Šaltojo formavimo mašinos

NATIONAL M56 HSLS

Sąlyga: naudotas, Surface Grinding Machine BLOHM Type HFS 6 Serial No.: 10493 Year of Manufacture: 1973 Electro-magnetic chuck 600 x 300 mm Grinding length 600 mm Grinding width 400 mm Table longitudinal travel max. 650 mm Cross travel 350 mm Distance spindle center - table surface max. 600 mm Distance spindle center - magnetic chuck max. 517 mm Table clamping area 1020 x 300 mm Grinding wheel diameter 300 mm Grinding wheel width 50 mm Grinding wheel bore 76 mm Table longitudinal feed 2–30 m/min, stepless Table cross feed 2–65 mm, stepless, electric Cross rapid traverse 3 m/min Vertical feed 0.001 – 0.020 mm per feed pulse Vertical rapid traverse 0.250 m/min Grinding wheel speed 1400 / 2800 rpm Motor power hydraulic pump 2.2 kW Motor power grinding spindle 5 / 6 kW Electrical connection 380 Volt, 50 Hz Ffedped Hbafjfx Ab Set Total connected load 11 kW - Automatic depth infeed - Hydraulic table longitudinal movement - Grinding wheel dressing unit on the spindle head - Electromagnetic plate, construction height 83 mm - Side-mounted coolant unit with magnetic filter in the filter housing - Recirculating grinding spindle lubrication - Freestanding electrical cabinet (800 x 500 mm) - Swiveling control panel - Operating manual and spare parts list Space requirements L x W x H: 3000 x 2200 x 2100 mm Weight of surface grinding machine: 3000 kg Weight of control cabinet: 200 kg Good condition

Sąlyga: naudotas, Gamybos metai: 2005, Allgemeine Informationen: - Modell: ROBODRILL α-T2 STAMA - Seriennummer: 046VH155 - Baujahr: 2005 - CNC-Steuerung: FANUC (Modell A04B-0094-B111#BD) - Gewicht: 2.200 kg - Stromversorgung: 200 V, 50/60 Hz, Dreiphasenstrom - Leistungsaufnahme: 10 kVA ----- Bearbeitungsmöglichkeiten: - Arbeitsgänge: - Fräsen (High-Speed- und Hochpräzisionsfräsen) - Bohren - Gewindeschneiden mit starrer Gewindespindel ----- Verfahrwege: - X-Achse: ca. 500 mm - Y-Achse: ca. 400 mm - Z-Achse: ca. 330 mm ----- Spindel: - Spindelaufnahme: BT30 - Standard-Spindeldrehzahl: bis 10.000 min⁻¹ ----- Werkzeugwechsler: - Typ: automatischer Werkzeugwechsler - Werkzeugwechselzeit: ca. 1,6 Sekunden ----- Verfahrgeschwindigkeiten: Ffodpfsuru I Rjx Ab Sjt - Eilgang (X, Y, Z): 54 m/min ----- Hauptmerkmale: - Kompakte Bauweise für höchste Steifigkeit - Hohe Produktivität dank ultraschneller Bohr- und Gewindeschneidzylken - Wartungsfreundlich durch integrierte FANUC-Diagnoseschnittstelle - Kompatibel mit automatisierten Fertigungszellen (STAMA Co-Branding)

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 1977, Grinding diameter: 350 mm Grinding length: 1000 mm Centre height: 100 mm Grinding wheel diameter: 360 mm Total power requirement: kW Machine weight approx. 3.8 t Fodount Eyspfx Ab Seft Space requirements approx. 3.5 x 1.3 x 1.5 m Machine in very good condition! External and internal spindle. Extensive accessories included.

Gamybos metai: 1990, Sąlyga: dilaminuotas dirbtuvėje (naudotas), Tangential Surface Grinder Brand: Jakobsen Model: 1432 Year: 1990 Spindle speed: 1400 rpm Grinding area: 800 x 400 mm Table size: 1000 x 350 mm Maximum table load: 400 kg Maximum workpiece height: 475 mm Wheel size: 350 x 50 x 127 mm Equipped with Heidenhain ND 221B digital readout. Selter electronic magnetic chuck, 800 x 350 mm, with magnetization regulator. Maximum distance between table and wheel: 650 mm Fsdoiv S Avopfx Ab Seft MONNET brand filter, manufactured in 2007. Includes sets of grinding wheels (see photos).

Gamybos metai: 1979, Sąlyga: paruoštas naudoti (naudotas), Max. Schleifdurchmesser: 300 mm, Max. Schleiflänge: 1.950 mm, Max. Werkstücklänge: 2.000 mm Max. Vorschubgeschwindigkeit: 1–30 m/min Ffsdpfx Ashq Uigsb Sot Kühlmittelzufuhr: 100 l/min Stufenlos regelbarer Drehzahlbereich: 2.000–6.000 U/min Spindel: 88 mm Spitzenhöhe: 150 mm Schleifscheiben: 100–250 mm Spindelleistung: 3,5 kW Gesamtleistung Schleifmaschine: 15 kW – 380 V – 50 Hz

