Langų sistema
WEINIG Unicontrol 12 NC

Name: WEINIG Unicontrol 12 NC
Brand: WEINIG
Availability: InStock

Sąlyga

Naudotas

Vieta

Oberkochen Vokietija

Rodyti žemėlapį

Duomenys apie mašiną

Įrenginio aprašas:: Langų sistema

Gamintojas:: WEINIG

Modelis:: Unicontrol 12 NC

Sąlyga:: naudotas

Kaina ir vieta

Vieta:: Oberkochen

Skambinti

Mašinų pardavimas

Ar jau įdėjote savo naudotos mašinos skelbimą? Parduokite per Machineseeker be komisinių.
Daugiau apie mašinų pardavimą

Pasiūlymo informacija

Sąrašo ID:: A19207316

Nuorodos Nr.:: 1305-2711

Naujinta paskutinį kartą:: Data 2025.05.22

Aprašymas

Slotted spindle 2 pcs.
Number of milling units: 7 pcs.
Spindle diameter: 50 mm
CNC control: Weinig PC-Nexus
Weinig Uncontrol 12
With radial and axial NC spindles as well as VARIO table
.....
The machine has been professionally dismantled and stored in 73447 Oberkochen.

Technical Data Summary
(Please enquire separately about any additionally included accessories)
.....

Cross-cut saw
.....
> Cross-cut saw, electronically/electrically, stepless horizontal adjustment
> Number of tools: 1 pc.
> Spindle speed: 3000–6000 rpm
> Spindle diameter: 40 mm
> Maximum tool diameter: 400 mm
> Motor power: 3.7 kW
> Laser guide light for identifying cutting section
> Axial traverse: 150 mm NC axis, stepless electronic adjustment
> Radial traverse: pneumatic, 8 positions for e.g. top edge rounding

Rounding unit
.....
> Position: horizontal, bottom
> Axial traverse combined with cross-cut saw

Electronic length stop
.....
> Length: 4500 mm

1st tenoning and slotting spindle
.....
> Number of tools: variable
> Motor power: 15 kW
> Spindle diameter: 50 mm
> Tool clamping length: 640 mm, with counter bearing
> Axial traverse: 580 mm NC axis, stepless
> Spindle speed: 2,800–4,000 rpm
> Tool diameter: 380–400 mm
> Counter support: entire clamping length is countered

2nd tenoning and slotting spindle
.....
> Number of tools: variable
Cjdewmgfyjpfx Aa Sorh
> Motor power: 15 kW
> Spindle diameter: 50 mm
> Tool clamping length: 640 mm, with counter bearing
> Axial traverse: 580 mm NC axis, stepless
> Spindle speed: 2,800–4,000 rpm
> Tool diameter: 380–400 mm
> Counter support: entire clamping length is countered

Transfer conveyor
.....
For transferring the components into the longitudinal machining area, including double workpiece separation before the entry to the longitudinal machining section.

1st profiling spindle (climb and conventional milling)
.....
> Position: vertical right
> Number of tools: variable
> Motor power: 11 kW
> Spindle diameter: 50 mm
> Tool clamping length: 400 mm, with counter bearing
> Axial traverse: 350 mm NC axis, stepless
> Radial traverse: 80 mm NC axis, stepless
> Spindle speed: 6000 rpm
> Tool swing diameter min.: 140 mm
> Tool swing diameter max.: 232 mm

2nd profiling spindle
.....
> Position: vertical right
> Number of tools: variable
> Motor power: 11 kW
> Spindle diameter: 50 mm
> Tool clamping length: 400 mm, with counter bearing
> Axial traverse: 350 mm NC axis, stepless
> Radial traverse: 80 mm NC axis, stepless
> Spindle speed: 6000 rpm
> Tool swing diameter min.: 140 mm
> Tool swing diameter max.: 232 mm

3rd profiling/milling unit (grooving unit from above)
.....
> Position: horizontal, top
> Motor power: 3.0 kW
> Spindle diameter: 40 mm
> Tool clamping length: 40 mm
> Axial traverse: 30 mm NC axis, stepless
> Radial traverse: 125 mm NC axis, stepless
> Spindle speed ...
