Plokštės Automobilių Pasukamas pirkti naudotą (7 551)

Sąlyga: naudotas, Technical details: Plate length: 5500 mm Plate width: 2150 mm Plate height: 340 mm Plate thickness: 340 mm Itedpjval Nfefx Af Ieb Machine weight approx.: 9.0 t Transport dimensions (LxWxH): approx. 5.5 x 2.2 x 0.35 m Material: Cast steel Milled, fine-machined surface T-slots according to DIN 650: a = 28 mm; h = 46 mm; b = 48 mm; c = 21 mm Slot spacing: 150 / 230 mm

Sąlyga: naudotas, Technical specifications: Itodpfx Aeu Nkpysf Ijb Plate length: 660 mm Plate width: 450 mm Plate height: 70 mm Through-hole in table: Ø 115 mm Machine weight approx.: 111 kg Required space approx.: 660x450x70 mm Through-hole 115 mm T-slots: according to DIN 650 and 508 - a = 22 mm - b = 38 mm - h = 40 mm - c = 17 mm

Sąlyga: naudotas, Technical details: Isdpfx Aju R A A Uof Istb Plate length: 640 mm Plate width: 330 mm Plate thickness: 65 mm T-slots according to DIN 650 for T-slot nuts according to DIN 508 a = 13.9 mm; b = 24.2 mm; c = 9.8 mm; h = 19.9 mm

Sąlyga: naudotas, Technical details: Plate length: 800 mm Plate width: 455 mm Itsdpju N Dhiofx Af Iob Plate height: 75 mm Machine weight approx.: 264 kg Transport dimensions (LxWxH): 800 x 455 x 250 mm Ram plate removed from a PYE 160S press - With central through-hole Ø 40mm - With 6x pitch circle holes Ø 16mm, pitch circle Ø 160mm - Diagonal T-slot according to DIN 650 (a = 19mm; h = 25mm; b = 38mm; c = 16mm) - Support plate on the underside = spacing approx. 410mm

Sąlyga: naudotas, Technical details: Plate length: 1100 mm Itjdpfx Asu N Dyrof Ieb Plate width: 700 mm Plate height: 85 mm Machine weight approx.: 430 kg Clamping plate, cast steel, with T-slot according to DIN 650 a=25; h=41; b=48; c=24 mm; pitch 76 mm

Sąlyga: naudotas, Technical details: Plate length: 2000 mm Plate width: 1500 mm Plate height: 820 mm Plate thickness: 185 mm Machine weight approx.: approx. 2.1 / 2.2 t per plate Transport dimensions LxWxH: approx. 2.0 x 1.5 m / per plate Itedou N D Rdspfx Af Ieb A total of 6 clamping plates are available for sale. (Price per piece) Material: cast steel / profile cast iron T-slots according to DIN 650: a = 43 mm; h = 105 mm; b = 76 mm; c = 50 mm; pitch 375 mm 4x through holes Ø 90 mm 10x mounting holes Ø 25 mm with countersink Ø 85 x 135 mm with base frame for plate no. 1, 3, 4, 5, and 6: L: 1990 mm x W: 1490 mm x H: 185 mm with base frame for plate no. 2: L: 2020 mm x W: 1515 mm x H: 520 mm

Sąlyga: naudotas, Technical details: Faceplate diameter: 800 mm Isdsu N E Anjpfx Af Istb Width: 140 mm Weight: 330 + 50 kg This faceplate is supplied without clamping claws. Clamping is carried out using the matching clamping plate Ø 790 x 26 mm. The clamping slots, each with a length of 300 mm, are radially arranged. T-slots according to DIN 650: a = 22 mm; h = 37 mm; b = 40 mm; c = 17 mm Flange mounting: Mounting surface outer Ø 410 mm and inner Ø 195 mm 6x clamping bolts on bolt circle Ø 235 mm Clamping plate: 4x through holes Ø 20.5 mm on bolt circle Ø 630 mm Various clamping holes M20 / M16 and M12 arranged in distribution Equipment: 4 pieces clamping screws M20 with clamping irons

