Vertikalūs apdirbimo centrai su X ašies eiga 0–399 mm pirkti naudotą (36)

Sąlyga: geras (naudotas), Gamybos metai: 2009, Maho HSC 20 linear / 5 axes, Itjdpfx Aswuyd Escusn Year of manufacture: 2009, Control: Siemens 840 D Solutionline, (Lo Dmndhswlfd Ejwjhh - unclear/likely a typo or irrelevant), Travel X/Y/Z: 200/200/280 mm, 2-axis NC swivel rotary table, Ø 190 mm, Spindle speed up to 42,000 rpm, Tool holder: HSK E 32, 24-position automatic tool changer, Renishaw laser measurement, 3D touch probe Renishaw, Chip conveyor, Machine operating hours: 5800 h, Spindle operating hours: 1800 h,

Sąlyga: naudotas, TECHNICAL DATA - Number of axes: 5 MILLING SPINDLE - Tool holder: HSK E-25 - Spindle drive power: 3.9 kW - Spindle speed: 40,000 rpm LINEAR AXES - Travel path X/Y/Z axes: 240/240/240 mm - Rapid traverse speed (X/Y/Z): [mm/min] - Feed speed (X/Y/Z): 0.02 - [mm/min] SWIVEL AXIS A - Travel range: 360° - Minimum resolution: 0.001° - Max. workpiece diameter: 100 mm SWIVEL AXIS B - Travel range: -30 / +210° - Minimum resolution: 0.001° TOOL CHANGER - Tool changer type: Bras chargeur - Number of tools in magazine: 32 - Tool change time: 7 s TABLE Isdow Hugxjpfx Acuotn - Max. table load: 60 kg ELECTRICAL SUPPLY - Supply voltage: 400 V - Total power: 6.4 kW WEIGHT AND DIMENSIONS - Required space: 1,900 x 1,600 mm - Machine height: 2,200 mm - Machine weight: 1,000 kg MACHINE HOURS - Power-on hours: 24,350 h - Operating hours: 6,500 h ACCESSORIES - Control: HEIDENHAIN TNC 430 - Rotary table type: 4th-5th axis integrated - Coolant tank - Coolant unit: HYFRA - Tool measurement probe - Tool holders: 31

Sąlyga: naudotas, Vertical Machining Center CHIRON FZ08W, 2 Pallets, 12 HSK32 Tools, Spindle 15,000 rpm, HSK-32. Rotary pallet changer (2 pallets), CNC controller Fanuc 21iM, chip conveyor. The machine is located in our warehouse in Gussago BS, Italy. Mimu Werkzeugmaschinen Gussago BS, Italy Itodpolaga Ejfx Acusn The machining center is a machine tool equipped with numerical control, capable of performing multiple machining operations with a single setup on multiple surfaces of the same workpiece. Generally, it is equipped with several movement axes, an automatic tool changer, and in some cases, multiple pallets. CNC type: Fanuc 21iM 2 pallets: Yes Number of pallets: 2 Spindle speed: 15,000 rpm

