable finger guard Optional pneumatic sheet support system, EUR 8,420 Kodpfx Asd Eqrgep Eslt We have numerous references!

Būklė: naujas, Sheet length: 3120 mm Sheet thickness: 6.0 mm Total power requirement: 11 kW Weight approx.: 6500 kg Dimensions (LxWxH): 3850 x 2750 x 1700 mm Our powerful brand KK Kletzer NC GUILLOTINE SHEAR (Swing Beam Design) Model BS has everything you need for cutting. NC guided guillotine shear KKI Technological advantages: - Fast and precise cuts Kjdpfxsd Eqrms Ap Eelt - Stable, durable frame construction - Easy operation - Low maintenance costs - High safety standard - Use of components from renowned manufacturers - Low unit costs Technical data: Sheet thickness: 6 mm Cut length: 3,120 mm Cutting angle: 1.39° Number of hold-downs: 15 Backgauge: 1,000 mm CNC-controlled Motor power: 11 kW Cutting speed: 18 cuts/min Throat depth: 150 mm Oil tank: 200 liters Length: 3,060 mm Width: 2,050 / 2,745 mm Height: 1,700 mm Weight: 6,500 kg • Stable swing beam design - Blade gap adjustment via the control - Backgauge - Blade gap - Cut length • Ball screw spindles for the backgauge • Balls in the table • Side gauge 1,500 mm • 2 support arms, 1,000 mm each • Cutting line illumination • 1,000 mm swing-up finger guard Optional pneumatic sheet support, EURO 5,500 We have many references!

Būklė: naujas, Sheet length: 2100 mm Sheet thickness: 6.0 mm Total power requirement: 11 kW Weight approx.: 5500 kg Dimensions (LxWxH): 3110x2195x1770 mm Our robust brand KK Kletzer CNC GUILLOTINE SHEAR, oscillating cutting version, model SWT, has everything you need for cutting tasks. We have also raised the standard for the oscillating cut version and deliver all our shears with automatic blade gap adjustment via the ELGO P40T touchscreen control at no extra charge. NC link-guided guillotine shear KKI Technological Advantages: - Fast and precise cuts - Stable, durable frame construction - Automatic blade gap adjustment Kodpfxsfhlbde Ap Ejlt - Easy operation - Low maintenance costs - High safety standard - Use of components from renowned manufacturers - Low unit costs Technical specifications: Maximum sheet thickness: 6 mm Cutting length: 2,100 mm Cutting angle: 1.5° Number of hold-downs: 15 Back gauge: 1,000 mm, CNC-controlled Motor power: 11 kW Strokes per minute: 18 Throat depth: 50 mm Oil tank capacity: 200 liters Length: 3110 mm Width: 2195 mm Height: 1770 mm Weight: 5500 kg • Sturdy oscillating cut design • Blade gap adjustment via control system - Back gauge - Blade gap - Cutting length • Ball screw spindle for back gauge • Balls in worktable • Side stop 1,500 mm • 2 support arms, 1,000 mm each • Cutting line illumination • Flip-up finger guard (up to 1,000 mm) Option: - Pneumatic sheet support, EURO 3,900.-- We have many references!

Būklė: naujas, Sheet length: 3,200 mm Sheet thickness: 6.0 mm Cutting width: 3,200 mm Total power requirement: 7.5 kW Weight approx.: 8,500 kg Dimensions (LxWxH): 4,650 x 1,700 x 1,800 mm Technical data: Sheet thickness: 6 mm Cutting length: 4,200 mm Cutting angle: 1.50° Backgauge: motorized, 1,000 mm Motor power: 7.5 kW Length: 4,650 mm Width: 1,700 mm Height: 1,800 mm Weight: 8,500 kg Equipment: Swing cut design NC preset control ELGO P 40 T Touch with backgauge and blade gap adjustment from the front via the control panel Motorized backgauge up to 1,000 mm Clearly arranged control panel mounted on swiveling arm Kedped Ab Hhjfx Ap Eslt Hydraulic hold-downs positioned close to the cutting edge Foot switch Blade gap adjustment Cutting line illumination Wide support table with ball transfers Folding finger guard, 1,000 mm 1 side stop with T-slot 2 sheet support arms with T-slot Easy blade changing and re-sharpening Adjustable cutting length for efficient processing Lower blade with 4 usable edges Upper blade with 2 usable edges Qualified customer service Operating manual in ENGLISH Machine and equipment in accordance with CE standards