Sąlyga: naudotas, Technical details: Itodswm Ngtopfx Af Ijb Plate length: 2500 mm Plate width: 1250 mm Plate height: 100 mm Transport dimensions (LxWxH): 2.53 x 1.25 x 0.10 m Cast steel The plates are machined in the area in front of the T-slots, with recesses of 75mm x 60mm Table surface: 2530 mm x 1245 mm Longitudinal T-slots: number: 5 Size: a = 32 mm, h = 53 mm, b = 54 mm, c = 23 mm Center distance: 250 mm 2 slots chamfered 8 through-holes with D = 17 mm

Sąlyga: naudotas, Technical Details: Lapping plate diameter: Ø 1000 mm Coating thickness: approx. 8.0 mm Plate thickness: approx. 75 mm Inner diameter: 400 mm Machine weight approx.: 0.37 t Dimensions: 1,200 x 1,200 x 300 mm Bore diameter: Ø 290 mm Flange mounting: Ø 320 mm This working plate is suitable, for example, for use on disc grinding, fine grinding, and/or lapping machines. Itedeu Uzzujpfx Af Iob Application: Material removal for gentle processing of the workpiece surface, as well as maintaining the flatness of the tools. The pattern/structure (honeycomb) improves material removal by providing additional cutting edges. This achieves a superior surface finish and flatness. Diamond and CBN lapping plate/lapping disk. The central bore Ø 290 mm features a countersink with a bore of Ø 400 mm x 47 mm depth. Packaged in a wooden crate: 1150 x 1150 x 166 mm.

Sąlyga: naudotas, Technical details: Iedpfxjval Emo Af Iotb Plate length: 2600 mm Plate width: 380 mm Plate height: 115 mm Plate thickness: 115 mm Machine weight approx.: approx. 0.4 t / per plate Transport dimensions LxWxH: approx. 2.6 x 0.38 x 0.2 m / per plate A total of 3 plates are available for sale (price per plate). These plates can be assembled into a single plate table. Material: Steel, milled surface Longitudinal slot quantity: 2 (a=36 mm, h=48 mm, b=60 mm, c=24 mm) Center distance: 160 mm Base fastening, quantity: 4, size D=32 mm x 45 mm, countersunk D70x65 mm Drilling on front face, quantity: 1/front, M20, centrally located

Sąlyga: naudotas, Technical details: Plate length: 4900 mm Plate width: 1460 mm Plate height: 300 mm Plate thickness: 300 mm Machine weight approx.: 5.3 t / per plate Transport dimensions LxWxH: approx. 4.9 x 1.5 x 0.3 m / per plate Two plate units are available for sale. Material: cast steel T-slots according to DIN 650: a=58; h=108; b=110; c=50 mm Itedpfeval Hqsx Af Isb Center distance: 295 mm 6 through-holes Ø 40 mm On one plate, 2 slot areas are broken out at the front end.

Sąlyga: naudotas, Technical Details: Spindle diameter: 130 mm Drilling depth: 1,380 mm X-travel: 2,500 mm Y-travel: 1,600 mm Z-travel: 380 mm W-axis: 900 mm spindle feed U-axis: 320 mm facing slide feed Control system: on request Tool holder: ISO SK50 Speed – facing slide: 4.5–180 rpm Drive spindle speed: 4.5–900 rpm Feed – x/y: 5–2,000 Total power requirement: approx. 40 kW Machine weight approx.: < 35 t plus auxiliary equipment The machine can be offered in four different sales options. Please choose! 1. The machine is in as-new mechanical condition, as it stands. 2. The machine as it stands, including plate table 4,000 x 2,000 x 300 mm = Stock No. 1101081 3. The machine rewired, with new control cabinet, digital readout, 4-axis, Siemens AC drives, Siemens axis motors (50A/31Nm) with 12 month warranty on all new parts. Iodpfxovr S Uls Af Ietb 4. Additional accessories can also be optionally offered, e.g. coolant system, chip conveyor, enclosure, etc. Please contact us to discuss these options.

