DMG CLX 450 V6

DMG CLX 450 V6

Sąlyga: geras (naudotas), Gamybos metai: 2021, veikimo valandos: 2 400 h, Funkcionalumas: visiškai funkcionalus, 2-axis universal turning center with driven tools, C-axis, Y-axis and sub-spindle Machine in extremely well-maintained condition Ergonomic DMG MORI SLIMline® panel Main spindle A2-8" with AC motor, power 17 / 25.5 kW (100/40% DC), 4,000 rpm Radial servo turret VDI 40 with 12 driven stations, Trifix® interface (DIN5480) Direct measuring system for X and Y axis Chip container Hydraulic hollow clamping cylinders, max. bar capacity D80 mm Sub-spindle A2-6" with spindle motor ISM 52, output 13 / 14 kW (100/40% DC), 5,000 rpm Electronic handwheel Y-axis ± 60 mm DMG MORI IoTconnector Control DMG MORI SLIMline® 0i-F Plus Fanuc Touch 19" Bar package & interfaces Part catcher for up to D80 x 200 mm, max. workpiece weight 4 kg Interface for bar feeder or loading device (DMG MORI standard) Right-side chip conveyor Signal lamp with 4 colors Main spindle chuck Hydraulic 3-jaw chuck D254 SMW BB-D 250 Pass-through D78 mm (limits bar capacity to D78 mm) Sub-spindle chuck Hydraulic 3-jaw chuck SMW BB-D 210 Pass-through D66 mm Draw tube inner diameter D52 mm Sub-spindle options External chuck rinse Pneumatic ejector with internal coolant supply Coolant / chip removal 12 bar high-pressure system with double filter and manual switching Coolant spray gun 5 bar Measuring / monitoring Manual tool measuring probe MARPOSS General options Parts conveyor front left instead of parts container Conveyor belt outside the work area Clamping jaw options Set of soft jaws for BB-D 210 (3 pieces per set, 3 sets) Set of soft jaws for BB-D 250 (3 pieces per set, 3 sets) Fanuc options Nedpfxsx Tg I Ue Af Iscl Tool monitoring software NCGuide software for programming environment incl. MANUAL GUIDEi Technology cycle alternating spindle speed Connectivity SERVICEcamera incl. accessories (antenna, charger, SD card) Special equipment / accessories Hydrafeed MSV 80 with floor rails, barfeed magazine, and modifications Swarf bin (model 350) VDI40 holder with multiple seats D1 (2 pieces) VDI40X25/25 double-Y holder for 4x Ø25 mm (2 pieces) VDI40X25X100 25Ø boring bar holder (1 piece) Axial driven tool VDI40, ER32, 1:1, max. 6,000 rpm, external cooling (1 piece) Radial driven tool VDI40 DIN 5480 H=100 mm, ER32, 1:1, max. 6,000 rpm, external cooling (1 piece) Cut-off holder H=32 mm, VDI40, universal toothing (1 piece)

Sąlyga: naudotas, Article: Clamping Heads Brand: Various Manufacturers Nedpfxon H Nzuo Af Iscl For Multi-Spindle Automatic Lathes, used or new Please contact us for further information and photos via e-mail (at) or

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 2017, SIEMENS 840D SL CNC Control Travel paths: 550 x 320 x 420 mm Swiveling milling head: +100 / -10 ° Spindle mount: HSK A50 Spindle speed: up to 12,000 rpm Tool changer: 64 positions Turning spindle: 4,500 rpm Nodpfowwundex Af Iecl NC swivel rotary table with B and C axes Tool breakage monitoring Tool length measuring system 3D measuring probe Various accessories MARCELS MASCHINEN CH

Sąlyga: geras (naudotas), Gamybos metai: 2019, mašinos/transporto priemonės numeris: XD-38II-CP-0703-H, sukimosi skersmuo virš skersinio stumduko: 38 mm, veleno greitis (maks.): 6 500 aps./min, tekėjimo skersmuo: 38 mm, veleno skylė: 39 mm, galia: 7,5 kW (10,20 AG), The machine can be inspected at our premises in Immendingen by prior arrangement. Included in the scope of delivery are the original chip conveyor, as well as a bar feeder from FMB type 3-36 turbo. Njdpfxjvtmals Af Iocl Also included is a Büchele SFB-301 high-pressure unit, 150 bar, with 4 valves.