Būklė: naujas, Sheet length: 3,200 mm Sheet thickness: 6.0 mm Cutting width: 3,200 mm Total power requirement: 7.5 kW Approx. weight: 5,100 kg Dimensions (LxWxH): 3,800 x 1,750 x 1,700 mm Technical Data: Sheet thickness: 6 mm Cutting length: 3,200 mm Cutting angle: 1.30° Backgauge: motorized, 1,000 mm Motor power: 7.5 kW Length: 3,800 mm Width: 1,750 mm Height: 1,700 mm Weight: 6,250 kg Kljdpfovap Tuex Ap Eot Equipment: Swing-beam shear design NC preselection control ELGO P 40 T with backgauge and cutting gap adjustment from the front via control panel motorized backgauge up to 1,000 mm clear control panel mounted on swivel arm hydraulic hold-downs positioned close to the cutting edge foot switch cutting gap adjustment cutting line illumination wide support table with ball transfers fold-up finger guard, 1,000 mm 1 T-slot side stop 2 sheet support arms with T-slot simple blade changing and regrinding adjustable cutting length for efficient processing bottom blade with 4 cutting edges (reversible) top blade with 2 cutting edges (reversible) qualified customer service Operating manual in ENGLISH Machine and equipment in accordance with CE regulations

Būklė: naujas, Sheet length: 4065 mm Sheet thickness: 6.0 mm Total power requirement: 11 kW Weight approx.: 11,150 kg Dimensions (LxWxH): 4830 x 2955 x 2130 mm Our strong brand KKI CNC GUILLOTINE SHEAR, link-type Model AS 4006 offers everything you need for perfect cutting operations. CNC guided guillotine shear KKI Thanks to a robust and durable mechanical and hydraulic system, a precise backgauge with ball screw, and a user-friendly CNC control, Dener guillotine shears are highly efficient production machines. Shears for sheet thicknesses from 6 mm to 20 mm and cutting lengths from 3 to 6 m are part of our standard portfolio. On request, higher sheet thicknesses and cutting lengths are also available. Dener guillotine shears owe their long service life to their particularly robust construction with a fully welded frame. The entire machine body, the cutting beam, and the backgauge are resistant to torsion and deformation, ensuring the highest cutting quality. By entering the sheet thickness and material type, the CNC control automatically calculates the necessary cutting angle and cutting gap. Our strong brand KKI CNC GUILLOTINE SHEAR, link-type Model AS 4006 has everything you need for perfect cutting results. Kedpfed Egqwjx Ap Eolt Technological advantages: - Fast and precise cuts - Stable, long-lasting frame construction - Automatic cutting gap adjustment - Easy to operate - Low maintenance costs - High safety standards - Use of components from renowned manufacturers - Low unit costs Our strong brand KKI CNC GUILLOTINE SHEAR, link-type Model AS 4006 has everything you need for perfect cutting results. With our patented blade support system, we can finely adjust and stabilize the upper blade, ensuring precise high-quality cuts. The so-called 'banana cut' is prevented. Technical data: Sheet thickness: 6 mm Cutting length: 4,065 mm Cutting angle: 0.5 - 3° Number of hold-downs: 23 Backgauge: 1,000 mm via CNC Motor power: 11 kW Cutting speed (0.5 - 3°): 23–9 (cuts/min) Throat depth: 350 mm Oil tank: 200 liters Length: 4,830 mm Width: 2,300 / 2,955 mm Height: 2,130 mm Weight: 11,150 kg • Link-type execution • CNC control - Backgauge - Cutting angle - Cutting gap - Cutting length • Ball screw for backgauge • Ball rollers in table • Side gauge 1,500 mm • 2 support arms 1,000 mm • Cutting line illumination • Foldable finger guard up to 1,000 mm Optional pneumatic sheet support, EUR 8,420,-- We have many references!

