Dviejų velenų daugiavamzdis

Demak, A. COSTA, GABBIANI, COSMEC 36/22

Sąlyga: naudotas, Gamybos metai: 2003, Hochleistungs-Hobelmaschine Weinig Typ Hydromat 23 Vierseitige Hobel- und Profiliermaschine Weinig Hydromat 23 zum Vierseitenhobeln und Profilieren von Holz mit einer Vorschubgeschwindigkeit bis zu 100 m/min. Originaldaten der Maschine, technische Änderungen vorbehalten. - Spindeln: 8 - Spindelanordnung: 1. unten 18,5 kW // 6.000 U/min // Werkzeugkreis 125 - 180 mm // Gegenlager Kedpfxsup Av Do Af Njdw 2. rechts 22 kW // 6.000 U/min // Werkzeugkreis 112 - 250 mm 3. links 22 kW // 6.000 U/min // Werkzeugkreis 112 - 250 mm 4. oben 22 kW + Faseinrichtung // 6.000 U/min // Werkzeugkreis 112 - 250 mm // Gegenlager 5. unten 15 kW // 6.000 U/min // Werkzeugkreis 112 - 250 mm // Gegenlager 6. oben 22 kW // 6.000 U/min // Werkzeugkreis 112 - 250 mm // Gegenlager 7. unten 15 kW // 6.000 U/min // Werkzeugkreis 112 - 250 mm // Gegenlager 8. universal 11 kW // 6.000 U/min // Werkzeugkreis 112 - 200 mm - Spindeldurchmesser: 50 mm - Arbeitsbreite: 20 - 230 mm - Arbeitshöhe: 12 - 160 mm - Vorschub 22 kW // ca. 8 - 100 m/min - Baujahr: 2003 - ATS-System - Antrieb der Horizontalspindeln über Zahnriemen - 5 angetriebene Walzen im Tisch - Luftkissensystem im Maschinentisch - Kurzer Einlauftisch mit 4 angetriebenen Walzen - 400 V // 50 Hz

Sąlyga: naudotas, Gamybos metai: 2022, Funkcionalumas: visiškai funkcionalus, Y ašies padavimo greitis: 700 m/min, Apvalių rąstų žievės nuėmimo staklės CAMBIO 75, su CAM TOOL peilių sistema. Į komplektą įeina centrinis konvejeris ir papildomi ritinėliai už žievės nuėmimo staklių. Pilnai darbinės būklės, po kapitalinio remonto. Kdedpstcu Uajfx Af Njw

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 2004, Daugiaašmenė pjūklas Raimann ProfiRip KR 310 M su pakuotės kapavimo pjūklu HOLTEC ES 121SHKA kapavimo pjūklu ir ištraukiamu Hurrican dulkių siurbliu Modelis: Raimann ProfiRip KR 310 M Metai: 2004 (atnaujintas 2022 m.) Daugiaašmenė pjūklas su 2 reguliuojamais pjūklo diskais Techniniai duomenys: Kdsdpfx Asw S S A Tjf Njw Vėžės plotis: 340 mm Bendras praėjimo plotis: Maks. 950 mm (vietoje 800 mm) Pjovimo aukštis su/slėginė plokšte: 115 mm / 130 mm Ruošinio ilgis: Min. 450 mm Maksimalus pjūklo disko skersmuo: 380 mm Minimalus pjūklo disko skersmuo: 250 mm Pjūklo disko kiaurymė: 80 mm Pjūklo veleno skersmuo: 65 mm Pjūklo veleno sūkių dažnis: 3900 aps./min. Variklis: 30 kW Lazerinės linijos: 3 vnt. Darbinis slėgis: 6 bar Reguliuojamas padavimo greitis: 8–48 m/min Padavimo variklis: 1,5 kW Įtampa: 400V / 50Hz

