SK Group & Céspedes 20HL fermentacijos ir laikymo rūsys (2014 m.)

SK Group & Céspedes Gär- und Lagerkeller

Gamybos metai: 2024, Sąlyga: naujas, The semi-automatic filler is the ideal solution for small businesses producing up to 5,000 bag-in-box units per year. The system is equipped with: an electromagnetic flow sensor, an electronic control panel—for programming the filling volume (minimum 1 liter) and performing calibration—and a self-priming EURO 20 rubber impeller pump. At the beginning and end of the cycle, the vacuum must be operated manually by the user, and nitrogen injection is managed using two manual pulse valves. Opening and closing of the tap are performed with two standard stainless-steel tools supplied as standard. A drip-catcher buffer is included. The stainless-steel bag holder features adjustable height and is removable. The user selects the desired filling volume and activates the switch to start the filling cycle. The filler performs a complete cycle: opening the valve / starting the pump / stopping the pump / closing the valve. • Touchscreen control for programming capacity and calibration • Digital flow meter max. 7,000 l/h • Stainless steel table with adjustable and removable support, featuring 4 adjustable feet • Stainless steel filling head Kjdpfjtpxtisx Agrjdw • Pulse valve for manual nitrogen injection • Locking system for the filling head • Drip-free filling • Automatic start and stop for an external pump • Dual semi-automatic system for opening and closing the connector • Suitable for filling flexible bags or pouches (high or low type) with at least 1 liter capacity • S/S – Suitable for CIP (Cleaning In Place) circuit Technical data: • Power requirements: 220V 50-60 Hz • Suitable for: Ø 20–25 mm • Capacity: 5 l/h 150 pcs • Capacity: 10 l/h 100 pcs • Capacity: 20 l/h 40 pcs • Dimensions: 740x900x720 mm • Weight: 50 kg

Sąlyga: paruoštas naudoti (naudotas), Gamybos metai: 2014, Number of decks: 1, total number of zones: 12, number of regenerative zone pairs: 3, number of pasteurization zones: 5, number of separate cooling zones: 1, number of tunnel modules (excluding infeed and discharge modules): 12, pump side: right, belt load: 152.6 kg/m², max. belt load: 260 kg/m², throughput for 0.15 l and 0.25 l: 65,000 cans/h, with documentation, an on-site inspection is possible. Kdedpfx Ajrn Ta Uogrew

Sąlyga: labai geros būklės (naudotas), 12 x GRP storage tanks Capacity: 65,000 litres Diameter: 3,500 mm Length: 7,800 mm Weight: approx. 2,500 kg Last stored medium: vinegar (food grade) Design: cylindrical with flat bottom Connections: 1 x oval manhole 1 x residual drain 1 x extraction nozzle Kdjdpfxjhzt N Nj Agrsw

Sąlyga: naudotas, Gamybos metai: 2013, Machine (additional features): High-pressure homogenization Capacity range: 600 l/h Kodpevcq Edofx Agrjdw Pressure: 250 bar Pulp particle size: 1 µm pulp particles Length: approx. 2.2 m Width: approx. 2.5 m Height: approx. 1.9 m Operation / Control: Integrated into ProLeit process control system via signal exchange, motor controlled via external frequency converter. Features: CIP-capable, SIP-capable