Būklė: naujas, Sheet length: 3100 mm Sheet thickness: 6.0 mm Total power requirement: 11 kW Approximate weight: 7000 kg Dimensions (LxWxH): 4110 x 2195 x 1770 mm Our strong brand, KKKletzer CNC GUILLOTINE SHEAR swing beam type, Model SWT, provides everything you need for precise cutting. Even in the swing beam design, we have raised the standard and now supply our guillotine shears with automatic blade gap adjustment via the ELGO P40T touchscreen control, without extra charge. NC link-guided guillotine shear KKI Technological advantages: - Fast and precise cuts - Stable, durable frame construction - Automatic blade gap adjustment - Simple operation - Low maintenance costs - High safety standards - Use of components from renowned manufacturers - Low unit costs Technical data: Kedpfxod Eqrns Ap Eolt Sheet thickness: 6 mm Cutting length: 3,100 mm Cutting angle: 1.5° Number of hold-downs: 15 Backgauge: 1,000 mm via CNC Motor power: 11 kW Strokes per minute: 16 Throat depth: 50 mm Oil tank: 200 liters Length: 4,110 mm Width: 2,195 mm Height: 1,770 mm Weight: 7,000 kg • Stable swing beam construction • Blade gap adjustment via control system - Backgauge - Blade gap - Cutting length • Ball screw drive for backgauge • Ball transfers in the table • Side gauge 1,500 mm • 2 support arms 1,000 mm each • Cutting line illumination • 1,000 mm foldable finger guard Option: • Pneumatic sheet support, EURO 3,900.-- We have many references!

Būklė: naujas, Sheet length: 4100 mm Sheet thickness: 6.0 mm Total power requirement: 15 kW Weight approx.: 10,200 kg Dimensions (LxWxH): 4120x2195x1770 mm Our strong brand KK Kletzer - CNC GUILLOTINE SHEAR swingshear design Model SWT has everything you need for cutting. We have also raised the standard in the swing beam design and supply our guillotine shears with automatic blade gap adjustment via ELGO P40T touchscreen control at no extra charge. NC guided guillotine shear KKI Technological advantages: - Fast and precise cuts - Robust, durable frame construction - Automatic blade gap adjustment - Easy to operate - Low maintenance costs - High safety standard Kjdpfx Ajd Tm Rbsp Eelt - Use of components from well-known manufacturers - Low unit costs Technical Data: Sheet thickness: 6 mm Cutting length: 4,100 mm Cutting angle: 1.5° Number of hold-downs: 19 Backgauge: 1,000 mm via CNC Motor power: 15 kW Strokes per minute: 12 Throat depth: 50 mm Length: 5120 mm Width: 2195 mm Height: 1770 mm Weight: 10,200 kg • Robust swing beam design • Blade gap adjustment via controller - Backgauge - Blade gap - Cutting length • Ball screw spindle for backgauge • Ball transfers in the table • Side stop 1,500 mm • 2 support arms, each 1,000 mm • Cutting line illumination • Flip-up finger guard to 1,000 mm Option: Pneumatic sheet support, EUR 4,900 We have numerous references!

Būklė: naujas, Sheet length: 3035 mm Sheet thickness: 6.0 mm Total power requirement: 11 kW Weight approx.: 8,300 kg Dimensions (LxWxH): 3775x2955x2260 mm Our strong brand KKI CNC GUILLOTINE SHEAR, swinging beam type, Model AS 3006 has everything you need for perfect cutting. CNC swinging beam guillotine shear KKI: Thanks to robust and durable mechanics and hydraulics, a precise backgauge with ball screw drive, and user-friendly CNC control, Dener guillotine shears are highly effective production machines. Shears for sheet thicknesses from 6 mm to 20 mm and cutting lengths from 3 to 6 meters belong to our standard portfolio. Of course, greater sheet thicknesses and cutting lengths are available upon customer request. Dener guillotine shears owe their long service life to their particularly robust design with a fully welded frame. The entire machine body, the cutting beam, and the Kljdpfx Apod Egq Ae Est backgauge are resistant to torsion and deformation, thus enabling the highest cutting quality. By entering the sheet thickness and material type, the CNC control automatically calculates the required cutting angle and blade gap. Our strong brand KKI CNC GUILLOTINE SHEAR, swinging beam type Model AS 3006 has everything you need for perfect cutting. Technological advantages: - Fast and precise cuts - Stable, durable frame construction - Automatic adjustment of the blade gap - Easy operation - Low maintenance costs - High safety standards - Use of components from renowned manufacturers - Low unit costs Our strong brand KKI CNC GUILLOTINE SHEAR, swinging beam type Model AS 3006 has everything you need for perfect cutting. With our patented blade support system, we can finely adjust and stabilize the upper blade, guaranteeing precise, high-quality cuts. Banana-shaped cuts (curvature) are thus prevented. Technical Data: Sheet thickness: 6 mm Cutting length: 3,035 mm Cutting angle: 0.5 - 3° Number of hold-downs: 15 Backgauge: 1,000 mm via CNC control Motor power: 11 kW Cutting speed (0.5 - 3°): 29-12 (cuts/min) Throat depth: 350 mm Oil tank: 200 liters Length: 3,775 mm Width: 2,300 / 2,955 mm Height: 2,260 mm Weight: 8,300 kg • Swinging beam design • CNC control - Backgauge - Cutting angle - Blade gap - Cutting length • Ball screw drives for • Ball transfer tables • Side gauge 1,500 mm • 2 support arms, each 1,000 mm • Cutting line illumination • Folding finger guard up to 1,000 mm high Optional pneumatic sheet support, EURO 6,320,-- We have numerous references!

