Profilis lenkimo mašina

OSTAS OPK 65

Sąlyga: naujas, Ostas Profile Ring Bending Machine OPK 65 Bledefig Aiepfx Aahod Technical Specifications: • Tool holder, shaft: 60 mm • Tool: 175 mm • Working speed: 5 m/min • Motor: 3 kW • Dimensions (LxWxH): 900 x 1250 x 1200 mm • Weight: 1080 kg • 3 driven rollers • Hardened standard rolls • Hardened and ground tool holder, shaft • Mobile control panel • Horizontal and vertical operating position • Side guide rolls • Digital displays (2 pcs.) • Brake motor • In accordance with CE standards

Sąlyga: labai geros būklės (naudotas), Stehle S820 (automatische Gerade-Messer-Schleifmaschine). Bitte überprüfen Sie Ihren Spam-/Junk-Mail-Ordner, falls Sie innerhalb von 24 Stunden nach Absenden Ihrer Anfrage keine Antwort erhalten! Bedpsq Dzkujfx Aahold Technische Daten: • Maximale Werkzeugbreite: 330 mm • Werkzeugdurchmesser für Hobelköpfe (Mindest-/Maximalgröße Messerträger): 120 – 230 mm • Schleifscheibendrehzahl: 2.850 / 5.750 U/min • Schleifen von 2 bis 12 Messern pro Kopf mittels Teilapparat möglich • Teilapparate für das Schleifen von 4, 6, 8, 10 und 12 Messern im Lieferumfang • Antriebsleistung Schleifscheibenmotor: 1,3 kW • Freiwinkel: 10 – 35° • Kühlmitteltank: 125 Liter • Motor der Kühlmittelpumpe: 0,28 kW • Anschlusswert gesamt: 2 kW Bitte überprüfen Sie Ihren Spam-/Junk-Mail-Ordner, falls Sie innerhalb von 24 Stunden nach Absenden Ihrer Anfrage keine Antwort erhalten!

Sąlyga: naujas, - Section bending machine - Shaft diameter 60 mm - Both lower rolls are hydraulically actuated - Three driven rolls Bjdpogg N Amsfx Aahjld - 2 digital displays - Brake motor - Can be operated horizontally or vertically - Mobile control panel - Emergency stop - Documentation - 400V

Sąlyga: labai geros būklės (naudotas), Funkcionalumas: visiškai funkcionalus, Gamybos metai: 2022, veikimo valandos: 11 500 h, mašinos/transporto priemonės numeris: 3098, lazero valandos: 6 900 h, lazerio galia: 10 000 W, maks. lakšto storis: 30 mm, plieno lakšto storis (maks.): 30 mm, galia: 10 kW (13,60 AG), paskutinio kapitalinio remonto metai: 2024, darbo diapazonas: 4 020 mm, Įranga: apsaugos šviesos užtvara, aušinimo blokas, dokumentacija / vadovas, MSF Pro 4001.20LB MicroStep CNC cutting system from the MSF Pro series featuring the following specifications: • 2D laser cutting head with an IPG YLS 10000 U fiber laser source • Fully automatic shuttle table • Fully automatic HSK 63 drilling spindle • High-performance Donaldson DFPRO 6 filter system with 7.5 kW Bljdpjvw Tdljfx Aahsd Technical Data: Model: MSF Pro 4001.20LB Working area: approx. 4,000 x 2,000 mm Guides: high-precision linear guides Drives: maintenance-free Panasonic AC servo motors Traverse speed: up to 100,000 mm/min Measuring system: IRC 2500 (incremental encoder) Z-axis positioning speed: 18 m/min Z-axis travel range: 150 mm Z-axis acceleration: 0.75 G Positioning accuracy (Pa*): 0.07 mm according to VDI/DGQ 3441 Repeatability (Ps*): 0.03 mm according to VDI/DGQ 3441 Ambient temperature: +10 °C to +35 °C Relative humidity: 0 to 90 % Laser cutting head: EX-TRABEAM® Pro Cleaning and calibration station (LU3K) Automatic nozzle changer (8 nozzles) Fully automatic drilling spindle Technical Data (Drilling Unit): Drilling capacity: Ø 4 mm - Ø 30 mm Thread cutting: M5 - M20 Max. material thickness: up to 25 mm* Power: 21 kW Speed: up to 10,000 rpm Tool cooling: internal cooling Tool change: automatic Automatic measurement of drilling tools Pneumatic hold-down device Brush for removing drilling chips Donaldson® Filter System DFPRO 6 Cyclopeel Fan output: 7.5 kW Airflow: 4,500 m³/h Asper Nesting® | Automatic nesting software Includes Witt gas mixer The machine was always operated with a maintenance and support contract.

