CNC apdirbimo centras

WINTER ROUTERMAX 1325 ECO+OZ

Dimensions (L/W/H): 3300 x 2100 x 2100 mm
Weight: 1500 kg
Total power requirement: 14 kW
CNC Machining Center ROUTERMAX 1325 ECO+OZ

- Working area X-axis: 1300 mm
- Working area Y-axis: 2500 mm
- Working area Z-axis: 300 mm
- Milling spindle, water-cooled, 4.5 kW each, ER 25 with CHILLER CW 3000 cooling unit
- Spindle speed: stepless up to 22,000 rpm
- Drive system (X & Y axes): rack and pinion
- Drive system (Z axis): ball screw
- Drive motors: stepper motors
- Max. travel speed: 22 m/min
- Max. working speed: 15 m/min
- Working accuracy: 0.05 mm
- Vacuum grid table with 4 zones and T-slots
- Vacuum pump: 5.5 kW, dry-running, air-cooled
- Tool length sensor
- MACH3 control including PC and monitor
- Oscillation unit, including oscillating knife, software
- Interface: Ethernet / USB
- CAD/CAM software: Vectric Cut2D PRO (nesting included)
- Electrical connection: 3-phase, 400 V, 50 Hz
- Operating ambient temperature: 0–45°C
- Width: 2100 mm
Chedpfx Ahev A Haksvjc
- Length: 3300 mm
- Weight: 1500 kg
