Hidraulinis presas

VEB Wema Zeulenroda PYE 250 SS

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 2011, CNC Twin-Spindle Turning Center Control: CNC path control incl. 19" TFT Siemens Sinumerik 840 D sl solution line with ERGOline control and ShopTurn 3 G TECHNICAL DATA Maximum turning diameter: 340 mm Spindle distance: 1470 mm Turning length: 1135 mm Swing diameter over bed: 700 mm Swing diameter up to tool turret 2: 540 mm Travel paths: X1 – Tool turret I: 270 mm Y1 – Tool turret I: 120 mm Z1 – Tool turret I: 1200 mm X2 – Tool turret II: 195 mm Y2 – Tool turret II: 80 mm Z2 – Tool turret II: 1200 mm X3 – Counter-spindle slide: 180 mm Z3 – Counter-spindle slide: 1200 mm Main Spindle Integrated spindle motor ISM 102 Drive power (100/40% duty cycle): 40/48 kW Torque (100/40% duty cycle): 570/680 Nm Speed range: 0-4000 rpm Bar diameter: 102 mm Draw tube inner diameter: 104 mm C-axis and spindle brake (angular resolution): 0.001° Counter Spindle Integrated spindle motor ISM 76 Drive power (100/40% duty cycle): 25/32 kW Torque (100/40% duty cycle): 280/380 Nm Speed range: 0-5000 rpm Bar diameter: 65/75 mm C-axis (angular resolution): 0.001° Slide 1 Tool turret (direct drive) Number of tools: 12 Tool holder diameter VDI (DIN 69880): 40 mm Max. power (100/40% duty cycle): 10.9/14.2 kW Max. torque (100/40% duty cycle): 26/34 Nm Kdodpfx Aswcd S Njf Tjw Speed range: 40–10000 rpm Slide 2 Tool turret (direct drive) Number of tools: 12 Tool holder diameter VDI (DIN 69880): 40 mm Max. power (100/40% duty cycle): 10.9/14.2 kW Max. torque (100/40% duty cycle): 26/34 Nm Speed range: 40–10000 rpm Slide 3 Rapid traverse speed X-/Z-axis: 30/45 m/min Tool resolution Z-axis: 0.001° Feed force (40% duty cycle) X-/Z-axis: 16/13 kN EQUIPMENT/ACCESSORIES  Short bar loader IRCO ILS-RBK 100/16  Various main spindle reduction tubes  NC-controlled workpiece unloader from both main and counter spindle The unit consists of NC-controlled * horizontal axis * swivel unit * vertical axis * 2-jaw gripper for interchangeable gripper jaws  Conveyor belt for removing workpieces from the machine  Coolant system 8/20 bar with immersion cooler  Chip conveyor  Oil mist extraction  Control cabinet cooling unit (up to 40°)  Counter-spindle slide  Easy-Tool Monitor  1 collet chuck for quick-change chuck size 100 for main spindle  1 collet chuck for quick-change chuck size 100, Nova AxisFix for counter spindle  Approx. 40 various quick-change chucks size 100 (total stock)  Change device, pneumatic ø 100 mm  Approx. 50 various tool holders, stationary and driven (total stock)  Mounting elements  Documentation

Sąlyga: naudotas, Gamybos metai: 2003, Pressure: 250 t Stroke: 20 - 190 mm Strokes per minute: 25 - 140 Throat depth: 460 mm Clearance between frame uprights: 590 mm Shut height: 690 mm Table size: 1500 x 880 mm Pass-through opening in table: 950 x 250 mm Table height above floor: 900 mm Ram area: 870 x 725 mm Ram adjustment: 120 mm Drive power: 30.0 kW Weight: 32.0 t Space requirement approx. 2.34 x 2.38 x 3.99 m (L x W x H) Approved for manual loading operations and automatic operation in accordance with CE standards Kodevuun Tepfx Af Tsdw Equipped with infinitely variable drive, safety light curtain (manufacturer: Sick), hydraulic clutch/brake combination, hydraulic overload protection in the ram, automatic stroke adjustment, motorized ram adjustment, pneumatic ram counterbalance, fixed table, pneumatic drawing cushion in the table (20 t), motorized central lubrication, operator panel with two-hand control Clear space between tie rods: 940 mm Side opening: 900 mm

Sąlyga: paruoštas naudoti (naudotas), valdiklio modelis: Fanuc 310i, tuščias svoris: 10 000 kg, bendras ilgis: 4 500 mm, bendras plotis: 1 990 mm, bendras aukštis: 2 300 mm, sūpynės skersmuo virš skersinio vežimo: 950 mm, Vřeteno 1: 20 kW – 5000 ot/min – průchozí otvor vřetena: 70 mm Revolverová hlava 1: 12 poháněných nástrojů – 2,5 kW – 4000 ot/min Poháněná osa C Posuv v ose X1: 165 mm Posuv v ose Y1: +50/-30 mm Posuv v ose Z1: 678 mm Vřeteno 2: 17 kW – 5000 ot/min – průchozí otvor vřetena: 42 mm Revolverová hlava 2: 12 poháněných nástrojů – 2,5 kW – 4000 ot/min Poháněná osa A Posuv v ose X2: 165 mm Posuv v ose Z2: 640 mm Podavač tyčí Iemca Master 880 P Průměr průchozího otvoru vřetene: 70 & 42 mm Výkon na vřetenu: 20 & 17 kW Počet rychlostí: 5000 ot/min Ksdpfxsv Rwlte Af Tjdw Sklíčidlo: Ø 175 mm Výměník nástrojů: ano (2x) Počet nástrojů: 12 nástrojů (2x)

