Būklė: naudotas, Transistor pulse inverter for three-phase feed drives with analog control, servo amplifier SIEMENS Type Simodrive 610 6SC6101-3A-Z Serial No.: A 822M103 Z = A30+A20+A18 Year of manufacture: 1989 The Simodrive 610 transistor pulse inverters are designed for powering three-phase servomotors 1FT5/1FS5. The dynamic characteristics of these motors are intended to be fully utilized. By appropriately equipping the power section, the pulse inverters can be used for a wide range of applications. This flexibility can be further increased with expansion modules for the power section. Connection voltage: 3 AC 50/60 Hz 165 Volts or DC 220 Volts (Suitable transformer: 380/165 Volt 5kVA – not included in delivery) Output voltage: 3 DC 200 Volts Efficiency: approx. 95% Number of feed axes: 4 Speed reference value: ±10 Volts Auxiliary voltage: 24 Volts Relay contact for status/fault indication Dimensions (W x H x D): 339 x 440 x 300 mm Weight: approx. 25 kg The servo amplifier is still operational in a Gildemeister GDM42. For further Gildemeister components, please refer to stock numbers: Gedpfxoh D Syvs Acyjip 60343, 60347, 60348

Būklė: naudotas, DC main spindle drive, converter unit with digital control Simoreg V55 Spindle module, drive controller, rectifier, DC controller Manufacturer: SIEMENS Type: SIMODRIVE 6RA2725-6DV55-0 D380/60 Mreq-GdG6V55-3A0 Version: V55 base unit Input voltage: 3 AC 380 V Input frequency: 50 / 60 Hz Input current: 49 A Output voltage: 380 VDC Output current: 60 A Rated power: 22 kW Dimensions (W x H x D): 270 x 260 x 290 mm Weight: approx. 25 kg The drive controller is still operational in a Gildemeister GDM42. Godpfxjh D Syrs Acyeip The matching drive motor can be found under stock number 60347. Further components from the Gildemeister can be found under stock numbers: 60346, 60347, 60348

Būklė: naudotas, Bar Contactors, DC Contactor, Contactor, DC Switch, Power Contactor, Circuit Breaker, High Voltage Switch Giedefipfuepfx Acysp ABB Type NORR63-03 CC-SP FPL7146886R6000 CTC2014028R0001 Contactor Type: Normally Open Main Contacts Design: Open design mounted on busbars Drive: AC drive + laminated magnetic circuit + rectifier + series resistor Drive Rated Voltage: 220-230 V / 50-60 Hz Main Contact Rated Current: 63 A Main Contact Rated Voltage: 1500 VDC Number of Main NO Contacts: 0 Number of Main NC Contacts: 3 Number of Auxiliary Contacts: 1 NC + 1 NO + 1 Changeover Auxiliary Contact Rated Current: 6 A - Main contacts with deionization chambers for rapid arc extinguishing Dimensions (W x H x D): 410 x 250 x 195 mm Weight: approx. 9 kg Used but in very good condition

Būklė: naudotas, Multibeam Safety Light Curtain M 2000 extended version SICK Transmitter unit type: M20S-04130A122 Transmitter unit ID: 1 018 190 Transmitter unit software: V 3.2 Receiver unit type: M20E-04130A122 Receiver unit ID: 1 018 191 Receiver unit software: V 2.5 Protective field height: 913 mm Range: m Beam spacing: 300 mm Beam width: 13 mm Number of beams: 4 Safety category: Type 2 Resolution variant: 116,170 mm Response time: 6.7 ms Supply voltage: 24 Volt DC Installation cross-section: 38 x 48 mm Overall length: 1100 mm - Scope of delivery as shown - Cascadeable The cascadeable light curtains are designed for both single operation and cascading operation. Godsf Axpcspfx Acyeip A cascadeable light curtain consists of a transmitter and a receiver. An additional cascadeable or standard light curtain can be connected. Weight: 4.5 kg Good condition Perfect for presses, eccentric presses, hydraulic presses, guillotines, folding presses, or robots for use as a safety fence around machines such as nibbling machines or automats. Suitable as a safety curtain for machine tools such as milling machines, lathes, drilling machines or grinding machines. Not suitable for hand protection.

