Profilinės plieno žirklės

Peddinghaus Profilstahlschere Typ 210 / 11

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 1996, eigos ilgis: 160 mm, spaudimo jėga: 120 t, Hydraulic Press Brake Manufacturer: DURMA Model: HAP 30120 Isdpfsu Iarbex Af Ioal Year: 1996 Technical Details Manufacturer: DURMA Model: HAP 30120 Year of manufacture: 1996 Pressing force: 120 t Working length: 3050 mm Stroke: 160 mm Motor power: 11 kW Dimensions: L 4,150 x W 1,950 x H 2,600 mm Weight: 7.5 t Equipment • CNC-controlled backgauge • Insertion depth adjustable via controller • Controlled axes: X, Y • 2 support arms • Technical documentation • Tooling: o Multi-V die V12, V20 (slightly damaged), V13, V16, V45, V15, V10, V65 Length 3,050 mm o Upper tool, slightly goosenecked, H 150 mm, L 2,970 mm, segmented All information is supplied without guarantee. A demonstration is possible at any time in our showroom.

Gamybos metai: 1982, Sąlyga: geras (naudotas), mašinos/transporto priemonės numeris: 82-540, Offer 18474 Technical Specifications: - Flat bar shear cuts flat bars up to 100 x 18 mm - Blade length approx. 250 mm - Profile steel shear cuts angles - 90° up to 100 x 10 mm - 45° up to 70 x 8 mm - Bar shear cuts: - Round steel: 90° up to 36 mm Iedpfxeg Eubns Af Ieal - Square steel: 90° up to 30 mm - Notching unit for sheets up to 8 mm - Punching unit: - Punching force approx. 50 t - Throat depth 350 mm - Punches steel up to 20 mm Ø in 15 mm - Drive: 400 V / 3 kW - Space requirement approx. W 1100 x H 1700 x D 2300 mm - Weight approx. 1,900 kg

Sąlyga: geras (naudotas), Funkcionalumas: visiškai funkcionalus, darbinis plotis: 3 100 mm, atstumas tarp stulpų: 2 550 mm, galinis atmušas: 1 500 mm, spaudimo jėga: 110 t, Press capacity: 110 tons Bending length: 3,100 mm Frame width: 2,550 mm Back gauge: 1,500 mm Stroke length: 150 mm Iajdpfx Afswi N T Ej Iel Throat depth: 250 mm Approach speed: 100 mm/sec Working speed: 8 mm/sec Return speed: 65 mm/sec Control system: ESA Kvara S630 Touch Equipped with: - Foot pedal - Various tool sets - Merlino light curtain safety system - Controls renewed in 2018 Country of origin: Netherlands Motor power: 7.5 kW Machine dimensions (LxWxH): 320 x 160 x 244 cm Machine weight: 8,700 kg

Sąlyga: paruoštas naudoti (naudotas), Gamybos metai: 1996, Funkcionalumas: ribota funkcionalumas, mašinos/transporto priemonės numeris: 6510114174, bendras svoris: 2 200 kg, Automatinis režimas neveikia. Be ritininių konvejerių. Iaedjwi Nhcepfx Af Iol

Sąlyga: naudotas, Funkcionalumas: visiškai funkcionalus, Gamybos metai: 2007, veikimo valandos: 22 372 h, lazero valandos: 11 345 h, lazerio galia: 4 000 W, plieno lakšto storis (maks.): 20 mm, aliuminio lakšto storis (maks.): 8 mm, bendras svoris: 16 000 kg, bendras ilgis: 11 600 mm, bendras plotis: 5 200 mm, bendras aukštis: 2 200 mm, darbo diapazonas: 40 002 000 mm, Įranga: aušinimo blokas, Standard equipment: • Enclosed machine frame with integrated laser unit • Laser unit: CO₂ laser TruFlow 2000, high-frequency excited, maintenance-free turbo radial blower, mirror telescope, cooling unit, logbook function • Automatic pallet changer • Longitudinal conveyor belt for small parts/waste • Drive: Maintenance-free three-phase servo motors • Quick-change cutting head system Laser cutting head with 5" lens and laser cutting head with 7.5" lens • Programmable cutting gas pressure control • ControlLine capacitive height regulation and process control • Automatic focus adjustment FocusLinePlus • Laser power control • Positioning laser • NitroLine high-pressure cutting • High-speed processing with SprintLine • Automatic production of small holes • PlasmaLine plasma sensor technology • Automatic sheet metal and edge detection • Programmable power cycles • Microweld • Spray device for safe thick sheet processing • Automatic air blow-off device • Residual heat extraction • Control Sinumerik 840D: Open PC-based control, simple operation, online help, integrated e-shop, diagnostic functions, maintenance logbook, technology data, teleservice • Workshop programming with TruTops Laser lite Safety: • Multibeam light barriers, fully encapsulated and ventilated beam guidance, monitoring system, multi-chamber extraction and compact dust collector, safety cabin • Network connection RJ45 via teleservice installation • 3.5" floppy disk drive • TFT color display Iajdev Sm Ruspfx Af Isl Higher-performance lasers: • TruFlow 4000, incl. NitroLine Plus, beam path ventilation with nitrogen and lens monitoring sensors Extended machine equipment: • PierceLine Process Control System • Total of 2 auxiliary machine pallets, steel slats • Crane-liftable traverse for manual pallet handling • Compressed air cutting

