Tiesinimo staklės 650 x 15 mm

Schubert WMP 63/600

Manufacturer: SCHUBERT
Model: WMP 63/600
Year of manufacture: 1974

Total rolls: 23
Upper rolls: 11 units
Lower rolls: 12 units
Variable speeds: 5 - 15 m/min
Max. surface torque at 40 kg/mm²: 3500/1800
Minimum workpiece length: 130 mm
Max. vertical roll spacing: 16 mm
Chedpswpkxcefx Ahvjc
Central lubrication
Length of infeed table: 400 mm

Specifications
Metric | US Standard
Roll width: 650 mm
Sheet thickness at 5 x upper roll Ø: 15 mm
Upper roll Ø: 63 mm
Lower roll Ø: 63 mm
Number of rolls: 23
Bending speed: 3 - 15
Number of driven rolls: 23

Dimensions (approximate)
Length: 2,400 mm
Width: 2,300 mm
Height: 1,900 mm
Weight: 6,000 kg
