Mobilus vakuuminis presas

COLUMBUS Move

MOVE – the high-precision vacuum press with an enormous usable area for vacuum laminating and vacuum veneering of curved workpieces. Offers ultimate flexibility owing to its complete mobility and revolutionary folding mechanism, reducing its footprint by 45% when folded.

High-precision vacuum press with hinged opening, including:
- Revolutionary folding mechanism (footprint reduced to 45%)
- 40 m³ high-performance vacuum pump (up to 900 mbar (9 t/m²)) from BECKER – with optional automatic shut-off when the target vacuum is reached (for large vacuum volumes)
- Adjustable pressure from 400 to 900 mbar, analog vacuum pressure gauge
- Highly elastic natural rubber membrane (up to +130 °C)
- Quick-change membrane system
- Robust, 15-ply phenolic resin worktop (up to +120 °C)
- Gas pressure springs for flap opening
- Vacuum pressure gauge
- Connection for external vacuum bag
- Smooth-running swivel castors
Chedpfxjxfz Has Ahvjc
- FESTO pneumatic components and SIEMENS electrical engineering

Technical data and dimensions:
- Usable area: approx. 3050 x 1350 mm
- Overall dimensions: approx. 3700 x 1700 x 1100 mm
- Overall dimensions (folded): approx. 3700 x 770 x 1780 mm
- Frame inner dimensions: approx. 3130 x 1430 mm
- Voltage: 230 V
- Power: 1.2 kW
- Mains frequency: 50 Hz
- Weight: 670 kg
