Prie veleno montuojamos žirklės

marki FOD BYDGOSZCZ* DPPD III 50E 530/150

Sąlyga: naujas, Gamybos metai: 2025, Funkcionalumas: visiškai funkcionalus, pjūklo disko skersmuo: 700 mm, pjovimo aukštis (maks.): 250 mm, darbinio aukščio: 850 mm, galia: 7,5 kW (10,20 AG), We are selling 1 x JRIMAC Under-Table Crosscut Saw UKS 1,000 Cross-sections: 60x940 - 140x820mm - 180x720 - 220x520 - 240x340 Max. cutting height: 260mm Saw blade: 700mm Working height: 850mm Extraction ports below and above: 160mm - Continuously adjustable pneumatic feed rate - Hydraulic brake cylinder for consistent stroke speed - Pneumatically controlled workpiece clamping device Fsdpsrfudrsfx Ab Sjft - Cut initiation via two-hand control with safety shield - Roller conveyors and stop systems available upon request

Sąlyga: labai geros būklės (naudotas), Storti RM 500 Edger - Italian manufacture - Year of manufacture: 1993 Ffsdpfxjk Talpe Ab Sst - Electrically adjustable saw blade spacing TECHNICAL SPECIFICATIONS: - Maximum cutting width: 435 mm - Maximum cutting height: 170 mm - Motor power: 2 x 22 kW - Maximum workpiece width: 600 mm - Minimum material length: 800 mm - Maximum blade diameter: 600 mm - Spindle diameter: 40 mm - Two upper feed rolls - One upper pressure roll - Feed roll motor power: 2 x 1.1 kW - Feed rolls with automatic pressure adjustment - Seven lower driven toothed rollers - Electric adjustment of saw blades - Two lasers - Feed speed: 25 and 50 m/min - Infeed table: 2950 mm - Outfeed table: 3000 mm - Drive roller diameter: 100 mm - Feed drive motor power: 2 x 1.5 kW Transport dimensions: 500 x 240 x 180 cm Weight: 3500 kg

Sąlyga: labai geros būklės (naudotas), pjovimo plotis (maks.): 700 mm, pjovimo aukštis (maks.): 120 mm, Right-hand machine, machine no. 188 hydraulic width adjustment, electrically adjustable Infinitely variable feed rate adjustment 0 - 80 m/min Drive motor 37 kW with V-belt pulley and motor tensioning rail Ffedov Raqxspfx Ab Sjt Various saw heads, spacer rings, and saw blades Infeed table with individual stands Fixed outfeed table The machine has been completely refurbished and is in top condition.

Gamybos metai: 1993, Sąlyga: naudotas, • Working width (mm): 2200 • Motor power (kW): 22 Fedpfx Abjn I Twyj Ssft • Upper rollers: with PU rings • Lower rollers: knurled • Saw shaft: included

Gamybos metai: 2001, Sąlyga: paruoštas naudoti (naudotas), Saw blade diameter: 750 mm, blade speed: 2200 rpm, table dimensions: 1500 x 1500 x 900 mm, cutting height at 90°/45°/30°: 295/200/137 mm, motor power: 16 kW, length: 1800 mm, width: 1500 mm, height: 1100 mm, weight: 650 kg. An on-site inspection is possible. Ffjdeurwy Ajpfx Ab Sjt