Sąlyga: geras (naudotas), Gamybos metai: 1989, mašinos/transporto priemonės numeris: 51756, Offer 25200 Technical Data: - Pressing force: 200 t - Working width: 3,100 mm - Distance between uprights: 2,600 mm - Table width: 180 mm - Throat depth: 300 mm - Installation height: 450 mm - Approach speed: 80 mm/sec - Working speed: 9 mm/sec - Return speed: 60 mm/sec - Ram stroke: 120 mm - Adjustable range of fixed stops: 120 mm Iaedpfxjwvipgo Af Iel - Drive: 400 V / 18.7 kW - Space requirement approx.: W 3,300 x H 2,950 x D 1,900 mm - Weight approx.: 10,500 kg Including: - Adjustment of pressing depth and pressing force - Motorized backgauge with fine adjustment handwheel - 4-way universal die – pointed tool - Two-hand control panel, foot pedal

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 1999, Techniniai duomenys: Darbo ilgis: 3050 mm Atstumas tarp kolonų: 2690 mm Presavimo jėga: 130 t CNC valdymas: DELEM Reguliuojama galinė atrama Valdomos ašys: Z1 / Z2; X; R CNC valdomas bombiravimas Įrengimo aukštis: 535 mm Eigos ilgis: 365 mm Iškyša: 410 mm Hidraulinis įrankių tvirtinimas viršuje ir apačioje Kumštelinio kelio matavimo sistema su spyruokline kompensacija naudojant stiklo matavimo liniuotes Programuojamas apatinio įrankio poslinkis (I ašis) – dviem pozicijoms Variklio galia: 12,5 kW Atramos pirštų skaičius: 2 CE ženklinimas Matmenys (ilgis x plotis x aukštis): apie 3800 x 2350 x 3150 mm Svoris: apie 14 t Būklė: Isdpfx Asw Tcncef Ioal Gera būklė Pardavėjas neatsako už rašybos ar duomenų perdavimo klaidas. Mašina atitinka savo amžių išvaizdos, techninių parametrų ir nusidėvėjimo atžvilgiu; naudotos mašinos parduodamos be jokios garantijos.

Sąlyga: geras (naudotas), mašinos/transporto priemonės numeris: 98260075, a used WMW profile steel shear Isdob Ilbfjpfx Af Ieal Punching force: 420 kN (42 tons) Punch throat depth: 320 mm Flat bar shear cuts 100 x 18 mm Bar shear cuts solid round/square material: 36/30 mm Further technical data on request.

Sąlyga: geras (naudotas), Gamybos metai: 1988, Accessories: Yes Punching force: 800 kN Frequency: 50 Hz Current: 17/11 A Voltage: 220/380 V Round bar: 32-17 mm Square bar: 30-18 mm Angle iron: 100 x 10 mm Flat bar: 350 x 16 mm Throat depth: 200 mm Working height: 1107 mm Total power requirement: 4 kW Machine weight approx. 1.5 t Iasderyaqyjpfx Af Isl Space requirement approx. 1200 x 700 x 1850 mm

Sąlyga: geras (naudotas), Presskracht 110 ton Buiglengte 3100 mm Bouwjaar 1990 + retrofit Ijdpfx Asw Hx Rzjf Ieal Staanderbreedte 2600 mm Aangestuurde assen: Y1, Y2, X-as Besturingssysteem: ESA S630 Inclusief Wila kleminzet/spondeer (dichtdrukstempel)