Sąlyga: naujas, Gamybos metai: 2024, X ašies eiga: 280 mm, Y ašies eiga: 280 mm, Z ašies eigos atstumas: 400 mm, greitas poslinkis X ašimi: 30 m/min, greitas poslinkis Y ašis: 30 m/min, greitasis eiga Z ašyje: 20 m/min, padavimo ilgis X ašis: 280 mm, padavimo eiga Y ašimi: 280 mm, padavimo ilgis Z ašis: 400 mm, X ašies padavimo greitis: 2 m/min, Y ašies padavimo greitis: 2 m/min, padavimo greitis Z ašis: 2 m/min, nominali (akivaizdi) galia: 6 kVA, sukimo momentas: 57 Nm, valdiklių gamintojas: Siemens, valdiklio modelis: S828 D, ruošinio ilgis (maks.): 150 mm, ruošinio plotis (maks.): 80 mm, ruošinio aukštis (maks.): 180 mm, ruošinio skersmuo (maks.): 80 mm, ruošinio svoris (maks.): 3 kg, Įranga: sūkių greitis be galo kintamas, CHARAKTERISTISCHE DATEN Tisch Arbeitsfläche des Tisches: 750 x 270 mm Anzahl der T-Nuten im Tisch: 3 Breite der T-Nuten im Tisch: 14 mm Abstand der T-Nuten im Tisch: 100 mm Maximale Tischbelastung: 100 kg Maximale Verfahrwege Längsachse "X": 280 mm Querachse "Y": 280 mm Vertikalachse "Z": 400 mm Eilgang Längs "X": 30 m/min Quer "Y": 30 m/min Vertikal "Z": 20 m/min Spindel Werkzeugaufnahme: BT40 oder SK40* Iodpfxou Sklas Acuetn Werkzeugklemmkraft: 8 kN Servoachsenmotoren Längsachse "X": 3,5/6 Nm Querachse "Y": 3,5/6 Nm Vertikalachse "Z": 3,5/6 Nm Positioniergenauigkeit der linearen Achsen: +/- 0,005 mm Hauptantriebsmotor Leistung S1/S6 (Siemens): 4,3/6,4 kW Maximales Drehmoment an der Spindel S1/S6: 38/57 Nm Maximale Spindeldrehzahl: 8000 U/min Werkzeugmagazin Anzahl der Werkzeuge / Option*: 8 / 16* Maximaler Werkzeugdurchmesser: 80 mm Maximale Werkzeuglänge: 150 mm Maximales Werkzeuggewicht: 3 kg Gesamtabmessungen Länge: ca. 1360 mm Breite: ca. 2200 mm Höhe (maximaler Verfahrweg Z-Achse): ca. 2550 mm Kühlmittelbehälter-Volumen: 130 l Gewicht: ca. 1500 kg Standardzubehör: CNC-Steuerungssystem SIEMENS ✓ 3-Achsen-Interpolation ✓ Kugelgewindespindeln, geschmiert mit Festschmierstoff ✓ Wassergekühlte Werkzeugkühlanlage ✓ 8-fach Werkzeugmagazin, Schwenkarm BT40 oder SK40 ✓ Elektrisches Handrad ✓ Teleskopische Führungsabdeckungen ✓ Kabine zum Schutz des Arbeitsbereichs ✓ Beleuchtungssystem mit Lampe ✓ Grafische Unterstützung der Programmierung – vordefinierte Bearbeitungszyklen ✓ LCD-Display 8“ (S808) – 10,4” (S828) ✓ Gewindeschneiden ohne Kompensationshalter (starr) ✓ Luftdüsen am Spindelende ✓ Spindelkühlungssystem ✓ Kühlschmiermittel-Konzentrat TRIM MicroSol 515 ✓ Sicherungssystem gegen Öffnen: vordere Türen des Bearbeitungsraums / Schaltschranktüren ✓ Luftdrucksensor für niedrigen Druck ✓ Elektrische Ausrüstung für Netz 3x400V, 50Hz ✓ USB-Anschluss an der Frontplatte ✓ Standardlackierung ähnlich RAL 5000 (Maschinenbasis), RAL 7035 ✓ Maschinenstatusanzeige ✓ Bedienungs- und Programmieranleitung ✓ Sonderausstattung und Sonderanfertigungen: • Zweites 8-fach Werkzeugmagazin, Schwenkarm ISO40/BT40 • Spindelkühlung 6–9 bar • Werkzeugmesseinrichtung RENISHAW TS 27R • Werkstückmesseinheit RENISHAW OMP40 mit Zyklen • Separates Spindelkühlaggregat für die Bearbeitung von NE-Metallen und Kunststoffen • Handrad an der Stange (Pilot) • Werkzeugwagen • Präzisionsspannvorrichtung • Automatisch öffnende Türen • Zusätzliche Ethernet-Schnittstelle am Schaltschrank zum Datentransfer zwischen PC und Maschine • Siemens-Software SinuTrain

Gamybos metai: 2006, veikimo valandos: 82 068 h, Sąlyga: geras (naudotas), Funkcionalumas: visiškai funkcionalus, mašinos/transporto priemonės numeris: 258-22, Travelling column machine in steel-concrete composite construction with workpiece changer device. Low-maintenance model from the globally renowned manufacturer CHIRON. Double spindle - vertical - machining center including KNOLL chip conveyor AE 1058.009 and a composite system (already dismantled). Prescribed maintenance intervals for the system and individual components have always been adhered to. TECHNICAL DETAILS Drilling performance in steel: 60: 2 x Ø 36 mm (with indexable insert drill) Guides: with long-life grease lubrication Speed range: 20–12,000 rpm CNC control: SIEMENS 840D Spindle distance in X-axis: 250 mm X-axis: 300 mm Y-axis: 400 mm Z-axis: 425 mm (with variable tool change level) Rapid traverse speed: 60 m/min in X, Y, and Z axes Main spindle drive: 1 unit with 2 AC motors Power at 100% duty cycle: 9.5 kW Power at 15% duty cycle: 14.0 kW Drive: digital direct drives with indirect absolute position measuring system (no need for referencing) Tool stations: 212 Tool diameter: max. 65 mm Tool diameter when adjacent positions are free: max. 175 mm Tool weight: max. 2.5 kg (5.0 kg at 2 positions) Tool change time: approx. 0.9 s (control dependent) Chip-to-chip time: approx. 2.1 s (control dependent) Workpiece changer: 0 / 180° Tool holder: HSK A 63 1 MACHINE DETAILS Power supply: 3/N/PE - 50/60 Hz Operating voltage: 400 V Power: 44 kVA Rated current: 63 A Coolant unit HL 450 / 900 CHIP CONVEYOR Manufacturer: KNOLL Type: AE 1058.009 Year: 2006 Iedpomt A Ivsfx Acuetn EQUIPMENT - CHIRON maintenance manual on screen - Operating hours and piece counter - 230 V socket - Connection socket for portable mini-handwheel - Switch cabinet cooler as door-mounted unit - Signal lamp - Splash guard enclosure - Chip conveyor - Mini control panel - Rinse gun - Central pneumatic connection - Fixture rinse system - 70 bar high-pressure pump - 1 internal cooling package with extraction unit - Fully enclosed work area - Extraction unit with air cleaner - Extraction capacity 800 m³/h - CHIRON tool life monitoring with: - Automatic loading door of the splash guard enclosure - "opening" and "closing", operated via two-hand control - Integrated workpiece changer IWW 0/180° - Chiron Lasercontrol Single F500 - RJ45 Ethernet port at the switch cabinet instead of in the operator panel - Pneumatic and hydraulic connections - Central hydraulic and pneumatic connection prepared for max. 20 connections, 6 fitted including couplings; of these, 4 for hydraulics, max. 210 bar, and 2 for unregulated pneumatic. - 4 additional hydraulic connections - Hydraulic power unit - 2 hydraulic power unit extensions for additional clamping circuits

