Alzmetall Ax3 pirkti naudotą (141)

Būklė: naudotas, Gamybos metai: 1999, Outreach 290 mm Drilling stroke 160 mm Total power requirement 1.9 kW Description to follow! Bdsdpfxew En D Ue Aa Def

Būklė: naujas, ALZMETALL AX3/SV Column Drilling Machine NEW Manufacturer: Alzmetall Model: AX3 SV Condition: New Drilling capacity in steel: 40 mm Tapping capacity in steel: M24 Cast iron: M30 Short spindle: MK 3 Spindle stroke: 120 mm Working radius: 293 mm Column diameter: 115 mm Machine table: 515 x 360 mm Distance spindle to table: 117/701 mm T-slots: 2 x 14 x 224 mm Feed (per revolution): 0.1 + 0.2 mm Machine height: approx. 1840 mm Net weight: approx. 270 kg Drive: stepless (variable speed) Motor: 750/1500 rpm Power: 1.0 / 1.6 kW Spindle speed range: 80-1125 rpm Additional equipment: Bodpfx Aasy S Auzo Dsdf - Reversing switch - LED machine lamp - Tapping device - Coolant system B Available immediately from stock

Būklė: naujas, As a machinery dealer in Offenburg, we offer new and used ALZMETALL bench and pillar drilling machines. You can find an overview of our drilling machines on our website. If you have any questions, feel free to give us a call. Here we present the new series of ALZMETALL pillar drilling machines with TOUCH display: ALZMETALL AX3 iTRONIC-V Pillar Drilling Machine Condition: NEW Standard features: 7" TFT LCD display with touch function: - Manual input of target spindle speed - Actual speed display - Integrated drilling depth display with touch zero-point transfer - Virtual drilling depth scale in the display - Machine status and warning indicators on the display - Service information - Selectable operating language: DE/EN/FR/ES/IT/NL/RU - Stepless speed adjustment via adjustment lever - Spindle guard with electric safety interlock - Three separate buttons for clockwise, counterclockwise, and stop - Emergency stop mushroom push button (locking) - Lockable main switch - Clockwise and counterclockwise operation via contactor control - Control voltage 24 Volts - Protection class IP 54 - Coating: DD textured lacquer signal white RAL 9003, PANTONE 7545c, black Technical data: Manufacturer: ALZMETALL Type: AX 3 iTronic-V Drilling capacity steel E 335 (St 60) (mm): 40 Tapping capacity steel E 335 (St 60): M 24 Tapping capacity cast iron EN-GJL-200 (GG 20): M 30 Short spindle: MK 3 Spindle stroke (mm): 120 Usable throat (mm): 293 Column diameter (mm): 115 Machine table (mm): 515 x 360 T-slots (mm): 2 x 14 x 224 Bedey S Auuopfx Aa Dodf Distance spindle-table (mm): 117 / 701 Feed: 0.1 + 0.2 mm/rev Machine height (mm): approx. 1840 Drive: stepless Speed range (r/min): 160 - 2250 Motor (kW): 1.45 / 1.9 Weight (kg): approx. 270 Special equipment included: - Foot switch for tapping operation Further options available: - LED machine lamp - Coolant system B - On-screen technology calculator - Maximum drilling depth display Optional accessories: - Machine vice size 3/125mm BB type BON3 - Machine vice size 4/160mm BB type BON4 - Quick-release drill chuck Supra 1-13mm or 3-16mm MK3 Available at short notice. For self-collection. Forklift available. Shipping possible. Errors, modifications, and prior sale excepted. Didn’t find the right machine? Please feel free to contact us.

Gamybos metai: 2011, būklė: paruoštas naudoti (naudotas), Įvairūs metalo apdirbimo staklės, įskaitant didesnę radialinę gręžimo staklę Wagner, yra prieinamos. 1) Koloninė radialinė gręžimo staklė Wagner PRC 50, pagaminimo metai: 2011, gręžimo galia (plienui): 50 mm, veleno eiga: 315 mm, išsikišimo diapazonas: 350 mm–1600 mm, veleno atstumas iki pagrindo: 370 mm–1270 mm, sūkių dažnis: 2000 aps./min, staklių matmenys X/Y/Z: apie 2500 mm/1100 mm/2900 mm, svoris: apie 3500 kg. Staklės turi nežinomą gedimą. 2) Koloninė gręžimo staklė Alzmetall AX3/SV, pagaminimo metai: 2000, gręžimo galia (plienui): 32 mm, veleno eiga: 120 mm, išsikišimas: 293 mm, kolonos skersmuo: 115 mm, stalo matmenys X/Y: 515 mm/360 mm, sūkių dažnis: 2250 aps./min, svoris: apie 300 kg. 3) 2x metalo apskritiminės pjovimo staklės Macc NTM 350, pagaminimo metai: 1998/2010, disko skersmuo: 350 mm, pjovimo pajėgumas: 120 mm, svoris: apie 450 kg. 4) Juostinis šlifuoklis Grit A/S GIS 150, pagaminimo metai: 2014, juostos matmenys X/Y: 150 mm/2000 mm, variklio galia: 4 kW, svoris: apie 100 kg. Galima apžiūra vietoje. Pageidautinas paketininis pardavimas. Bedpfx Ajy Eqtioa Dedf