Būklė: naujas, Sheet length: 3,200 mm Sheet thickness: 6.0 mm Cutting width: 3,200 mm Total power requirement: 7.5 kW Weight approx.: 6,250 kg Dimensions (LxWxH): 4,180 x 2,150 x 2,000 mm Technical Data: Sheet thickness: 6 mm Cutting length: 3,200 mm Cutting angle: 1.30° Backgauge: motorized, 1,000 mm Motor power: 7.5 kW Length: 4,000 mm Width: 1,700 mm Height: 1,800 mm Weight: 6,250 kg Equipment: Swing-beam cutting design NC preselection control ELGO P 40 T with backgauge and cutting gap adjustment from the front via control panel motorized backgauge up to 1,000 mm clearly arranged control console mounted on swivel arm hydraulic hold-downs positioned close to the cutting edge foot switch Klodpfxjh Talzs Ap Est cutting gap adjustment cutting line illumination broad support table with ball transfers foldable finger guard, 1,000 mm 1 side gauge with T-slot 2 sheet support arms with T-slot simple blade replacement and regrinding adjustable cutting length for efficient processing lower blade can be used 4 times upper blade can be used 2 times qualified customer service OPERATING MANUAL IN ENGLISH Machine and equipment in compliance with CE regulations

Būklė: naudotas, Sheet thickness: 6 Motor: 10 Dimensions (LxWxH): 3750 x 1600 x 2450 Sheet length: 3050 Weight approx.: 4800 Description: Hydraulic Guillotine Shear ATLANTIC ATS 3000 Used Machine Sheet width: 3050 mm Sheet thickness: 6.0 mm Sheet thickness for stainless steel: 4.0 mm Cutting angle: 0.5 - 3.0 ° Hold-downs: 18 units Strokes per minute: 9 / 14 spm Back gauge – adjustable: max. 750 mm Control: conventional Motor power: 10.0 kW Weight: 4800 kg Dimensions L-W-H: 3750 x 1600 x 2450 mm Well-maintained condition Equipment: - Electro-hydraulic, link-guided guillotine shear - Front control panel, left side – easy to operate - With electro-hydraulic cutting angle adjustment - With manual blade gap adjustment, accessible from the rear - Electro-motorized back gauge, 10-750 mm - With analogue position display + handwheel for fine adjustment - 1x robust side gauge Kledpfx Apju Uwyys Ejt - 1x movable foot switch - Front finger/hand guard - 2x emergency stop buttons at front

Būklė: naujas, HYDRAULIC SHEAR MVD MODEL iSHEAR B 06-4000 COMPLETE WITH REAR PNEUMATIC SHEET SUPPORT. Kodpfx Apjfh R Ins Eslt CNC ESA S 625 TECHNICAL SPECIFICATIONS Cutting capacity for material 450N/mm2: 06 mm Cutting capacity for material 700N/mm2: 04 mm Cutting length: 4100 mm Fixed cutting angle: 1.5° Sheet-holding cylinders: 18 Strokes per minute: 10 – 14 Throat depth: 250 mm Motor power: 10 kW Millimetric square and two sheet supports: 1000 mm Backgauge travel: 1000 mm Approximate weight: 11,000 kg

Būklė: naudotas, Maks. pjovimo ilgis: 3 000 mm Maks. lakštinio plieno storis: 6 mm Motorizuotas galinis atmušas su skaitmeniniu indikatoriumi iki 1 000 mm Šoninis atmušas ir stalo prailginimai Pjovimo ilgio ribotuvas Ksdovmz Nbspfx Ap Ejlt Pjovimo krašto apšvietimas Hidraulinis kirpimo kampo reguliavimas Galąsti peiliai Svoris: apie 6 500 kg Puiki būklė

