Apdirbimo centras su dėliojamuoju stalu

MORBIDELLI UNIVERSAL 3615

Būklė: naudotas, Gamybos metai: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Traverse length X-Y: 4,200 x 2,000 mm Description of units and accessories (basic version) The main body structure is a monolithic construction made from thick-walled steel. It is reinforced across the entire machine bed by welded-in triangular plates, providing exceptional stability. The use of triangles—with a wide base—for all load-bearing components ensures lasting precision and stability. The machine layout allows for optimal workflow with minimal space requirements. This construction provides the processing unit with a balanced and secure foundation, ensuring superior load distribution. The mobile unit carrier, designed as a gantry, is constructed as a solid monoblock. It is moved in the X-direction along precision-ground prismatic guides via recirculating ball carriages. The working unit is also mounted onto this mobile carrier using precision-ground prismatic guides and recirculating ball carriages. Axis movement: The Y and Z axes are driven by precision-ground recirculating ball screws of the highest accuracy class. The X axis drive employs a backlash-free preloaded precision rack-and-pinion system, ensuring balanced load distribution during positioning—critical for smooth movements, even in complex operations. The axes are driven by brushless AC servomotors. These provide excellent positioning speeds due to very low acceleration/deceleration times. Furthermore, these motors include fully integrated measurement systems, making this drive system entirely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum system (base version) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. vacuum (connection): 0.9 bar Control / control cabinet · Office PC or industrial PC (see options) · Base NC control: ESA-GV KVARA 6.0 · Cable remote control with main functions ELECTRICAL/ELECTRONIC CNC CONTROL Universal is equipped with a high-performance NC controller. The integrated office PC provides the CNC with an unmatched degree of user-friendliness: the software operates on Windows XP and allows for swift and straightforward programming, which is easy to learn even for inexperienced users. The system is open and allows the connection of CD-ROM drive, sound card, barcode scanner, modem, printer, scanning systems, etc. Additionally, the installation of all standard network systems as well as all off-the-shelf CAD programs is possible. To save space, the control cabinet is placed beneath the machine table, and the operator works at a separate, mobile terminal that can be positioned freely. XILOG PROGRAMMING SYSTEM Software features: - Import of DXF files - Import of ASCII files - User interface in operator's native language (available for I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral on the selected plane - supported programming - Calculator for direct transfer of computed data - Graphic and syntax helpers for drilling and milling operations - Parametric programming, to perform identical panel machining on different p Hjdpfx Afjvvi Nzetefh

Būklė: naudotas, Gamybos metai: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Description of Units and Accessories (Basic) The structure of the machine base is a monolithic construction made of thick-walled steel. It is reinforced through the entire machine bed with welded triangular plates, providing exceptionally high stability. The triangular shape with a wide base used for supporting parts is the key to ensuring long-lasting precision and stability. The design of the machine allows the user to maintain an optimal workflow, even with minimal space requirements. This machine base offers the processing unit a balanced and secure foundation with excellent load distribution. The mobile unit carrier, designed as a gantry, is constructed as a solid monoblock. It is positioned in the X-direction on prismatically ground rails using recirculating ball carriages. The machining unit is again mounted on the mobile carrier on prismatically ground rails and recirculating ball carriage. Axis movement: The drive system in the Y and Z axes is via ground recirculating ball screws of the highest precision class. The drive in the X axis is via a backlash-free, preloaded precision rack-and-pinion drive. This ensures balanced load distribution during the positioning process. Such a characteristic is crucial to ensure smooth movement, even during more complex operations. The movement of the various axes is achieved by brushless AC servomotors. These provide excellent positioning speeds due to very short ramp-up times. Additionally, the measurement systems are fully integrated into these motors. These features make this type of drive completely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum system (Basic) · Vacuum pump: 100 m³/h · Power: 2.5 kW · Max. vacuum (connection) 0.9 bar Control / Control cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with the most important functions ELECTRICAL/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC provides the NC control system with an unparalleled level of user familiarity: the software runs on Windows XP, allowing fast and easy programming that can be learned quickly, even by inexperienced users. The system is open and allows the connection of a CD-ROM drive, sound card, barcode reader, modem, printer, scanning systems, etc. Furthermore, installation of all commercially available network systems as well as any CAD programs available on the market is possible. To save space, the control cabinet is placed under the machine table, and the operator works at a separate wheeled terminal that can be freely positioned. PROGRAMMING SYSTEM XILOG Software features: - Import of DXF files - Import of ASCII files - User interface in the operator's native language (available for I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, spiral in the chosen plane - Assisted programming - Calculator for direct transfer of calculated data - Graphic and syntax help for drilling and milling operations - Parametric programming to perform the same panel machining on different Hsdpfx Aovvi Rfoftjfh

Būklė: geras (naudotas), Gamybos metai: 2007, Darbo sritis apie 3600 x 1500 mm X ašies greitis 70 m/min Y ašies greitis 60 m/min Z ašies greitis 15 m/min Variklio veleno elektros tiekimas 8,5-13 kW Horizontalios gręžimo galvutės 6-8 Praėjimo aukštis apie 130 mm Z ašies eiga 240 mm Sumontuota galia 20-30 kW Svoris apie 3500 kg Vietos poreikis apie 7400 x 3500 mm Gręžimo agregatas: 12 reguliuojamų velenų bei 4 + 2 horizontalios ašys Pjūklas Vertikali frezavimo galvutė Interpoliacinė vektoriaus ašis Horizontali frezavimo galvutė Stalas „TVN“ su šešiais laikikliais, L=1500 mm Lazerių įranga siurbimo pozicijoms Interpoliacinė vektoriaus ašis Vakuuminis siurblys NC valdymas su PC-Office Grąžto apsukos reguliuojamos inverteriu Hfsdpfx Afeyt H Imetoh Tiksli komplektacija pagal užklausą Duomenys pateikiami be garantijos Kaina nuo vietos, galime padėti su demontavimu (Pardavimas vykdomas kliento pavedimu)
