Kraštų apklijavimo staklės VOLL servo PUR

SCM Olimpic S3000

Sąlyga: naudotas, Gamybos metai: 2016, TECHNICAL DATA AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Working area drilling/grooving mm 0 x 800 / 0 x 800 Travel of X axis mm 750 Max. traverse speed X-Y axes m/min 25 DRILLING UNIT Vertical spindles Quantity 7 (4X-4Y, one shared) Horizontal spindles (Y axis) Quantity 2 (1+1) Horizontal spindles (X axis) Quantity 1 Fixed grooving saw (direction) X Saw blade diameter mm 100 Max. saw blade thickness mm 5 Motor output kW (HP) 1.5 (2) Spindle speed rpm 3350 Saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Compressed air consumption Nl/cycle 90 Extraction requirement m³/h 1200 Extraction air velocity m/sec 20 Extraction nozzle diameter mm 80+80 F10L Drilling unit Includes: - 7 independent vertical spindles - Drill shank D10 mm - Distance between spindles 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1+1 drill shank D10 mm) - Speed 3350 rpm - 1 integrated sawing unit in X (max. diameter 100 mm) - Saw blade speed 4300 rpm - Motor output 1.5 kW - Vertical pneumatic stroke per spindle 70 mm - Horizontal pneumatic stroke of drilling unit Workpiece positioning and aggregate drive A CNC-controlled vacuum suction system clamps and positions the workpiece sequentially under the working unit during machining. X and Y axis movement is on THK guides with transmission via reinforced toothed belts. Z axis movement is pneumatic on ball-bushing guides with positioning via adjustable stops. Positioning of working units is achieved with DC technology and drives. CNC CONTROL The control was specially developed for use in drilling and milling machines. CN - 7" color display with touchscreen functionality - Alphanumeric keyboard - Self-diagnosis and operator language-specific error or fault messages Programming - Programming via CN - automatic optimization of drilling operations - Option for panel zero-point shift - Storage and import of drilling programs via USB dongle - Import of drilling programs from external CAD/CAM software Configuration - User interface in same language as instruction manuals Graphical representation of unit configuration Vacuum suction system "B-Power" Vacuum suction cup with double vacuum connector, recommended for highly porous panels (e.g. light MDF). Machine operation interface Software Xilog Maestro USB Hardware and software requirements: - Operating system: Windows XP Professional (SP2), Windows Vista or Windows 7 - Processor: Intel compatible, 2GHz min; multicore processor recommended - RAM: 1GB min., 2GB recommended - Free disk space: 5GB - Graphics card: OpenGL compatible (The code includes a DVD for installation and a USB key) Xilog Maestro features Programming - parametric, graphical programming - Supported programming with graphics and syntax assistance for drilling operations - Ability to create and save machining macros Integrated additional functions - Self-diagnosis and operator-language error or fault messages - User interface in Lredpevvi I Rjfx Af Iog

Sąlyga: geras (naudotas), Gamybos metai: 2004, Clamping knife head type (max.): 460 mm Knife head weight (max.): 150 kg Mounting plate diameter for knife heads (Ø): 360 mm Mounting taper for knife heads, nominal diameter Ø: 58.227 mm Travel distance - Z axis: 200 mm Chart recording magnification: ±10 - ±500 µm Machine weight approx.: 2.3 t Space requirement approx.: 2 x 1.5 x 2.03 m In the manufacturing process for spiral bevel gears, the quality of the gear cutting tools used is critical. Especially in dry cutting, achieving high gear quality and long tool life is only possible with precisely adjusted cutter heads. The Oerlikon Cutter Head Setting and Testing Device CS 200 enables quick and easy adjustment of individual cutters, checks their position, and documents the measurement results. The measuring process on the CNC-controlled testing device is semi-automated: Each step in the procedure is displayed on the screen via operator guidance. The positioning of individual cutters in the cutter head and the height of the cutter tips are managed by a special process that is largely automatic and simultaneously documented in a runout diagram. A subsequent measuring run checks the radial position of the inner and outer cutting edges of all the knives in the cutter head. If individual test parameters on the knives do not meet the specified tolerances, they can be individually readjusted. Lrjdpfx Afeul Efms Iog Combining a semi-automated setting sequence, operator-guided setup actions, and automated measurement procedures, cutter heads can be adjusted conveniently, quickly, and with high precision. Operator-guided setting and testing sequence: - Graphical display of the cutter head configuration and measurement results with tolerance monitoring - Step-by-step operator instructions in plain text (without coded information) - Simple assignment of measurement results to individual cutters - Documentation of adjustment and measurement results via printer - Setting and testing sequence suitable for stick blade cutter heads of the types ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® - Interface for neutral data