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 2018, veikimo valandos: 6 019 h, XYZ: 350 x 440 x 330 mm Drehtischdurchmesser: 320 mm Maximaler Werkstückdurchmesser: 320 mm Maximale Werkstückhöhe: 265 mm Maximale Tischbelastung: 100 kg Itsdpewfgnlsfx Acusn A-Achse: +/-115° Spindeldrehzahl: 18.000 U/min 36-facher Werkzeugwechsler Heidenhain TNC 640 Späneförderer, Hochdruckkühlung

Sąlyga: geras (naudotas), Gamybos metai: 2009, X ašies eiga: 200 mm, Y ašies eiga: 200 mm, Z ašies eigos atstumas: 280 mm, Maho HSC 20 linear / 5 axis, Year of manufacture 2009, Control system Siemens 840 D Solutionline, Travel (X/Y/Z): 200/200/280 mm, 2-axis NC tilting rotary table, Ø 190 mm, Spindle speed up to 42,000 rpm, Tool holder HSK E 32, 24-position tool changer, Itodjwpfnxepfx Acuon Renishaw tool laser measurement, 3D probe Renishaw OMP 400, Chip conveyor, Machine operating hours: 5,800 h, Spindle operating hours: 1,800 h,

Sąlyga: paruoštas naudoti (naudotas), Gamybos metai: 2013, Bendra informacija Mašinos svoris: 12 020 kg Valdymo blokas Gamintojas: MAZATROL Judesiai X ašies eiga: 203,2 mm Y ašies eiga: 70,10 mm Z ašies eiga: 71,8 mm Papildoma įranga Įrankio laikiklis: CAT#40 / Automatinis įrankių keitiklis (ATC): 48 įrankių Itodpfewfuquox Acusn Šis 3 ašių vertikalus apdirbimo centras Mazak VCN 700E/40-II pagamintas 2013 metais. Puikiai tinka precizinei inžinerijai, pasižymi tvirta konstrukcija ir patikimu veikimu. Pasinaudokite proga įsigyti šį Mazak VCN 700E/40-II vertikalų apdirbimo centrą. Susisiekite su mumis dėl detalesnės informacijos. Pritaikymo sritys Frezavimas

Sąlyga: naudotas, Vertical machining center CHIRON FZ08KW 2 pallets Iodpfx Asumma Iscuetn 15,000 RPM HSK40A CNC Fanuc 21iM The machine is located in our warehouse in Gussago, BS. Mimu Machine Tools Gussago, BS, Italy. The machining center is a machine tool equipped with numerical control, capable of performing multiple machining operations in a single setup on several surfaces of the same workpiece. It is generally equipped with multiple axes of movement, an automatic tool changer system, and sometimes multiple pallets.

Sąlyga: geras (naudotas), Gamybos metai: 2012, Primacon PFM 24 NGD / 5 axes, year of manufacture 2012, Heidenhain iTNC 530 control, travels X/Y/Z 240/240/240 mm, 40-position tool magazine, HSK F 32 / 25 E interface, Fischer Precise spindle up to 50,000 rpm, 4th and 5th axes with Howimat rotary table, length measuring probe, Renishaw 3D probe, Z axis overhauled in 2023. Iodpfxov Tb Hte Acuotn

Sąlyga: geras (naudotas), Gamybos metai: 2007, Primacon PFM 24 NGD / 4 axes, Year of manufacture: 2007, Control: Heidenhain iTNC 530, Travel (X/Y/Z): 240/240/240 mm, Fischer Precise spindle up to 50,000 rpm, Itedpfx Ajv Tb Eiocuen Tool holder: HSK F 32 / 25 E, 4th axis: Hirschmann, Length measuring probe, 32-position tool magazine,