Sąlyga: naujas, Funkcionalumas: visiškai funkcionalus, Comparable to Durma, Baykal, Ermaksan, etc. Bending length 3020 mm Press force 220 t Approach speed 140 mm/s Bending speed max. 10 mm/s Return speed 130 mm/s Stroke 350 mm Installation height 600 mm Throat depth 450 mm X-axis travel 750 mm X-axis speed 300 mm/sec R-axis travel 250 mm R-axis speed 100 mm/sec Clear distance between frames 2555 mm Machine length 3730 mm Machine width 2290 mm Overall height 3055 mm Table height 820 mm Motor power 22 kW Oil tank capacity 300 l Machine weight 11500 kg (Technical data may vary depending on equipment) Standard equipment: • 3 CNC axes (Y1, Y2, X) • Double-guided press beam, stable and precise • Robust double-guided backgauge • Manually adjustable backgauge fingers, double-guided on linear guide • Movable front arms with height adjustment • Lateral and rear safety covers • Lower die adapter rail 60 mm • Manual upper tool clamping system (Promecam system) • Manual crowning • Foot switch with emergency stop • 380 V, 50-60 Hz, 3 phase • LED lighting Blsdpfx Ajq D Dzljahjd Including the following options: • Delem control DA 66T • Fiessler AKAS 2M laser finger guard • FPSC Safety PLC (manual) • X-R axis with servomotors • CNC crowning for high bending precision • 2 additional backgauge fingers - Other bending lengths and thicknesses are available upon request with the appropriate accessories! -

Gamybos metai: 2022, Sąlyga: naujas, Aluminium angle conveyor belt with substructure Conveyor belt length: 1000 mm horizontal + 2400 mm inclined Incline angle at the bend: 45° Discharge height: approx. 2000 mm Height of the horizontal section: 300 mm (top edge) PPU conveyor belt FDA food-compliant Conveyor belt type: EM 15/2 0+17 PU blue 7 white Belt width: 400 mm T20 cleats welded on – spacing 202 mm * Antistatic due to threads in the running side fabric Endless welded with staggered finger splice 30 mm high side wave edges, high-frequency welded on both sides * Edge-free zone on both sides for belt guidance in the inclined section Lateral arrangement: -70/+35/-5/+190/-5/+30/-70 mm Continuous support plate Drive: Motor approx. 0.25 kW Belt speed: approx. 0.3 m/sec Connection: 220/400 V, 50 Hz, protection class IP54 Our core competency is to deliver exactly what the customer really needs. We work closely with our customers to develop customized, individual solutions and deliver corresponding systems from our own production. Please feel free to contact us by phone to find a suitable solution for your application. Conveyor belt, conveyor system, discharge belts, belt conveyor, magnetic separator, overband magnetic separator, recycling, wood chips, plastic, metal-free metal detection, neodymium, overband magnet, magnetic belt separator, lifting magnets, filter rods, magnetic grids, grate magnets, metal separator, block magnet, filtration systems. Bljdpfx Aoht U Tdeahod

Sąlyga: naujas, Capaciteit, mm ----- 25 x 2 mm Radius, min/max ----- 10/100 mm Radiusverschil ----- 90 mm Buigsnelheid/herhaalbaarheid ----- 500º/s. ±0,05° Buislengte ----- 1.350 ∞ mm Gewicht ----- 2.200 kg Machineafmetingen ----- 3,0 x 1,2 x 1,3 m Buisrotatie ----- 0–850°/sec Lengteaanvoer ----- Standaard 0–2.400 mm/sec Booster ----- 0–1.200 mm/sec Tolerantiegraad ----- 0,05°/mm Draaibeweging van de buigkop ----- 0,75 sec Standaard componenten voldoen aan VDMA-, ISO- en DIN-normen. OPTIES * Online koppeling met CAD-systeem en meetmachine * Automatisch buismagazijn met vrij programmeerbare robot of laadarm * Lasnaaddetector en buispositioneerder via elektromagnetische of optische detectie * Vrije radiusbuiging * Simulatie/Collision Control * Verlenging van het bed Bljdpfx Aoga T Exoahed

Gamybos metai: 2025, Sąlyga: naujas, Manual Length Stop MD 50 h – Precise Measuring & Positioning with Handwheel and Digital Display Blodpfxeidln Tj Aahjd The manual length stop MD 50 h with handwheel drive and digital measurement display is the ideal solution for frequently changing cut lengths and for precise positioning of long materials. Thanks to rapid adjustment via the handwheel and precise digital travel measurement, you can increase the efficiency and quality of your production. Technical Specifications & Advantages: ✔ Handwheel drive for the carriage – precise & quick adjustment ✔ Digital actual-value length display – exact positioning throughout the entire working range ✔ Direct travel measurement via sensor/magnetic tape – maximum precision ✔ Pneumatic stop clamping with high holding force – secure position fixation ✔ Carriage with 8 ball bearings – stable & durable ✔ Measuring lengths from 1 m to 6 m (optionally up to 20 m) – individually customizable ✔ Cable chain with steel channel – robust design for industrial applications ✔ Available in left- or right-hand versions – flexible for various machine layouts Retrofittable for existing machines & roller conveyors! Enquire now & secure your offer!

Sąlyga: geras (naudotas), Gamybos metai: 2002, Manufacturer: BRÜCK Model: 12/1600 Load capacity: 12,000 kg Maximum sheet width: 1,600 mm Coil diameter: 1,800 mm Weight: approx. 14 t Bjdpfx Ajhrnbkoaheld Without control cabinet.

Sąlyga: naujas, veleno skersmuo: 80 mm, - Ring bending machine - Shaft diameter 80 mm - The two lower rolls are hydraulically adjustable - Three driven rolls - 2 digital displays - Brake motor Bledpfx Aaeucqquehed - Usable in horizontal or vertical position - Mobile control panel - Emergency stop - Documentation - 400V