Būklė: naudotas, Hydraulically shiftable reversing gearbox for lathes Hydraulic reversing gearbox from a lathe Year of manufacture: approx. 1985 Change gearbox for rapid change of rotation direction (clockwise or counterclockwise) - Electric hydraulic pump for hydraulic pressure generation (380 Volt, 0.25 kW) Giodpjdz Sp Dofx Acyop - 2 solenoid valves for switching between clockwise and counterclockwise operation - Fitted with pulleys Ø 230 and 200 mm - Operated with a 15 kW drive motor, fast directional reversal with high torque transmission - Drive motor always runs clockwise, gearbox is hydraulically shifted to clockwise, counterclockwise, or stopped without actuation Overall dimensions (L x W x H): 480 x 520 x 430 mm Weight: 170 kg Good condition

Būklė: naudotas, High-current EMC filter SCHAFFNER type FS 20364-1200-99 3-phase, 3 x AC pre-mains unit, mains connection module, mains filter Input voltage: 3 x 400 VAC Input frequency: 50 / 60 Hz Gsdpfx Ajd D Dh Ascysip Rated current: 3 x 1200 A Dimensions (W x H x D): 135 x 260 x 235 mm Weight: 27.5 kg Very good condition, from warehouse clearance, unused 2 units available, price per unit

Būklė: naudotas, Drive motor, DC servo motor LENZE type GFQUBT 112-22 Spindle motor, electric motor Serial No.: 0239398K Year of manufacture: 1993 Rated power: 6 kW Operating voltage: 400 V DC Rated current: 18 Amperes Maximum speed: 1000 rpm Excitation voltage: 210 VDC Excitation current: 3.4 Amperes Shaft diameter: 38 mm (shaft with 10 mm keyway) Shaft length: approx. 76 mm (shaft extension from centering collar) Centering flange diameter: 230 mm Bolt circle diameter: 264 mm, 4 x 14 mm holes Long-life tachometer HÜBNER type TDP 0.2 LT-4 Giedsqv I S Sjpfx Acyop Tacho voltage: 60 V / 1000 rpm Maximum speed: 9000 rpm External fan LENZE type GSD 160 Mains connection: 400 V, 50 Hz, 0.32 kW Build length: 830 mm (excluding shaft and centering flange) Overall dimensions (L x W x H): 920 x 300 x 460 mm Net weight: 130 kg Good condition

Būklė: naudotas, Electric Motor, E-Motor LAMMERS Three-phase motor, heavy-duty motor Type: 1TZ95012AA434AB4-Z Mounting style: B3 Frame size: 200L Motor speed: 2,960 rpm Current consumption: 54 Amperes Motor power: 30 kW Mains connection: 400 Volt, 50 Hz Shaft diameter: Ø 55 mm Shaft stub length: 110 mm Keyway width in the shaft: 16 mm - Foot-mounted motor with 4 mounting holes Ø 19 mm, bolt hole spacing 315 x 300 mm Motor housing length without shaft: 620 mm Gjdpfxsf Axnxs Acyjip Motor housing length with shaft: 730 mm Required space (L x W x H): 730 x 400 x 520 mm Net weight: 205 kg Very good condition – new, unused, from stock clearance

Būklė: naudotas, Electric Motor, E-Motor SIEMENS Three-phase motor, Heavy-duty motor Type: 3LE16012BB233GB4 Design: V1 Frame size: 225M Motor speed: 1,475 rpm Current consumption: 84 Amps Motor power: 45 kW Power supply: 400 Volt, 50 Hz Shaft diameter: Ø 60 mm Shaft length: 140 mm Keyway width in the shaft: 18 mm Flange diameter: 450 mm Godpfefifnisx Acyoip Centering diameter: 350 mm Bolt circle diameter: Ø 400 mm - Flange-mounted motor with 8 mounting holes Ø 18 mm Motor housing length without shaft: 715 mm Motor housing length with shaft: 855 mm Required installation space (L x W x H): 855 x 450 x 570 mm Net weight: 320 kg Very good condition – new, unused, from warehouse clearance