Būklė: naudotas, Gamybos metai: 1978, Sheet width 3100 mm Sheet thickness 2 mm Back gauge 1000 mm Kljdpfouagxpsx Ap Est Shear angle 1°06' Stroke rate 45 strokes/min Total power requirement 3.0 kW Space requirement approx. 3600 x 2200 x 1600 mm Weight 4500 kg Equipment: - Electrically driven motorized back gauge - Digital ELGO position display - Manual blade clearance adjustment - 1x side gauge with mm scale - 2x support arms - 1x movable double foot switch - Front finger guard Special accessories included: - Pneumatic sheet metal support device for thin sheet cuts

Būklė: naudotas, Gamybos metai: 1989, Sheet width: 2540 mm Sheet thickness: 6 mm Backgauge: 900 mm Hold-downs: 14 pcs Strokes per minute: 20 Ksdpfx Asvg R Sfjp Eolt Total power requirement: 10 kW Space requirements approx.: 3100 x 2200 x 2600 mm Weight: 5000 kg Equipment: - Central lubrication - Electric backgauge - 1x side gauge 2350 mm - 2x front support arms with stop 1700 mm - Front finger guard - Spare blade (used) - Foot switch

Būklė: naujas, Sheet width 4100 mm Sheet thickness 10.0 mm Sheet thickness for stainless steel 6.0 mm Hold-downs 28 pieces Strokes 18 strokes/min Oil capacity 260 ltr. Cutting angle 0.5 - 2° Control CYBELEC Cybtouch Motor power 22.0 kW Backgauge - adjustable 1000 mm Dimensions (L-W-H) 6100 x 2580 x 2460 mm Weight 15,100 kg The manufacturer ERMAK offers with its hydraulically guided guillotine shear model series HVR a robust and durable machine for economical sheet metal processing. This compact all-rounder allows you to increase your productivity. The hydraulic guillotine shear model HVR supports you with precise, fast, and cost-efficient cutting in your daily workflow. The use of hydraulic hold-downs to secure the sheet and the support table with integrated ball rollers ensures ergonomic and efficient cutting for the operator. The CNC control enables the use of various types of sheet metal, which are already stored in the material library. After selecting the maximum thickness and material type, the optimal blade clearance and cutting angle are set automatically via the CNC control (electro-hydraulic adjustment), but can also be manually adjusted. The position and retract function of the motorized backgauge can be conveniently set via the touchscreen. Additionally, the control offers memory for cutting programs with cutting sequences. Ksdpexabwujfx Ap Eolt ----- Robust electro-hydraulic CNC guillotine shear, guided by guideways * including CYBELEC CNC touch screen controller * including CNC electro-hydraulic blade clearance adjustment * including CNC electro-hydraulic cutting angle adjustment ----- Equipment/features: - CNC electro-hydraulic guillotine shear, guideway/slideway guided - including CYBELEC CNC touch screen controller, model "CybTouch 8" - Some functions of the CNC control: * Backgauge preset (X axis) * Blade clearance adjustment * Piece counter * Cutting length limitation * Material selection including sheet thickness * Cut line illumination (cutting to scribed line) ...and many more - Motorized backgauge, travel 5.0 - 1,000 mm (X axis) * On ball screw spindle * Automatic swing-up at maximum travel for longer cuts * Includes selectable "Swing-Away" retract function * Positioning accuracy 0.1 mm * Approx. traverse speed 80 mm/sec - 1x side gauge with T-slot and mm scale - 2x front support arms with T-slot and mm scale - Ball rollers in the front support table - Folding finger guard with safety switch * Finger guard with viewing windows for cutting to scribed line - Cut line lighting with shadow projection - BOSCH/HOERBIGER hydraulic system - SIEMENS electrical system - Light curtain at the rear of the machine (safety device) - Mobile foot switch - CE marking/declaration of conformity - Operating manual + wiring diagram + hydraulic diagram Including special equipment: - Pneumatic sheet metal support device for thin sheet cutting * Monoblock design