Sąlyga: naudotas, Technical details: Plate length: 3000 mm Plate width: 1775 mm Plate height: 350 mm Itjdpfsu N Dglsx Af Ijb Material of the plate: Cast steel. 7 T-slots according to DIN 650 a=35 mm; h=60 mm; b=62 mm; c=26 mm; Center distance: 250 mm The clamping plate is equipped with side mountings on the longitudinal side and front side.

Sąlyga: naudotas, Gamybos metai: 1999, Technical details: Plate length: 5,500 mm Plate width: 1,500 mm Plate height: 250 mm Itjdpfou N Dnvjx Af Ieb Machine weight approx.: 6.5 t Space requirement approx.: 5.5 x 1.5 m - Slot distance (T-slots) = 542 / 500 mm with parallel offset arrangement - T-slot according to DIN 650 - a = 28.0 mm; h = 48.0 mm; b = 48.0 mm; c = 22.0 mm - Including adjustment screws and cover caps In stock.

Sąlyga: naudotas, Gamybos metai: 1979, Technical details: Plate length: 6,400 mm Plate width: 1,870 mm Plate height: 415 mm Machine weight approx.: 8,600 kg Transport dimensions (LxWxH): 6.4 x 1.9 x 0.42 m Cast steel plate - T-slot according to DIN 650 - a = 36 mm; h = 69 mm; b = 59 mm; c = 25 mm; slot spacing 315 mm Itodpfx Afju N Dqdo Ieb - Incl. cover plates Ø 147 x 3 mm

Sąlyga: naudotas, Technical Data: Faceplate diameter: 900 mm Width: 120 mm Max. through-hole: Ø 140 mm Weight: 330 kg Equipment: - 4x clamping jaws Flange fitting: Itsdpfxeu N E A Uj Af Ieb - Ø inner: 410 mm through x depth: 50 mm - 12x clamping holes Ø 26 mm, bolt circle Ø 460 mm T-slots according to DIN 650: a = 22 mm, h = 43 mm, b = 40 mm, c = 18.5 mm

Sąlyga: naudotas, Technical details: Faceplate diameter: 1000 mm Width: 150 mm Bore diameter: Ø 130 mm Max. through-hole: Ø 130 mm Weight: 475 kg Dimensions: Ø 1000 x 255 mm Equipment: - 4x external/internal jaws; clamping travel approx. 200 mm; max. clamping range approx. Ø 900 mm / min. approx. Ø 100 mm - T-slot size according to DIN 650: a = 22 mm; h = 43 mm; b = 40 mm; c = 16 mm x length = 285 mm Flange mount: Iodpfx Aeu N E E Nof Iotb Inside Ø: 195 mm, depth 21 mm 4x clamping holes Ø 20 mm, countersink Ø 30 x 31 mm, pitch circle Ø 235 mm Good used condition

Sąlyga: naudotas, Gamybos metai: 1992, Technical Details: Sheet width: 1550 mm Sheet thickness: 2.5 mm Frame clearance: 1630 mm Blade length: 1550 mm Stroke adjustment, upper beam: 90 mm manual / 70 mm hydraulic Stroke adjustment, lower beam/bending beam: 105 mm manual Stroke adjustment, bending beam: 40 mm Max. bending angle: 93° (L-/Z-bending) and 180° for folding Back gauge: no Total power requirement: 4.5 kW Machine weight approx.: 1.8 t Machine dimensions approx. (LxWxH): 2.6 x 1.1 x 1.7 m Itsdpfx Afeu Ib Ans Iob Hydraulic unit dimensions: 1400 x 700 x 1480 mm Bending capacity: 2.5 mm at approx. 400 N/mm² tensile strength Hydraulics: OILTECH with approx. 200 liters

Sąlyga: naudotas, Technical details: Table length: 1100 mm Table width: 800 mm Table height: 100 mm Number of T-slots: 3 T-slot spacing: 300 mm Machine weight approx.: 650 kg T-slots according to DIN 650 and 508 - Width a: 30 mm - Width b: 50 mm - Height c: 30 mm - Height h: 50 mm Isdpfx Aju Nklusf Ijtb