Sąlyga: beveik kaip naujas (naudotas), Gamybos metai: 2022, veikimo valandos: 800 h, Funkcionalumas: visiškai funkcionalus, tekėjimo ilgis: 610 mm, sukimosi skersmuo virš skersinio stumduko: 500 mm, tekėjimo skersmuo: 725 mm, veleno greitis (maks.): 5 000 aps./min, veleno skylė: 65 mm, X ašies eiga: 260 mm, Y ašies eiga: 80 mm, Z ašies eigos atstumas: 610 mm, greitas poslinkis X ašimi: 30 m/min, greitas poslinkis Y ašis: 15 m/min, greitasis eiga Z ašyje: 30 m/min, padavimo ilgis X ašis: 260 mm, padavimo eiga Y ašimi: 80 mm, padavimo ilgis Z ašis: 610 mm, sukimo momentas: 250 Nm, strypo praėjimas: 65 mm, Įranga: dokumentacija / vadovas, sūkių greitis be galo kintamas, For sale: As-new EMCO MAXXTURN 65-G2 SMY, year of manufacture 2022, equipped with Siemens Sinumerik ONE with ShopTurn control! CNC turning center for complete machining of turned/milled parts. Features: - Integrated spindle motors, counter spindle water-cooled (preloaded roller guides) with Y-axis, - On main/counter spindle - Latest control technology SINUMERIK ONE with ShopTurn conversational programming. Main spindle: • Max. bar capacity: 65 mm • Max. torque: 250 Nm • Speed range: 0-5000 rpm Counter spindle: • Drive power: 22 kW • Max. torque: 130 Nm • Speed range: 0-7000 rpm Tool turret: • 12-station tool turret VDI 30 radial with direction logic for up to 12 driven tool holders - Max. drive power: 6.7 kW - Max. torque: 25 Nm Nedpfjx E Dncox Af Iscl - Max. speed: 5000 rpm Y-axis: • Travel range: +/-40 mm • Hollow clamping cylinder incl. draw tube • C-axis for main/counter spindle • Sinumerik ONE / OPERATE control • 22" multi-touch display • SHOPTURN • 3D simulation • Rest material detection • USB interface • Control cabinet air conditioning unit • Coolant system incl. coolant pump (3.5 bar) • Chuck flushing (extra pump 3.5 bar) • Parts ejector and flushing through the counter spindle Hydraulic unit • Interface for chip conveyor • Documentation and CE certificate Control language: German/English Electronic handwheel EMCO TOOL BREAKAGE AND WEAR MONITORING / SINUMERIK ONE Alternating spindle speed COUNTER SPINDLE AS TAILSTOCK This cycle allows the counter spindle with mounted live center to be used for supporting workpieces. Thus, shaft parts can be supported and machined on machines without a tailstock by using the counter spindle. The maximum contact pressure is limited to 50% of the maximum axis force. EMCO PROFI-NET ROBOT INTERFACE Interface for connecting robots. Implementation via HARTING connector. Signal exchange via Profinet. Safety signals 2-channel/potential-free. Digitization package for Sinumerik Condition monitoring SIEMENS ONE INTERFACE for connection to MDE/BDE systems Standard with the following information: • Machine on - AUX ON • Automatic operation • Production mode - program active • Program running and override between 95 and 105% • Piece count pulse (M30) • Programmable pulse (M300) 3D MACHINE DATA / MT65-G2 3D data model of the machine including: Pneumatically operated finished part catcher for gentle unloading of finished parts. Finished parts can be transported to a catch box (standard) or via a conveyor belt (option). • Max. finished part length: 175 mm • Max. finished part diameter: 65 mm • Max. finished part weight: 4.5 kg INTERFACE SL1200 HT65-DT/TT + MT65-1000 For connecting the EMCO SL1200 short bar loader. etc.... Machine is available immediately!

Sąlyga: beveik kaip naujas (naudotas), Gamybos metai: 2021, Technical Data: Cone Rolling Machine Working width: 1050 mm Max. bending capacity for mild steel St40: 4.0 mm Diameter of conical top roll: 70 - 185 mm Diameter of side and central lower rolls: 105 mm Conical bending device Mobile control panel with digital display Hydraulic drop-end bearing CE marking Motor power: 5.5 kW Dimensions (L x W x H): approx. 3600 x 1200 x 1200 mm Net weight: approx. 3 tons Condition: Ncedpow An Uhofx Af Isl Very little used, as new condition The seller does not assume liability for typographical or data transmission errors. The machine's appearance, technology, and wear are consistent with its age; used machines are sold without any guarantee.

Sąlyga: geras (naudotas), Gamybos metai: 2022, CNC Lathe Manufacturer: DMG MORI Machine Model: CLX 350 V1 Control: SLIMline 0i-F Plus Fanuc Touch Year of Manufacture: 2022 Controlled Axes: X / Z TECHNICAL DATA Turning length: 540 mm Spindle: Motor spindle 11/16 kW Tool holder: VDI30 with 12 stations Main spindle: AC motor - Speed: up to 5,000 rpm - Spindle nose: Main spindle A2-6" - Drive power (100/40% DC): 11 / 16.5 kW Nsdpfjw Hxi Dox Af Iocl Turret: 12 stations - Driven: 12 stations - Tool holder: VDI 30 FEATURES + Technology cycle for using alternating spindle speeds for vibration-critical workholding + Direct position measuring system X-axis + Programmable positioning and pressure force + Ergonomic DMG MORI SLIMline® operating panel + Hollow chuck device, max. bar capacity D65 mm + Tailstock, hydraulically traversable via M-function + External electronic handwheel + Chip disposal package: + Chip conveyor with right-hand side discharge instead of chip tank + 4-color signal lamp + Differential pressure clamping for the main spindle + Foot pedal for tailstock + Automatic NC tailstock for maximum machining flexibility – full control of force in the range from 0.7 to 3.5 kN + High-pressure pump 12 bar + Coolant spray gun 5 bar + Manual tool setting device in work area, make MARPOSS + Mechanical oil mist separator type AFS 600 Modifications and errors in the technical data and information are subject to change.