Būklė: naujas, Sheet width: 3,100 mm Sheet thickness: 6.0 mm Klodjxaa D Hopfx Ap Ejt Sheet thickness (stainless steel): 4.0 mm Frame width: 3,100 mm Hold-downs: 14 pieces Oil capacity: 150 ltr. Strokes: 18 strokes/min Cutting angle: 1.2° Control: CYBELEC CybTouch Total power requirement: 11.0 kW Weight: 6,300 kg Dimensions L-W-H: 4,000 x 2,100 x 1,640 mm The manufacturer ERMAK offers you with the hydraulic swing beam shear, model series HGS, a robust and durable machine for economical sheet metal processing. With this compact all-rounder, you can increase your productivity. The HGS hydraulic swing beam shear supports you with precise, fast, and cost-effective cuts in your daily workflow. The use of hydraulic hold-downs for sheet fixation and the support table with integrated ball rollers ensure ergonomic and efficient cutting for your operator. The CNC control allows the use of various sheet types, which are already stored in the material library. After selecting the maximum thickness, the optimal cutting gap is automatically set electro-hydraulically by the CNC control, but can also be adjusted manually. The position and retract function of the motorized backgauge can be easily set via touchscreen. Furthermore, the control offers a memory for cutting programs with sequence management. ----- Robust electro-hydraulic CNC swing beam shear * Including CYBELEC CNC touch screen control * Including CNC electro-hydraulic cutting gap adjustment ----- Equipment: - CNC electro-hydraulic swing beam shear - Including CYBELEC CNC Touch Screen Controller, model “CybTouch 8” - Some functions of the CNC control: * Backgauge preselection – X axis * Cutting gap adjustment * Piece counter * Cut length limitation * Material preselection, including sheet thickness * Cutting line illumination (cutting to scribe line), etc. - Motorized backgauge, travel range = 5.0 – 1,000 mm (X axis) * on ball screw spindles * automatically folding up at maximum travel, for longer cuts * including selectable retract function (“Swing-Away function”) * positioning accuracy 0.1 mm * travel speed 80 mm/sec - 1x side gauge, with T-slot and mm scale - 2x front support arms, with T-slot and mm scale - Ball rollers in the front support table - Folding finger guard with safety switch * finger guard with viewing windows for scribed line cutting - Cutting line illumination with shadow projection - BOSCH/HOERBIGER hydraulic system - SIEMENS electrical system - Light curtain behind the machine (safety device) - Freely movable foot switch - CE mark/declaration of conformity - Operating manual + wiring diagram + hydraulic diagram Including special equipment: - Pneumatic sheet support device for thin sheet metal cuts

Būklė: naudotas, Gamybos metai: 1987, Sheet width: 3050 mm Sheet thickness: 6.0 mm Sheet thickness for stainless steel: 4.0 mm Cutting angle: 0.5 - 3.0° Hold-down clamps: 18 units Strokes: 9 / 14 strokes/min Backgauge - adjustable: max. 750 mm Control: conventional Motor power: 10.0 kW Weight: 4800 kg Dimensions (LxWxH): 3750 x 1600 x 2450 mm Well-maintained condition (!!) Equipment: - Electro-hydraulic / link-guided guillotine shear - Front operating panel, left side – easy to use - With electro-hydraulic cutting angle adjustment - With manual blade gap adjustment, accessible from the rear - Electrically operated backgauge 10-750 mm Ksdpfx Apoxab Aqs Ejlt - With analogue position display + handwheel for fine adjustment - 1x robust side gauge - 1x movable foot switch - Front finger/hand safety guard - 2x emergency stop buttons at front - Operating manual (PDF)

Būklė: naudotas, Gamybos metai: 2008, Sheet width 4100 mm Sheet thickness 6.0 mm Sheet thickness for stainless steel 4.0 mm Strokes per minute 12 - 24 SPM Cutting angle 1° 30' Working height 865 mm Backgauge - adjustable 1.0 - 1000 mm Hold-downs 20 pcs Control ENC 100 M Throat depth 50.0 mm Oil capacity 200 ltr Total connected load 15.0 kW Dimensions L-W-H 5230 x 2250 x 2150 mm Weight 11,460 kg Original price ~ 50,000 Euro (!!) Special price on request ----- NC electro-hydraulic swing beam shear * with DURMA "ENC 100 M" control unit * manual blade gap adjustment (eccentric) * incl. pneumatic sheet support for thin sheet cutting ----- Equipment: - Robust electro-hydraulic swing beam shear - Including DURMA "ENC 100M" NC control unit * Backgauge preselection – X axis * Counter preselection * Cutting length limitation * Swiveling control panel, front left - Monoblock welded steel construction made of high-quality steel - CNC electro-motorized backgauge * with ball screw and linear guides * automatic backgauge retraction during cutting process Kodpew U U T Tefx Ap Eolt - Light barrier protection for rear access to the machine - Manual blade gap adjustment via eccentric - High-performance hydraulic cylinders made of SAM 1040 material - Hydraulic pistons, high-quality chrome-plated and finely honed - Split, foldable finger guard 1,000 mm - Easy sheet handling via ball transfer rollers in the table - 1x long side gauge incl. mm scale and stop dog - 3x front support arms - 1x freely moveable foot switch - Operating manual Special accessories included: - Pneumatic sheet support device for thin sheet cutting - For max. material thickness – ST ... 3.0 mm