Sąlyga: naudotas, Technical Details: Face plate diameter: 350 mm Width: 80 mm Bore diameter: 50 mm Machine weight approx.: 32.0 kg Dimensions: 350x125 mm - Face plate with 4 internal/external clamping jaws (clamping range 80 mm) Iedpfxju Nk T Se Af Ietb - Clamping range internal: Ø 110-350 mm; external: Ø 40-300 mm - Flange mounting: Ø 130 mm - Material: steel

Sąlyga: naudotas, Technical details: Sheet thickness: 1 mm Frame opening: 2,255 mm Maximum bending angle: 130° Total power requirement: 2.25 kW Approx. machine weight: 1,400 kg Machine dimensions (LxWxH): approx. 2.7 x 1.15 x 1.3 m Machine without foot switch; however, it is pre-wired for one. The previous owner converted the upper beam adjustment to 60 mm; greater adjustment is only possible by reverting the modification. The foot control for automatic operation is missing. Iodowq I U Rspfx Af Ietb Manual operation is functional. No back gauge.

Sąlyga: naudotas, Technical Details: Itjdpfxeval H Rj Af Isb Plate length: 2990 mm Plate width: 1990 mm Plate height: 190 mm Plate thickness: 190 mm Machine weight approx.: approx. 7.0 t per plate Transport dimensions (LxWxH): approx. 3.0 x 2.0 x 0.2 m per plate 2 plates available for sale. Material: Cast steel Surface: machined/finish milled T-slots according to DIN 650: 8 x large T-slots: a = 36 mm; h = 70 mm; b = 55 mm; c = 25.5 mm 7 x small T-slots: a = 28 mm; h = 38 mm; b = 47 mm; c = 21 mm Center distance: 123 mm 9 x through holes Ø 80 mm 6 x through holes Ø 33 mm

Sąlyga: naudotas, Gamybos metai: 1988, Technical details: Sheet width: 2050 mm Sheet thickness: 2 mm Frame width: 2400 mm Blade length: 2050 mm Stroke adjustment (upper beam): 250 mm Stroke adjustment (lower beam): 100 mm Maximum bending angle: 180° Rear gauge – adjustable: with guide rails, mm Working pressure: 5.0 MPa Total power requirement: 2.2 kVA Machine weight approx.: 2.3 t Machine dimensions (LxWxH): 3.5 x 1.0 x 2.2 m Hydraulic unit dimensions: 0.75 x 0.55 x 0.80 m HYDRAULIC SWING BEAM FOLDER Itsdpsu Ib Dfofx Af Iob Operation via control panel with console and foot switch Bending angle: sharp bend up to 135° with 2 mm sheet Upper beam stroke: 250 mm Lower beam stroke: 100 mm Bending beam stroke: 100 mm Bending clearance: 7 mm with scale indicator

Sąlyga: naudotas, Technical Details: Plate length: 3,880 mm Plate width: 1,390 mm Plate height: 300 mm Number of T-slots: 4 units Machine weight approx.: 3.2 t Space requirements approx.: L: 3.7 x W: 1.4 x H: 0.3 m Dimensions (L x W x H): 3.7 x 1.4 x 0.3 m Base plate from a former radial drilling machine T-slot size according to DIN 650 a = 28 mm b = 50 mm Iodpfxsu Nkl Is Af Ietb c = 24 mm h = 52 mm T-slot spacing = 250 mm

Sąlyga: naudotas, Technical details: Table length: 870 mm Table height: 420 mm Table width: 680 mm Machine weight approx.: on request t Dimensions (L x W x H): 0.91 x 0.71 x 0.42 m with base frame Isdpfeu N Dgxex Af Ijtb -Center bore Ø 180 mm T-slots according to DIN 650: a=22 mm; h=38 mm; b=40 mm; c=16 mm with base frame, but also available without base frame on request