Sąlyga: naudotas, Gamybos metai: 2014, Power Control PC 22 control system with WoodWop – POWERTOUCH software. Panel height: 8 - 60 mm. PVC/ABS thickness: up to 3 mm. Feed speed up to 25 m/min (20 m/min with contour trimming). Electronically adjustable working height via CNC. Motorized, rubberized pressure belt with superior hold. Panel support guide for easier handling and introduction of small panels. Controlled entry guide. Anti-adhesive unit. Pre-milling unit with two motors (each 3 kW, 9000 rpm). Roller-bearing glue application unit for PUR adhesive, including premelter and glue tank. Edge pressing unit for straight profiles with CNC-actuated pressure rollers. Trimming unit with two motors (automatic tilt adjustment). Overlapping end trim unit with two motors. Rounding unit with two multifunction motors (flush trimming and rounding) with CNC control. Scraper unit for edges. Glue scraper unit. Buffing unit. Anti-adhesive unit. TECHNICAL DETAILS NEED TO BE VERIFIED. Lredpfx Aevqbh Eof Iog

Sąlyga: paruoštas naudoti (naudotas), Gamybos metai: 2005, veikimo valandos: 52 455 h, Funkcionalumas: visiškai funkcionalus, mašinos/transporto priemonės numeris: 2501-0154, tekėjimo ilgis: 600 mm, sukimosi skersmuo virš skersinio stumduko: 140 mm, tekėjimo skersmuo: 300 mm, ašies variklio galia: 25 000 W, veleno greitis (min.): 5 000 aps./min, veleno greitis (maks.): 5 000 aps./min, Z ašies eigos atstumas: 900 mm, greitas poslinkis X ašimi: 3 m/min, greitas poslinkis Y ašis: 3 m/min, greitasis eiga Z ašyje: 3 m/min, sukimosi greitis (maks.): 4 000 aps./min, sukimosi greitis (min.): 4 000 aps./min, sukimo momentas: 239 Nm, strypo praėjimas: 80 mm, X ašies padavimo greitis: 165 m/min, Y ašies padavimo greitis: 165 m/min, padavimo greitis Z ašis: 220 m/min, bendras svoris: 10 500 kg, Įranga: dokumentacija / vadovas, The machine is still in use and can be viewed in operation at VOVU Machining in Uden. A total of 6 identical machines are available here. Equipped with Fanuc 310iS control. Lrodpfour Hfzex Af Iog

Sąlyga: geras (naudotas), Gamybos metai: 2007, Technische Merkmale: - Maximale bearbeitbare Länge: 3.200 mm - Minimale bearbeitbare Länge: 200 mm - Maximale Breite: 200 mm - Minimale Breite: 40 mm - Maximale Werkstückhöhe: 130 mm - Tiefe bei max. Zapfendurchmesser 320 mm: 105 mm - Zapfenwagen-Geschwindigkeit min./max.: 0/100 m/min - Min./max. Profiliergeschwindigkeit: 3/15 m/min Zapfenbearbeitung: 1. Endabschneidsäge - 5,5 PS (4 kW) - Sägeblatt-Ø 400 mm 2. Zapfenfräser - Gegenlager 50 x 620 mm - 15 PS (11,3 kW) - Max. Werkzeug-Ø 320 mm - Achshub 575 mm - Automatischer Splitterschutz 3. Zapfenfräser - Gegenlager 50 x 620 mm - 15 PS (11,3 kW) - Max. Werkzeug-Ø 320 mm - Achshub 575 mm - Automatischer Splitterschutz - Vertikale Positionierung mit durchgehender Achse 4. Digitale Winkeleinstellungsspannung Profilieren: 5. Rechtsprofilfräse - Welle 50 x 320 mm - 10 PS (7,5 kW) - Werkzeug-Ø 130/240 mm - Achshub 280 mm - Zeitverzögerte Splitterschutzvorrichtung bei Kalibrierung - Doppelte Drehrichtung - Vertikale und horizontale Positionierung mit durchgehender Achse 6. Rechtsprofilfräse - Welle 50 x 320 mm - 10 PS (7,5 kW) - Werkzeug-Ø 130/240 mm - Achshub 280 mm - Vertikale und horizontale Positionierung mit durchgehender Achse 7. Rechtsprofilfräse - Welle 50 x 320 mm - 10 PS (7,5 kW) Ljdpfxet R T Hcj Af Iorg - Werkzeug-Ø 130/240 mm - Vertikale und horizontale Positionierung mit durchgehender Achse 8. Abschluss-/Aufnahmestation - Vertikale und horizontale Positionierung mit durchgehender Achse - Vorrichtung zum Ausziehen des Fensterladens - Hfutwt78Z 9. Untere horizontale Nutwelle - Vertikale und horizontale Positionierung mit durchgehender Achse - 88,5 PS (66,4 kW) 10. Digitale Führung 11. Teile-Rückführung zum Bediener