Sąlyga: naujas, Gamybos metai: 2025, Funkcionalumas: visiškai funkcionalus, bendras plotis: 2 400 mm, bendras ilgis: 15 000 mm, bendras aukštis: 2 800 mm, slėgis: 8 juosta, galia: 10,9 kW (14,82 AG), tuščias svoris: 6 400 kg, įėjimo įtampa: 400 V, pildymo svoris (min.): 200 g, užpildymo svoris (maks.): 5 000 g, XFR 1000 Linija za punjenje tečnih medija Potpuno automatizovana linija za punjenje tečnih medija sa robotskim zavrtanjem čepova, automatskim postavljanjem ručki, dvostrukim etiketiranjem, optičkom kontrolom kvaliteta i omotavanjem paleta. Kompaktno rešenje koje pokriva ceo proces, od izduvavanja boca do paletizacije i omotavanja napunjenih boca. XFR LIQUILOAD Omogućava optimalne brzine punjenja za boce različitih karakteristika i tečnosti različite viskoznosti. Kedpfx Aouq Nv Tsgrodw Jednostavna konfiguracija mašine za različite tipove boca i odgovarajuće tečnosti garantuje brzu prilagodbu zahtevima tržišta. • Mogućnost povećanja broja dizni • Dizne konstruisane za sprečavanje penušanja tečnosti • Od 800 do 4.000 napunjenih boca na sat • Servo upravljanje pozicioniranjem dizni • Jednostavno podešavanje novih programa XFR BOTTLELOCK Ova sekcija mašine vrši potpuno automatizovano zatvaranje napunjenih boca. Dizajnirana za različite tipove čepova, olakšava podešavanje i omogućava neometan rad. • Prilagodljivost na različite tipove čepova • Robotsko zatvaranje boca • Optička inspekcija • 800 do 2.000 zatvorenih boca na sat XFR HANDLEGRIP Automatsko robotsko postavljanje ručki na boce, dok se neprekidno pomeraju ka mašini za etiketiranje, obezbeđuje glatki i neprekinuti rad. • Prilagodljivost različitim tipovima ručki • Robotsko postavljanje ručki na boce • Optička kontrola orijentacije ručki • Mogućnost postavljanja ručki sa levkom XFR LABELFLOW Mašina aplikuje odgovarajuće etikete sa obe strane boce, obezbeđujući kompletan završni izgled. Nakon toga, etiḱirane boce prolaze optičku kontrolu. • HERMA sistem za etiketiranje • Jednostavna zamena tipa etikete • Servo upravljanje za veću preciznost etikriranja • Praćenje preostalog broja etiketa sa signalizacijom operateru OPCIONI DELOVI: 1. OPTIČKA KONTROLA Industrijske kamere sa integrisanim osvetljenjem i pneumatskim sistemom za izbacivanje. 2. PICK AND PLACE ROBOT Robot sa 6 osa i hvataljkom kapaciteta 160 kg za istovremeno slaganje 8 boca na Euro paletu. 3. PALETIZACIJA Paletizer sa automatskim dovođenjem paleta putem rolerskog transportera do zone slaganja boca. 4. OMOTAVANJE PALETA Automatska mašina za omotavanje nanosi rastegljivu foliju na paletizovanu robu, čime je osigurava za lakši i bezbedniji transport. 5. SKLADIŠTENJE GOTOVIH PROIZVODA Završene palete se transportuju do skladišta putem metalnog rolerskog transportera. 6. DALJINSKA PODRŠKA KUPCIMA Obezbeđujemo daljinsku podršku za optimalan rad mašine. 7. DODATNE OPCIJE Automatska integracija sa ERP sistemima; RFID prijava; NFC detekcija delova i alata; alati sa magnetnim postoljem. 8. KONFIGURACIJA MAŠINE Segmenti mogu raditi samostalno ili kao integrisano rešenje, u zavisnosti od specifičnih zahteva klijenta. Proton EE-Elektronika d.o.o. MachinFlex d.o.o.

Sąlyga: labai geros būklės (naudotas), 200m³ Stainless Steel Tanks Quantity: 3 units 180m³ Stainless Steel Tanks Diameter: 4.70 m Height without legs: 14 m Kdedpefngl Nsfx Agrow Wall thickness: 4.1 mm Bottom thickness: 5.1 mm We offer transport with our special trailer to all regions of Europe!