Sąlyga: naujas, Gamybos metai: 2024, Funkcionalumas: visiškai funkcionalus, X ašies eiga: 720 mm, Y ašies eiga: 600 mm, Z ašies eigos atstumas: 500 mm, valdiklių gamintojas: Heidenhain, valdiklio modelis: TNC 640, sukimosi greitis (maks.): 15 000 aps./min, General Spindle: Direct drive Speed: 15,000 rpm Power: 34 kW Torque: 180 Nm Tool holder: SK 40 Tool changer: 90 positions Working area Ncodpfx Ajtpm Nief Ijl Travel X: 720 mm Travel Y: 600 mm Travel Z: 500 mm Rotary/swivel table: D = 700 mm Table load: 350 kg C-axis resolution: 0.001 degrees Other Rapid traverse X/Y/Z: 36 m/min Max. speed B-axis: 25 rpm Max. speed C-axis: 25 rpm Equipment Chip management: Chip conveyor Coolant supply: Through-spindle coolant 40 bar Workpiece measurement: Renishaw OMP 40 Tool measurement: BLUM laser bridge Software: Kinematic Optimiser

Sąlyga: naudotas, Gamybos metai: 2014, Technical Details: Maximum grinding diameter: 3-220 mm Regulating wheel width: 500 mm Maximum grinding wheel width: 500 mm Approx. machine weight: 16 t Space required (approx.): 12 x 10 x 8 m Grinding wheel diameter min./max.: 420-610 mm Grinding wheel diameter x width – bore: 304.8 x 500 mm Regulating wheel diameter min./max.: 300-350 mm The machine is currently configured for plunge grinding. Ncodpst Uw Avefx Af Iol Centerless grinding with automation and PPM Marposs; Güdel Grinding with JUPITER means centerless cylindrical grinding, optionally also with CBN. JUNKER combines this cylindrical grinding method with CBN grinding wheels, offering significant productivity advantages, especially for high volume production due to the long service life of the grinding wheel. In addition, simultaneous material removal across the entire length of the part ensures considerably reduced processing times, both in serial and small batch manufacturing. JUPITER Grinding Methods There are two grinding processes in centerless grinding: through-feed grinding and plunge grinding. Both methods are possible with the JUPITER series. Areas of application for through-feed grinding: - Bolts and bearing bodies - Large rings - Small rings - Piston parts (e.g., for compressors) - Shafts with constant diameter - Piston rods (e.g., for shock absorbers) - Small pistons for hydraulics and injection systems - Precision wires and rods - Piston pins Areas of application for plunge grinding: - Rotor shafts - Transmission parts - Bearing seats for camshafts - Tubes for built camshafts - Universal joints - Needle parts for injection systems - Valve stems - Barrel rollers.

Sąlyga: naudotas, Gamybos metai: 2007, Turning diameter: 300 mm Swing diameter over bed: 430 mm Njdpswx R Rkefx Af Iecl Swing diameter over cross slide: 300 mm Control: SIEMENS SINUMERIK 840 D Travel – X axis: 160 mm Travel – Z axis: 510 mm Max. workpiece length: 480 mm Main spindle bore: 53 mm Main spindle speed: 0 – 7,000 rpm Spindle nose: DIN 55026 A2-5 Spindle torque: 100 Nm Main spindle motor: 15 kW Sub-spindle bore: 53 mm Sub-spindle speed: 0 – 7,000 rpm Spindle nose: DIN 55026 A2-5 Spindle torque: 100 Nm Sub-spindle motor: 15 kW C-axis resolution: 0.001° C-axis rapid traverse: 1,000 rpm Turret: 1 x 12 stations Number of driven tool stations: 1 x 12 Tool holder: cylindrical shank (DIN 69880) VDI 25 Speed of driven tools: 0 – 8,000 rpm Torque: 16 Nm Power: 4 kW Feed force X/Z axis: 4,000 / 6,000 N Rapid traverse X axis: 24 m/min Rapid traverse Z axis: 30 m/min Total connected load: 38 kVA Machine weight: approx. 4 t Machine dimensions (L x W x H): 2.65 x 1.84 x 2.32 m Accessories: Collet chuck 173 E on main spindle, Collet chuck 163 E on sub-spindle, Bar feeder, manufacturer FMB, type turbo 3-36/3200 A, year 2018, for bar diameters up to 36 mm and bar lengths up to 3,200 mm, Various tool holders for turret (no driven holders), Coolant system