Sąlyga: naudotas, Gamybos metai: 1989, Pressure: 250 t Stroke: 20 - 190 mm Strokes per minute: 24 / 48 Throat depth: 500 mm Gap between side frames: 1000 mm Shut height: 615 mm Table size: 1400 x 880 mm Table opening: 450/500 mm Table height above floor: 800 mm Ram area: 1380 x 620 mm Ram adjustment: 125 mm Drive power: 29.0 kW Kodevut Ncepfx Af Tjdw Weight: 27.0 t Space requirement approx. 2.0 x 2.6 x 4.1 m (L x W x H) Approved for manual feeding operations in accordance with German accident prevention regulations (UVV). Features include pole-changeable motor, pneumatic clutch/brake combination, hydraulic ram overload protection, pneumatic ram weight compensation, motorized ram adjustment, semi-automatic stroke adjustment, motorized central lubrication, two-hand operation. The machine can be inspected under power at our warehouse.

Sąlyga: geras (naudotas), Gamybos metai: 1998, Press force: 315.00 t Stroke: 500 mm Throat depth: 425 mm Daylight (Stroke up): 1,000 mm Table surface: 1,200 x 815 mm Table height above floor: 800 mm Ram surface: 1,100 x 700 mm Downward speed: 48 mm/s Upward speed: 330 mm/s Working speed: 19 mm/s Oil capacity: 1,600 l Power requirement: 82.0 kW Weight: 23.00 t Overall dimensions (W x D x H): 2.4 x 2.8 x 4.0 m Permitted for manual loading according to CE regulations. Equipped with oil-hydraulic drive, pressure-, time- and stroke-dependent control, Kjdjv Rwu Ujpfx Af Tedw front light barrier (Sick), two-hand operation.

Sąlyga: geras (naudotas), Gamybos metai: 2012, Stangendurchlass 51 mm, maximaler Schneiddurchmesser 255 mm, Y-Achse Verfahrweg +/- 40 mm, C-Achse an beiden Spindeln 0,001 Grad Auflösung, 12-fach Revolver oben & unten, Spindelleistung 18 kW, Kjdpfx Afsvzry Tj Tedw Spindeldrehzahl 5.000 1/min, Fräsleistung 18 kW, Frässpindeldrehzahl 6.000 1/min, Gegenspindelweg 650 mm, Späneförderer, Werkzeugvermessung, Teilefänger, Spannzangenfutter, Werkzeugbestückung, Stangenlademagazin & Wellenentlader

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 1988, Funkcionalumas: visiškai funkcionalus, stalo plotis: 680 mm, stalo ilgis: 1 070 mm, eigos reguliavimas: 90 mm, bendras svoris: 9 600 kg, spaudimo jėga: 110 t, eigos ilgis: 180 mm, įvesties srovės tipas: trifazis, galia: 7,5 kW (10,20 AG), perforavimo jėga: 110 t, garantijos trukmė: 6 mėnesiai, paskutinio kapitalinio remonto metai: 2020, Įranga: dokumentacija / vadovas, AIDA C1-11 110 Ton Eccentric Press with Air Clutch in like-new condition for sale Manufacturer: AIDA Engineering LTD Model: C1-11 (2) Year of manufacture: 1988 Press force: 110 t Two-hand operation Central ram Required air pressure: 5 bar Kodpfxju Har Es Af Tjdw Stroke length: 180 mm Number of strokes: 35-65/min Shut height: 350 mm Stroke adjustment: 90 mm Table size: 1080x680 mm Ram size: 600x525 mm Total response time: 170 ms Voltage: 200 V, 50 Hz, 7.5 kW Machine weight: 10,884 kg

Sąlyga: naujas, Gamybos metai: 2025, Funkcionalumas: visiškai funkcionalus, Eccentric Press 160 t / 1600 kN Siemens 1200 PLC Adjustable Stroke 16–160 mm Ram Adjustment 100 mm Ram Plate 740 x 420 mm Ram Plate Thickness 100 mm Table Plate 1200 x 600 mm Kdsdpswir U Ejfx Af Tow Table Plate Thickness 180 mm Motor 15 kW Weight 16,000 kg

Sąlyga: geras (naudotas), Gamybos metai: 2000, veikimo valandos: 5 000 h, Funkcionalumas: visiškai funkcionalus, mašinos/transporto priemonės numeris: 2089, bendras aukštis: 5 000 mm, stalo aukštis: 1 000 mm, bendras plotis: 3 000 mm, spaudimo jėga: 250 t, bendras svoris: 25 000 kg, HYDRAULIC PRESS BY MIB YEAR: 01/2000 CAPACITY: 250T MACHINE TO BE PUT BACK INTO OPERATION, COMPLETE Kodpfx Asv Hbh Rjf Tsdw