Būklė: naudotas, Permanent magnet DC servo motor SIEMENS Type: 1 HU3074-0AC01-Z Serial No.: B J157 1047 01 008 Voltage = 167 V DC Power = 1.8 kW Current = 12.5 A Max. speed = 2000 rpm Nominal torque = Mo 7 Nm Shaft diameter: 24 mm Shaft length: 50 mm Centering diameter: 130 mm Bolt circle diameter: 165 mm / 4 x 11 mm holes - Shaft with 8 mm keyway Housing dimensions (L/W/H): 335 x 140 x 145 mm Gjdouch N Iepfx Acyjip Weight: 23 kg Good condition

Būklė: naudotas, Crane motor, travel drive, crane bridge drive with gearbox Slip ring motor, three-phase asynchronous motor, brake motor, Crane motor, hoist drive, crane drive, lifting motor, creep speed motor Manufacturer: DEMAG Motor type: 24/10 KF8-2 Motor no.: 982869 Mounting type: B5 Rated voltage: 380 VAC Rated frequency: 50 Hz Power stage 1: 0.58 kW = 715 rpm Power stage 2: 2.3 kW = 2900 rpm Gjdpfx Acjptlbljyoip with gearbox DEMAG type KS 12 Reduction gearbox Serial no.: 1909104 Gear ratio: i = 118 with running wheel for crane runway rail 2 units available, price per unit

Būklė: naudotas, The servo controller allows precise control of torque, speed, and position, making it ideal for complex, high-precision tasks. Here you will find a selection of used servo motors with various specifications and features. Speeds: rpm Torque: Nm Torque constants: Current: 1.2 - ,5 A Voltage: 0 - V Frequency: 5 Hz Equipped with brake motors with the following specifications and capacities: Voltage: 24 V Current: A Torque: 1 - 5 Nm Servo motors available from various manufacturers and production years. Speeds: rpm Torque: Nm Gijdpfx Acjvcqguoyjp Torque constant: 2 Current: 1.2 - ,5 A Voltage: 0 - V

Būklė: naudotas, For the conversion of electrical energy into kinetic energy. Conversion of torque and speed via gearboxes. Used electric motors available with or without gearbox, with or without brake, in various designs, with different features and specifications. Speeds: 67 rpm, Power factors: cosφ, Power ratings: kW, Currents: A, Voltage: 22 V, Frequency: 50 / Hz. Types of gearboxes: helical gear, worm gear, bevel gear, flat gear, adjustable gearboxes. Gearbox speeds: 8 - 559 rpm. Torques: 5 - 840 Nm. Speed: rpm Gisdpfsvcqrkox Acyep Power factor: 0 cosφ Gearbox speed: 559 rpm Torque: 840 Nm Power: kW Current: A Voltage: 22 V Frequency: 50 / Hz

Būklė: naujas, Gamybos metai: 2021, Funkcionalumas: visiškai funkcionalus, bendras svoris: 10 kg, pavaros santykis: 70, parduodama: reduktorius Wittenstein 100S-MF2-70, variklis Siemens 1FT7043 Godpfowq Dutjx Acysip

Būklė: naujas, Skersmuo / mm Pjovimo (kiekis) / 0 Svoris / kg Atlanta 58 83 907 servo sraigtinis reduktorius Tipas: 58 83 907 Gedpfx Asymquwocyjip n1: 5000 aps./min. P: 5,20 kW

Būklė: naudotas, Voltai / V Amperai / A Svoris / kg Gsdjymgbyopfx Acyeip Bendras galios poreikis / kW YASKAWA - Servovariklis Tipas: USAFED-09C21S