Būklė: naujas, Sheet width: 3100 mm Sheet thickness: 6.0 mm Sheet thickness (stainless steel): 4.0 mm Frame gap: 3100 mm Hold-down clamps: 14 units Strokes per minute: 18 strokes/min Oil capacity: 150 l Shear angle: 1.2° Control unit: CYBELEC CybTouch Total connected load: 11.0 kW Weight: 6300 kg Dimensions L x W x H: 4,000 x 2,100 x 1,640 mm With the hydraulic swing beam shear of the HGS model series, the manufacturer ERMAK offers a robust and durable machine for economical sheet metal processing. This compact all-round machine boosts your productivity. The HGS hydraulic swing beam shear supports you with precise, fast, and cost-effective cuts during your daily workflow. Hydraulic hold-down devices fix the metal sheet securely, while the support table with integrated ball casters ensures ergonomic and efficient cutting for the operator. The CNC control allows you to select from different sheet types already stored in the material database. After choosing the maximum thickness, the optimal blade gap is set automatically via CNC electro-hydraulic adjustment, but can also be set manually. The position and retraction function of the motorized backgauge can be easily adjusted via touchscreen. Furthermore, the control stores cutting programs with sequences. ----- Robust electro-hydraulic CNC swing beam shear * including CYBELEC CNC touch screen control * including CNC electro-hydraulic blade gap adjustment ----- Equipment: - CNC electro-hydraulic swing beam shear - including CYBELEC CNC touch screen controller, model "CybTouch 8" - main CNC functions: Kodjxabzgepfx Ap Eslt * backgauge preselection – X axis * blade gap adjustment * piece counter * cutting length limitation * material preselection, including sheet thickness * cutting line illumination (cutting to scribe line), and many more - motorized backgauge, travel range: 5.0 – 1,000 mm (X axis) * on ball screw spindles * automatically retractable at maximum travel, for longer cuts * including selectable retraction function ("swing-away function") * positioning accuracy: 0.1 mm * travel speed: 80 mm/sec. - 1x side gauge with T-slot and mm scale - 2x front support arms with T-slot and mm scale - ball casters integrated in the front support table - hinged finger safety guard with safety switch * finger guard with viewing windows for scribe line cutting - cutting line illumination with shadow projection - BOSCH/HOERBIGER hydraulic system - SIEMENS electrical system - light curtain at the rear of the machine (safety device) - mobile foot switch - CE marking/conformity declaration - operating manual + electrical diagram + hydraulic diagram Included special equipment: - pneumatic sheet support for thin sheet cutting