Sąlyga: geras (naudotas), Gamybos metai: 1992, Funkcionalumas: visiškai funkcionalus, Manufacturer: BOSCH Type: SVZ 2500 A Maximum bag length: 400 mm Ksdpfx Aforrv T Ij Nodw Minimum bag length: 100 mm Maximum bag width: 250 mm Minimum bag width: 90 mm Maximum output: 80 bags/min

Sąlyga: beveik kaip naujas (naudotas), Double-shaft multirip saw A. COSTA PUMA 2/50 350/160 – Italian manufacture TECHNICAL PARAMETERS: cutting width: 350 mm cutting height: 160 mm motors: 37 and 45 kW feed motor: 3 kW lower shaft width adjustment maximum blade diameter: 280 mm spindle diameter: 2 x 60 mm sleeve diameter: 2 x 80 mm track width: 350 mm total power: 85 kW two feed speeds: 15 and 22 m/min central lubrication Kdsdpfxeqy E Rlo Af Njw minimum workpiece length: 600 mm electric height adjustment top and bottom shaft height adjustment six upper pressure rollers mechanical roller pressure town anti-kickback pawls cast iron frame extraction port diameter: 2 x 220 mm spindle speed: 4500 RPM machine dimensions (L/W/H): 250 / 235 / 210 cm weight: ~ 5000 kg

Sąlyga: geras (naudotas), Gamybos metai: 1996, KRÜSI Chalet Construction Machine / Log House Production Line Type CM 40 Manufacturer: Krüsi Maschinenbau AG, CH-9105 Schönengrund AR Year of manufacture: 1996 Condition: Good, technically inspected and cleaned / ready for operation Operating principle Processing of timber for chalet construction / log house production. Beams can be processed in a single pass. • Cross-cutting • Horizontal and vertical milling of notches/grooves in a single clamping • Drilling • Milling of end grooves Workpiece: • Max. cutting height: 200 mm • Max. cutting width: 250 mm Rugged welded steel construction. Machine (horizontal and vertical milling units) equipped with 4 special milling motors, hardened and ground guides for maximum processing accuracy. Carriage guided by dust-protected, preloaded ball bearing guide rollers. Working range up to 200 x 250 mm. Fully operational, with contactor control system; motors protected by thermal relays. Electrical equipment for 380 V, 50 Hz, with protective covers, central connection for customer-provided chip extraction system; includes 2 eccentric clamps; no milling tools (rebate cutter). Features electro-hydropneumatic horizontal and vertical feed, synchronized with the start of the milling motors. Rapid traverse and feed rate steplessly adjustable. Fully wired and installed, including air service unit. Beams thicker than 14 cm must be processed in two passes; for these beams, the workpiece must be fed again to the extent of the excess thickness for further milling. Machine guards over all moving parts with gas spring counterbalance. Machine description / equipped with: 1. Saw unit: Manual feed Spindle adjustment with analog scale display Max. saw blade Ø / bore Ø: 400 / 30 mm Tungsten carbide tipped with chip depth limiter (uni-directional) Adjustable riving knife Motor speed min⁻¹: 2900 Power (kW): 2.2 2. CM milling unit (log house unit): Hydropneumatic feed Spindle adjustment with digital scale display Horizontal milling unit: Cutter Ø: 180 mm Max. cutter width: 130 mm For cutter width >60 mm only use aluminum alloy cutters with indexable inserts. 2 x hydropneumatic feed motors, each 2.2 kW Hydropneumatic feed; rapid traverse and working feed rate steplessly adjustable. 3. Drilling unit: Manual feed Spindle adjustment with analog scale display Drill chuck: ER 25 collet Max. clamp Ø: 16 mm Max. drill Ø: 32 mm Motor speed min⁻¹: 1450, Power (kW): 1.8 4. End milling unit: Hydropneumatic feed Spindle adjustment with digital scale display Max. cutter Ø: 230 mm Max. cutter width: 60 mm Motor min⁻¹/2900, 3.0 kW 2 V-belts SPZ 9.5x1000 La Kjdeu Uh T Dopfx Af Nedw Pneumatics Required operating pressure min/max. MPa (bar): 0.7/1 (7/10) Air consumption: 8 Nm3/h Electrics Operating voltage V/Hz: 380 V, 50 Hz Rated power: 8.8 – 15.8 kW depending on configuration Customer-supplied fuse: 3 x 25 A (slow-blow) Max. simultaneous power demand: 4.4 kW Dimensions Machine width: 2400 mm Machine depth: 1600 mm Total height, guard lowered: 1600 mm Total height, guard raised: 2200 mm Extraction port Ø (under-floor extraction) Weight: approx. 1300 kg Including roller conveyor 2 x 6 m (2 x 4 m) Technical data subject to change!