Sąlyga: naudotas, Gamybos metai: 1985, Edge thickness: 0.4 – 12 mm Workpiece thickness: 10 – 55 mm Minimum workpiece length: 160 mm Minimum workpiece width: 65 mm Feed rate: 13 m/min Pneumatic connection: 7 bar Total length: 5220 mm Weight: 1950 kg Heating tub with Quickmelt hot melt adhesive granulate Glue roller rotation for synchronized and counter-rotation Edge magazine for PVC rolls and strip edging Motorized upper pressure adjustment Pneumatically actuated pressure rollers Swiveling control panel at machine infeed All units are track-controlled – i.e., all workpiece-actuated limit switches are omitted Lrodoc Tmygopfx Af Isg End trimming Milling combination for bevel and radius milling with 2 swiveling units (1 unit with combination cutter for radius/straight, 2nd unit with bevel cutter) with pneumatic adjustment Scraper – with pneumatic adjustment Buffing Central lubrication for chain track Quick-change glue tank Digital counters Electronic frequency converters with integrated motor brake Edge monitoring with fault display Infrared heating element CE compliant Note on used machines: • Technical details subject to error and prior sale. • Prices listed are ex-location, loaded free on truck. • Machines have been cleaned and function-tested. • All machines are sold as viewed, without any warranty claims. Buyers are free to inspect the machines at their location. • Special agreements are only valid in written form. (Enquiries will only be answered if your address and telephone number are provided!)

Sąlyga: labai geros būklės (naudotas), Funkcionalumas: visiškai funkcionalus, Gamybos metai: 2021, veikimo valandos: 22 351 h, valdymo tipas: CNC valdymas, automatizacijos lygis: pusiau automatinis, lazdo šaltinio gamintojas: Trumpf, lazero valandos: 17 317 h, lazerio galia: 4 000 W, maks. lakšto storis: 20 mm, plieno lakšto storis (maks.): 20 mm, nerūdijančio plieno lakšto storis (maks.): 15 mm, aliuminio lakšto storis (maks.): 10 mm, darbinis ilgis: 3 000 mm, darbinis plotis: 1 500 mm, Z ašies eigos atstumas: 115 mm, kartojimo tikslumas: 0,03 mm, aušinimo tipas: vanduo, bendras svoris: 12 000 kg, Įranga: CE žymėjimas, apsaugos šviesos užtvara, aušinimo blokas, avarinis stabdymas, dokumentacija / vadovas, dulkių šalinimas, Parduodama: TRUMPF TruLaser 3030 su LoadMaster automatizacija Lodpfx Afewya Twj Ierg Įrenginys sumontuotas 2021 m. birželį. Aptarnautas tik TRUMPF Slovakia, profesionali priežiūra atliekama kas pusę metų. Įrenginys puikios būklės, su LoadMaster automatizacija. Lakštų pjovimas iki 25 mm storio. Rezonatoriaus tipas ir galia: CO₂, 4 kW. Maksimalus darbinis plotas: 3000 × 1500 mm. Įranga veiks iki 2025 m. gruodžio pabaigos, galima apžiūrėti bet kada visiškai veikiančią. Pateikiama pilna serviso istorijos dokumentacija.

Sąlyga: paruoštas naudoti (naudotas), Gamybos metai: 1974, Funkcionalumas: visiškai funkcionalus, mašinos/transporto priemonės numeris: 74-4-10, Panel saw ALTENDORF F90, year of manufacture 1974 Machine No.: 74-4-10 Manufacturer: Altendorf, Germany Saw length (mm): 2600 Cutting width (mm): 1300 Max. cutting height (mm): 130 Max. saw blade diameter: 400 mm Main motor: 5.5 kW With scoring unit 4 speed settings Manual saw blade height adjustment Approx. weight (kg): 780 Ledpfx Afoipvrbs Ierg Technical data subject to change

Sąlyga: beveik kaip naujas (naudotas), Gamybos metai: 2006, Technical Data Brand: KENT Model: VK 1600MC Year: 2006 Serial Number: 2200139 CNC Controller: FANUC 18 iMD Location: Tabaza (Asturias, Spain) Table Dimensions Table Surface: 1700 x 810 mm T-slots: 22 x 5 x 160 mm Maximum Table Load: 2,000 kg Travel Longitudinal Travel X: 1600 mm Cross Travel Y: 815 mm Vertical Travel Z: 815 mm Lredpfx Afjqwyzfj Iog Spindle Nose to Table Distance: 220 ~ 1035 mm Spindle Nose to Column Distance: 865 mm Spindle Taper: BT50 Spindle Speed: 30 – 6,000 rpm ZF Gear Change (2 speeds): Yes Maximum Tool Weight: 15 kg Maximum Tool Size (Diameter x Length): 125 x 300 mm ATC (Automatic Tool Changer) Maximum Tool Size: Ø125 x L250 Maximum Tool Weight: 15 kg Number of Tools: 32 Feed Rates Working Feedrate: 1 – 10,000 mm/min Rapid Traverse Rates (X / Y / Z): 18 / 18 / 18 mm/min Motor Main Spindle Motor (30 max. power): 15 / 18.5 kW Axis Drive (X, Y, Z): X: 5.5 | Y: 5.5 | Z: 5.5 Coolant Pump CTS: One air & two coolant pumps – 4 bar + 6 bar / 20 bar Weight and Dimensions Machine Weight: 16,150 kg Machine Dimensions: 4,488 x 3,448 x 3,250 mm Footprint: 5,000 x 3,500 mm.

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 1995, Max. panel width: 4400 mm Max. panel length: 4300 mm Max. main saw blade projection: 110 mm Number of clamping units: 8 Lrsdpfx Aemt Hhwjf Isg