Sąlyga: naujas, Gamybos metai: 2025, Funkcionalumas: visiškai funkcionalus, įvesties srovės tipas: trifazis, garantijos trukmė: 12 mėnesiai, bendras svoris: 5 000 kg, įėjimo srovė: 44 A, stalo plotis: 1 200 mm, stalo ilgis: 2 700 mm, Kalimoji skirta padėklų apačių ir stalviršių sukalimui. Po vieno ciklo yra sukaltas vienas padėklas. Kalimas atliekamas mechaniškai. Mašina automatiškai paima vinis iš talpyklų, kuriose jos laikomos laisvai. Padėklų sudedamosios dalys imamos iš išorinių sandėlių dviejų darbuotojų. XP 1000 kalimoji skirta pramoninių padėklų gamybai su matmenų diapazonu nuo 800-1200/1200-2600. Kalimo ciklas reguliuojamas iš pulto, trunka mažiausiai 10 sekundžių. Plokštės su plaktukais reguliuojamos pilname plaktuko diapazone. Standartinėje kalimo įrangos komplektacijoje – 16 plaktukų ant aštuonių plokščių ir vienas formų komplektas 800/1200 padėklams. Kitos formos – pagal kliento pageidavimą už papildomą mokestį. Įrenginio našumas priklauso nuo darbuotojų ir jų greičio dėstant detales. Fsdpjt Tyn Ssfx Ab Ssft

Sąlyga: naujas, How does the machine work? The conveyor belt is installed downstream of an assembly machine, enabling subsequent trimming of the corners, chamfering of the pallet edges, and branding application. This machine is designed for continuous and reliable processing of pallets. It combines professional-grade precision with user-friendly setup. Pallet specifications: Minimum/maximum length: 600 mm – 1500 mm Minimum/maximum width: 600 mm – 1500 mm The machine is available in various models, with options for pallets up to a total length of 3000 mm. Ffjdpfx Aerg Dx Teb Sst IMH offers a range of additional machine modules that can be easily retrofitted to existing systems to achieve a higher level of automation. This listing merely serves as an example of the diverse solutions that can be realized with IMH machines. Since January 1, 2024, we have exclusively represented IMH machinery in Germany. The portfolio includes high-quality machines for pallet production, renowned for their reliability and performance. Feel free to contact us to learn more about IMH machinery or to arrange a personal consultation. Gebrüder Göbel – Your partner for IMH machinery in Germany. We look forward to supporting your projects!

Sąlyga: nepatikrintas (naudotas), Funkcionalumas: nepatikrintas, MULTIBLADE CIRCULAR SAW PAUL K 34G/1500 USED TECHNICAL SPECIFICATIONS: - FEED SYSTEM WITH RUBBER-COATED ROLLERS. - USEFUL FEED WIDTH: 1,500 MM Ffedpfjuryrnjx Ab Set - MAIN MOTOR POWER: 37 KW (50 HP) - ELECTRONICALLY CONTROLLED REDUCTION GEAR FEED MOTOR: 3 HP AND 2-48 M/MIN - MAXIMUM SAW BLADE DIAMETER: 300 MM - MAXIMUM CUTTING HEIGHT: 100 MM

Gamybos metai: 2006, Sąlyga: paruoštas naudoti (naudotas), Panel type: Coreboards for 3-layer parquet, panel length: 2230 mm, panel width: 782 mm, panel thickness: 9 mm–22 mm, panel thickness tolerance: 0.5 mm/panel, feed rate: 15 m–50 m/min, capacity: 12 cycles/min, working height: 1015 mm, max. saw blade diameter: 250 mm. Extraction system included. Documentation available. On-site inspection possible. Fjdpfst Amc Iox Ab Soft

Sąlyga: labai geros būklės (naudotas), Multi-Blade Edger ZLT 500 with Feeders 500/120 – Manufactured in the Czech Republic – Movable saw blade with the option to mount multiple blades TECHNICAL PARAMETERS: cutting width: 500 mm cutting height: 120 mm min. material length: 800 mm max. blade diameter: 450 mm single movable blade, spindle 70 mm fixed spindle length: 100 mm motor power: 45 kW two upper pressure rollers, four lower feed rollers feed speed steplessly adjustable via inverter shaft support two rows of pawls Fodpfx Asma Dkfsb Ssft maximum material width: 700 mm feed roller length: 3000 mm roller width: 700 mm roller diameter: 70 mm outfeed table: 6200 mm chain width: 60 mm seven pressure rollers two lower drive rollers transport dimensions (L/W/H): 700 / 245 / 180 cm weight: 3000 kg