Sąlyga: naujas, Gamybos metai: 2024, ANGOMAC SOLID MULTIRIP SAW 600 mm feed opening Cutting height up to 120 mm Maximum cutting width 480 mm Kdodpfeh Ia Upjx Af New

Gamybos metai: 2005, Sąlyga: paruoštas naudoti (naudotas), Wielopła Brodpol WP-165 2W - Machine in stock - Manufactured in Poland - Year of manufacture: 2005 TECHNICAL SPECIFICATIONS: - Cutting width: 380 mm - Cutting height: 165 mm - Diameter: 300 mm - Four top feed rollers - Pneumatic roller pressure - Four bottom feed rollers - Two rows of ratchets - Spindle diameter: 70 mm - Spindle speed: 3,640 rpm - Main motor: 2 x 55 kW Kdedpfx Afofum U Ee Now - Total power: 114 kW - Horizontal clearance: 500 mm Machine dimensions: - Length: 220 cm - Width: 180 cm - Height: 220 cm - Weight: 2,940 kg

Gamybos metai: 1999, Sąlyga: naudotas, The DSG 200 vertical sawmill is the ideal option for woodworking facilities specializing in furniture and wooden flooring production; it is efficient and performs reliably in operation. A used Wintersteiger mini sawmill is a very sound investment. A major advantage of this machine is that it does not take up as much space as standard equipment of this type, while still excelling in material processing. It is used for cutting individual elements and matching them to the desired sizes. The machine is easy to operate and can be mastered quickly. The greatest asset of our sawmill is its extensive equipment, featuring primarily a blade spraying system controlled from the panel, enabling precise cutting of wet material. It features independent adjustment of the upper rollers’ height, allowing for quicker cutting height settings. Pneumatic feed pusher assists the feed process. TECHNICAL DATA: -Total power: 27.3 kW -Air Jet system motor: 2.3 kW -Siemens control panel -Feed rate up to 2 m/min -Sawmill frame stroke: 210 mm -Strokes per minute: 400 -Cutting height: steplessly adjustable (smoothly) on our frame: 45–250 mm -Maximum achievable cutting height: 400 mm! -Cutting width under side pressure: 80–205 mm -Minimum block length: 250 mm -Lamella thickness: from 1.5 mm – depending on wood type and cutting height -Kerf for used blades: 0.9–1.1 mm depending on cutting height -Length: approx. 5000 mm -Width: approx. 1300 mm -Height: approx. 2600 mm -Weight: 5000 kg Pneumatic feed pusher assists the feed process The machine is supplied with: -Complete large saw blade frame -Small saw blade frame Kdedpfx Afjtvm Hdj Nsw -Frame pins -Frame tensioning wedges -Blade spacers -Blades for wet cutting -Blades for dry cutting -Set of upper feed rollers -4 lower feed rollers -Set of slides -Frame yokes -Pocket cutting guides -Loading magazines -DTR documentation -Electrical diagram

Sąlyga: naudotas, Gamybos metai: 1994, Doppia sega multilama a mandrino - Produttore: A.Costa - Modello: Jaguar - Altezza massima di taglio: 200 mm Ksdpfotqld Ujx Af Nodw