Sąlyga: paruoštas naudoti (naudotas), Gamybos metai: 2011, Features: * Used telescopic belt conveyor * Condition: fully functional with signs of use * Ideal for rapid material transport * Professionally dismantled and packaged * Color: Blue * 2 units in stock * Price per unit Technical Data: Manufacturer: Budde Year of manufacture: 09/11 Model: TGF03 Total length: 14,530 mm Conveying length: 14,000 mm Retracted length: 5,000 mm Extended length: 14,000 mm Overall width: 1,240 mm (incl. control cabinet) Width: 990 mm Belt width: 600 mm Condition: good (used) Belt type: smooth Overall height: 750 mm Dead weight: 2,200 kg Including counterweights at the rear. Telescopic Belt Conveyor The telescopic belt conveyor is ideally suited for use in picking zones to connect machines or workstations and optimize internal workflows. During transport, the telescopic belt conveyor can move sensitive and differently sized containers, boxes, or other packaging and item units to the loading or unloading point. It can also be used as a connecting section before or between production and processing machines. Furthermore, it enables efficient transport of parts within the facility and warehouse, and is suitable for conveying significant quantities and distances. Tailored solutions for your intralogistics We are your competent partner for roller conveyors, belt conveyors, inclined conveyors, or telescopic conveyors for loading and unloading your goods! We are happy to provide you with a customized offer or advise you on planning and installation matters. Just let us know your requirements and site conditions. Take advantage of our many years of experience and our excellent network of specialists. We have already successfully implemented projects for companies in various industries, such as logistics, the pharmaceutical industry, trade, or the electronics sector. Together, we will develop solutions to optimize your processes and material flow in a cost-effective and sustainable manner. We can also offer you fully automated sorting technology or additional components such as picking racks or containers. Kedpjd S Hkisfx Agrjdw

Sąlyga: labai geros būklės (naudotas), Dėl gabaritų, rezervuarai supjaustomi dalimis ir suvirinami mūsų specialistų kliento objekte. Kjdpfema Dgusx Agredw Aukštis – 4,30 m, Ilgis – 11 m Cilindras pagamintas iš AISI316 plieno, viršutiniai ir apatiniai gaubtai – iš dvigubo plieno (duplex), tačiau galima užsakyti ir iš AISI316 plieno. Suvirinimo darbų kaina derinama atskirai. Turime 2 vnt. Taip pat siūlome: 300 m³ talpos rezervuarą, matmenys 6,40 x 11,5 m, kaina 72 900 €; ir 2 vnt. 500 m³ talpos rezervuarų, matmenys 8 x 11,5 m, kaina – 108 900 €.

Sąlyga: paruoštas naudoti (naudotas), Gamybos metai: 2011, Liner paper min./max. feed width: 30mm/300mm, label roll diameter inner/outer: 76mm/280mm, container diameter min./max.: 25mm/210mm, pressing plate height: 120mm/200mm/300mm, conveyor belt width: 82mm/114mm/190mm, dimensions X/Y/Z: approx. 2500mm/1400mm/1500mm. Documentation available. Kodpfx Aget I Tz Iersdw

Gamybos metai: 2024, Sąlyga: naujas, mašinos/transporto priemonės numeris: 1234, Semi-automatic filling machine for soft packaging The semi-automatic filling machine BIB‘UP® is ideal for small to medium-scale production of soft packaging such as BIB (bag-in-box) with 2 to 20 liters and pouches with 1.5 to 3 liters. Also available without machine frame and without pump. Features: Three operating stages: removal of the fitting, cycle start (package air evacuation, counting and filling, injection, probing, nitrogen flushing at the end of the cycle), reinsertion of the fitting High working speed and performance Reliable, mobile, and very easy-to-operate filling machine BIB 3L bag: 280/290 cycles per hour 5L bag: 250/260 cycles per hour 10L bag: 200/210 cycles per hour 15L bag: 160/175 cycles per hour 20L bag: 140/150 cycles per hour Pouch 1.5L: 270 cycles per hour 3L: 245/250 cycles per hour Technical specifications: Kdodpfsiu Hxkex Agrjw Liquid throughput: 82 hectoliters/hour up to 0m (standard version), 125 hectoliters/hour up to 0m (optional) Air pressure min./max.: 5 bar / 8 bar Dry air supply: 7 to 10 bar Nitrogen supply: 1 to 4 bar Nitrogen pressure regulation: 0.2 to 0.4 bar Air flow rate: 7 m³/hour Power supply: 400V 3P+E, 50 Hz (standard version) Pulse counter: 75.3 counts per liter (standard version) Connection: 40 mm MACON diameter Noise level < 86 dB Space requirements: Depth: 1110 mm Height: max. 1770 mm Width: 745 mm Weight: 155 kg