Būklė: naujas, Sheet width: 3100 mm Sheet thickness: 6.0 mm Frame width: 3,100 mm Hold-downs: 14 units Strokes: 16 - 24 strokes/min Oil capacity: 150 ltr. Klsdpfxjxabcqj Ap Ejt Cutting angle: 0.5 - 1.5° Sheet thickness (stainless steel): 4.0 mm Frame throat: 350 mm Motor power: 11.0 kW Machine weight: approx. 7,060 kg Dimensions (L-W-H): 4.1 x 2.2 x 2.19 m The manufacturer ERMAK offers, with its hydraulically-guided swing beam shear of the HVR series, a robust and durable machine for the economical processing of sheet metal. This compact all-round machine allows you to increase your productivity. The hydraulic guillotine shear, model HVR, supports you with precise, fast, and cost-efficient cuts in your daily workflow. By utilizing hydraulic hold-downs to secure the sheet and a support table with integrated ball rollers, ergonomic and efficient operation for your operator is ensured. The CNC control enables the selection of various sheet types, which are already available in the material library. After choosing the maximum thickness and material type, the optimal blade gap and cutting angle are automatically set electro-hydraulically via the CNC system but can also be adjusted manually. The position and retract function of the motorized backgauge are easily set via touchscreen. Additionally, the controller provides a memory for cutting programs with cutting sequences. ----- Robust electro-hydraulic CNC swing beam guillotine shear * Includes CYBELEC CNC touchscreen control * Includes CNC electro-hydraulic blade gap adjustment * Includes CNC electro-hydraulic cutting angle adjustment ----- Equipment: - CNC electro-hydraulic swing beam guillotine shear - Including CYBELEC CNC touchscreen controller, model "CybTouch 8" - Selected CNC control functions: * Backgauge preselection - X axis * Blade gap adjustment * Piece counter * Cut length limiter * Material selection, including sheet thickness * Cut line illumination (cutting to scribe line) ...and many more - Motorized backgauge, travel range = 5.0 - 1,000 mm (X axis) * On ball screw spindles * Automatically folds up at maximum travel for longer cuts * Including selectable retract function ("Swing-Away Function") * Positioning accuracy 0.1 mm * Approx. travel speed 80 mm/sec - 1x side stop, with T-slot and mm scale - 2x front support arms, with T-slot and mm scale - Ball rollers in front sheet support table - Hinged finger guard with safety switch * Finger guard with viewing windows for scribe cutting - Cut line illumination with shadow projection - BOSCH/HOERBIGER hydraulic system - SIEMENS electrical system - Light curtain at rear of machine (safety feature) - Movable foot switch - CE mark / Declaration of Conformity - Operating manual + wiring diagram + hydraulic diagram Including special equipment: - Pneumatic sheet support device for thin sheet cutting

Būklė: naujas, Sheet width: 2100 mm Sheet thickness: 6.0 mm (ST 42) Sheet thickness for stainless steel: 4.0 mm (VA) Cutting angle: 1.2 degrees Strokes: 28 strokes/min Oil capacity: 150 liters Hold-down devices: 11 pcs Control: CYBELEC CybTouch Motor power: 11.0 kW Backgauge – adjustable: 1,000 mm Table height: 800 mm Weight: 4,500 kg Dimensions (L-W-H): 3,010 x 2,100 x 1,640 mm The manufacturer ERMAK offers you, with the HGS series hydraulic swing beam shear, a robust and durable machine for the efficient processing of sheet metal. With this compact all-round machine, you can increase your productivity. The HGS hydraulic swing beam shear supports you in precise, fast, and cost-effective cutting operations in your daily workflow. The use of hydraulic hold-downs to secure the sheet and the support table with integrated ball transfers ensure ergonomic and efficient cutting for your operator. The CNC control allows you to work with various sheet materials already preset in the material library. Once the maximum thickness is selected, the optimal blade gap is set automatically via the CNC electro-hydraulic control but can also be adjusted manually. The position and retract function of the motorized backgauge can be easily set via the touchscreen. Additionally, the controller provides memory for cutting programs including cutting sequences. ----- Robust electro-hydraulic CNC swing beam shear * incl. CYBELEC CNC touch screen control * incl. CNC electro-hydraulic blade gap adjustment ----- Equipment: - CNC electro-hydraulic swing beam shear - incl. CYBELEC CNC touch screen controller, model "CybTouch 8" - Selected features of the CNC control: * Backgauge preselection – X-axis * Blade gap adjustment * Quantity setting * Cutting length limitation * Material selection, incl. sheet thickness * Cutting line illumination (cutting on scribed line) ... and much more - Motorized backgauge, travel range = 5.0 – 1,000 mm (X-axis) Kjdpfx Aoxaa Acop Eelt * Running on precision ball screws * Automatic swing-up at maximum travel for long cuts * Incl. retract function selectable ("swing-away function") * Positioning accuracy 0.1 mm * Travel speed 80 mm/sec - 1x side gauge with T-slot and mm scale - 2x front support arms with T-slot and mm scale - Ball transfers in front support table - Folding finger guard with safety switch * Finger guard with sight windows for cutting to scribe - Cutting line illumination with shadow-vision - BOSCH/HOERBIGER hydraulic unit - SIEMENS electrical system - Light curtain at rear of the machine (safety device) - Free-moving foot switch - CE marking / Declaration of Conformity - Operating instructions + wiring diagram + hydraulic diagram