Sąlyga: naudotas, Gamybos metai: 2002, Funkcionalumas: visiškai funkcionalus, tekėjimo ilgis: 3 000 mm, sukimosi skersmuo virš skersinio stumduko: 520 mm, X ašies eiga: 600 mm, Y ašies eiga: 150 mm, Z ašies eigos atstumas: 3 150 mm, Sukimos skersmuo 520 mm Sukimos ilgis 3000 mm Valdymas SIN 840 D Siemens z ašis 3150 mm z ašies padavimo greitis 1 - 40 000 mm/min greitasis z ašies judėjimas 40,00 m/min Ffedpfx Aoxadk Djb Sot x ašis 600 mm x ašies padavimo greitis 1 - 30 000 mm/min greitasis x ašies judėjimas 30,00 m/min Pagrindinis velenas S1 Veleno apsukų diapazonas 1 - 3 300 aps./min Variklio galia prie 100% apkrovos 29,00 kW Veleno galvutė DIN 55026 - dydis A11 Veleno skersmuo prie priekinio guolio 160 mm Veleno kiaurymė 115 mm C ašis 360 x 0,001 ° Frezuojantis velenas S2 Įrankių tvirtinimas Capto C6 Apsukų diapazonas be pakopų 1 - 6 000 aps./min y ašis -100 / +150 mm B ašis -110 / +110 ° Įrankių magazinas 100 pozicijų Bendras galios poreikis 145 kW Staklių svoris apie 24 t

Sąlyga: naudotas, TECHNICAL DATA - Number of axes: 3 - Centre height: 175 mm - Distance between centres: 1000 mm LINEAR AXES - Grinding length: 500 mm - X x Z axis travel: 267 x 650 mm GRINDING SPINDLE HEADSTOCK - Continuous orientation: +/-8.5° - External grinding wheel dimensions: 500 x 80 x 203 mm - Wheelhead spindle power: 7.5 kW - Cutting speed: 44 m/s WORKPIECE HEADSTOCK - Taper type: MT5 - C-axis: +/-0.5° - Power: 1 kW - Rotational speed: 30-1,000 rpm TAILSTOCK - Taper type: MT3 - Quill stroke: 35 mm - Quill diameter: 50 mm - Max. workpiece weight between centres: 130 kg ELECTRICAL SUPPLY - Supply voltage: 400V 50 Hz - Machine dimensions: 2700 x 2350 x H. 2100 mm - Weight: 4,000 kg OPERATING HOURS - Operating hours: 17,775 h ACCESSORIES - CNC FANUC 16i-TA control - Pictogramming - Studer RELEASE C - Remote control with electronic handwheel - SENSITRON - Dynamic balancing unit Hydrobalance HBA 40000-1 - Automatic length probe MOVOMATIC C25 - In-process external diameter measuring arm MOVOMATIC - Grinding wheel guard with automatic tilting - Stationary diamond dressing device on workpiece headstock - Coolant tank: 375 l - Paper filter - Oil mist extraction Ffjdpfx Ajuhbydeb Set - Grinding wheel holder flanges

Sąlyga: labai geros būklės (naudotas), Neu 2008 Umlaufdurchmesser über Bett – 600 mm (Ø 23,62 Zoll) Drehdurchmesser × Bearbeitungslänge – Ø 300 × 600 mm (Ø 11,81 × 23,62 Zoll) Max. Drehdurchmesser – Ø 380 mm (Ø 14,96 Zoll) Max. Verfahrweg Z-/X-Achse – 600 / 240 mm (23,62 / 9,44 Zoll) Z-Achse: FANUC 2,8 kW (4 PS) / 3.000 U/min X-Achse: FANUC 2,8 kW (4 PS) / 3.000 U/min Spindelbohrung / Zugrohrdurchmesser – Standard: Ø 77 / Ø 52 mm (Ø 3,03 / Ø 2,04 Zoll); Option: Ø 86 / Ø 77 mm (Ø 3,38 / Ø 3,03 Zoll) Spindeldrehzahl – Standard: 8" Spannfutter 3.500 U/min; Option: 8" Spannfutter 4.500 U/min, 10" Spannfutter 3.500 U/min Spannfutter-Durchmesser – Standard: Ø 8"; Option: Ø 10" Hydraulischer Reitstock – Hub 465 mm (18,3 Zoll), MK 4 VDI-Werkzeugstationen – Option: 8, Standard: 10 Kühlschmierstoffanlage Späneförderer Anschlusswert – 208–220 Volt / 100 Ampere / 3 Phasen / 60 Hz Stellfläche (L × B × H) – 4.080 × 1.675 × 1.842 mm (160,62 × 65,94 × 72,51 Zoll) Ffedpfx Aborfx Tns Set Gesamtgewicht (ca.) – 5.200 kg (11.440 lbs)

Sąlyga: visiškai atnaujintas (naudotas), Gamybos metai: 1988,

Sąlyga: geras (naudotas), šlifavimo skersmuo: 1 600 mm, šlifavimo ilgis: 6 000 mm, Manufacturer: CINCINNATI Model: 60 x 216 Year of manufacture: 1970 Convex and concave grinding 6 steady rests included 2 hydrostatic steady rests Coolant system with magnetic filter Measuring system with 5-arm caliper: Arm 1: Working range 1300 to 1600 mm Arm 2: Working range 1000 to 1300 mm Arm 3: Working range 700 to 1000 mm Arm 4: Working range 400 to 700 mm Specifications Metric US Standard Centre height: 787 mm Grinding diameter Ø: 1574 mm Grinding length: 5800 mm Grinding wheel size: 914 x 101.6 x 304.50 mm Wheel speed: 1800 rpm Dimensions (approx.): Length: 15,100 mm Width: 5,500 mm Ffsdpfsvvvw Eox Ab Sst Height: 3,550 mm Weight: 120,000 kg Please note: The information on this page has been provided to the best of our knowledge and, where possible, obtained from the manufacturer. The information is given in good faith, but its accuracy cannot be guaranteed. Accordingly, no representation or contractual terms are implied. We recommend you verify all key details.