Būklė: naudotas, Pavaros galia / kW Voltai / V Amperai / A Gamintojas: Baumüller Tipas: GNA 160 LV Galia: 32 kW Maks. apsukos: 3375 aps./min Gsdpeymf Npefx Acyeip Įskaitant ventiliatorių ODF 71-2 Galia: 0,45 kW Maks. apsukos: 3600 aps./min Svoris: 315 kg

Būklė: naudotas, Pavaros galia / kW Voltai / V Amperai / A Bendras galios poreikis / kW Godpfeymf T Iex Acysip Mašinos svoris apie / t Užimamas plotas apie / m

Būklė: naudotas, Gamybos metai: 2015, bendras svoris: 422 kg, Motor – SIEMENS 1PH8 350 – 1DD102AW0-Z - Asynchronous motor - 480V Gisdpjw Hxiqsfx Acysp - 340 kW - 1350 rpm - 422 kg The motor is available 4 times, price per unit.

Būklė: naudotas, Gamybos metai: 2015, Motor – SIEMENS 1PH8 186 – 1DF00AA1 - Asynchronous / Synchronous motor - 330V - 74 kW - 1500 rpm Gedpew Hx A Dsfx Acyeip There are 2 units available, price per unit.

Būklė: naudotas, Synchronous servo motor with holding brake and gearbox, geared motor, electric motor, right-angle geared motor Motor: Manufacturer: LUST LTI DRIVES Godpfxof Dlzuj Acyeip Type: LSK-190-7-30-560 T1,P,KK,1R Order No.: 716090 Article No.: 0970.8016 Machine type: Permanently excited synchronous servo motor Controller DC link voltage Uzk: 560 VDC Rated power: 14.51 kW Rated speed: 3000 rpm Rated torque Mn: 46.2 Nm Standstill torque M0: 83.4 Nm Rated current In: 31.5 A Standstill current I0 / I0max: 54.9 / 219.6 A Number of pole pairs: 3 Shaft diameter: 32 mm Shaft length: 50 mm - Shaft end with key and keyway to DIN 6885 / A10x8x50 - Option 1R single-pole resolver - Option KK terminal box - Option T1 (DIN-PTC double basic insulation) - Power connection: 8-pole terminal box - Resolver connection: 12-pole terminal box Holding brake: Manufacturer: LUST LTI DRIVES Type: NFH10-H/BA Order No.: 718690 Article No.: Rated voltage: 24 VDC Rated current: 4.5 A Rated power: 108 W Brake torque: 65 Nm Right-angle gearbox WESTFALIA Systemtechnik Output hollow shaft: inner Ø 65 mm Hollow shaft length: approx. 280 mm Gearbox output speed: max. 450 rpm Gearbox input speed: max. 4500 rpm Gear ratio: 10:1 - Shaft end also ground externally - Gearbox mountable on two flange surfaces - Mounting holes on gearbox: 180 x 180 mm / 180 x 230 mm Overall dimensions (L x W x H): 1110 x 250 x 350 mm Total weight: 180 kg Good condition

Būklė: naudotas, Pavaros galia / kW Voltai / V Amperai / A Gisdpjyl Aa Nefx Acysp SIEMENS servovariklis 1FK6083-6AF71-1AH0 Svoris: apie 25 kg

Būklė: naudotas, Variklio galia / kW Gjdpfx Aceyl Aaveyoip Voltai / V Amperai / A SIEMENS NUOLATINIŲ MAGNETŲ VARIKLIS 1HU3056-0AF01 Svoris: apie 10 kg

Būklė: naudotas, Pavaros galia / kW Voltai / V Amperai / A SIEMENS servovariklis 1FK6063-6AF71-1AH0 Gedpfx Aoylz Sqecysip Būklė: naudotas (veikiantis)

Būklė: naudotas, Gamybos metai: 2008, Pavaros galia / kW Voltai / V Amperai / A Gjdpoylz R Tjfx Acyjip SIEMENS SERVO VARIKLIS 1FK7064-7AF71-1TA0 PUIKI BŪKLĖ Būklė: naudotas (veikiantis)