Būklė: geras (naudotas), Gamybos metai: 1995, Gręžimo našumas pliene (skersmuo) 40,0 mm Išsikišimas 293 mm Gręžimo eiga 140 mm Morzės kūgis 3, trumpa velena MK Stalas: 420 x 350 mm Sūkių skaičius 160–2250 aps./min. Kolonos skersmuo 115 mm Išsikišimas 293 mm Atstumas nuo velenos iki stalo, min. 117 / maks. 701 mm T-formos grioveliai 2 x 14 x 224 Bendras galingumo poreikis 1,45 / 1,90 kW Svoris 370 kg Užimamas plotas: apytiksliai 1200 x 800 x 1840 mm dabartinė nauja kaina ~ 12 500 eurų speciali kaina pagal užklausą Įranga: - tvirta kolona gręžimo staklė (klininis diržas) - bepakopė sūkių skaičiaus reguliavimas - grįžtamasis variklis - reguliuojamo aukščio darbo stalas * su 2 T-formos grioveliais - dešinė/kairė gręžimo velenos eiga (perjungiamas jungiklis) Bjdpfx Ajzl E Uuja Djdf - pagrindinis jungiklis su variklio apsaugos jungikliu - grybelio formos mygtukas (fiksuojamas) AVARINIAM SUSTABDYMUI - naudojimo instrukcija (PDF)

Būklė: naujas, Drilling capacity in steel St 60: 32 mm Drilling capacity in cast iron GG 20: 38 mm Boring capacity in St 60: 40 mm Thread cutting in ST 60: M 24 Thread cutting in GG 20: M 30 Short spindle: MK 3 Bdodpjyvvptsfx Aa Def Spindle stroke: 120 mm Throat depth: 293 mm Column diameter: 115 mm Machine table – usable area: 515 x 360 mm T-slots (number – width – spacing): 2 x 14 x 224 mm Distance spindle-table min./max.: 117 / 701 mm Feed: manual Spindle speeds – stepless: 160 – 2250 rpm Total power requirement: 1.45 / 1.9 kW Machine weight approx.: 260 kg Standard equipment: - Main switch with lockable motor protection switch - Mushroom-head emergency stop button (latching) - Stepless speed adjustment / digital speed display - Spindle guard with electrical interlock - Paint finish: DD textured lacquer Signal White RAL 9003, PANTONE 7545c, black Optional equipment: Pos. 12 LED machine lamp, with radially adjustable beam, connection power 230 V, protection class IP 65 Pos. 20.1 Tapping unit with foot switch for thread cutting with stop, max. 12 threads/min (thread cutting performance depends on spindle speed) Note: Spindle stroke is reduced by 15 mm Pos. 25 Coolant system B, comprising: separate reservoir (33 l), pump with motor protection switch, complete fittings, check valve Pos. 37.1 Digital drilling depth indicator, 0-point setting (drilling start), 5-digit LED display, character height 13 mm

Būklė: naujas, Drilling capacity in St 60: 40 mm Thread cutting in St 60: M 24 Thread cutting in GG 20: M 30 Spindle speeds – stepless: 160-2250 rpm Short spindle: MK 3 Spindle stroke: 120 mm Throat: 293 mm Column diameter: 115 mm Machine table – usable surface: 515 x 360 mm Distance spindle / table min./max.: 117/701 mm T-slots – quantity, width, spacing: 2 x 14 x 224 mm Feed: 0.1 + 0.2 mm/rev Machine height: 1840 mm Standard equipment: - Main switch with lockable motor protection switch - Mushroom-head emergency stop button (latching) - Stepless speed adjustment - Digital speed display - Feed overload protection - Protection rating IP 54 - Terminal board in control cabinet (no connection cable supplied) - Spindle guard with electrical interlock Special equipment: Item 12 LED machine lamp with radially adjustable light beam, connected load 230 V, protection rating IP65 Item 20.1 Thread cutting device with foot switch, for thread cutting with stop, max. 6 threads/min (thread cutting capacity depends on spindle speed) Bdsdpfx Asyvvq Dja Djf Item 25 Coolant system B, consisting of: separate tank (33 l), pump with motor protection switch, complete fitting Item 37.1 Digital drilling depth display Zero-point setting (drilling start), 5-digit LED display, character height 13 mm

Būklė: naudotas, mašinos/transporto priemonės numeris: 5961, galia: 1,3 kW (1,77 AG), įėjimo įtampa: 400 V, aukščio reguliavimo tipas: mechaninis, sukimosi greitis (maks.): 2 250 aps./min, sukimosi greitis (min.): 80 aps./min, bendras plotis: 600 mm, bendras ilgis: 1 000 mm, bendras aukštis: 1 800 mm, gerklės gylis: 293 mm, stalo plotis: 420 mm, stalo ilgis: 300 mm, bendras svoris: 280 kg, Įranga: sūkių greitis be galo kintamas, ALZMETALL AX 3 SV stulpinis gręžtuvas Techniniai duomenys / įranga: Gamintojas: ALZMETALL Tipas: AX 3 SV Serijos numeris: 5961 Verpstės tvirtinimas: MK 3 Verpstės eiga: 120 mm Išsikišimas: 293 mm Stalo matmenys: 420 x 300 mm Stulpo skersmuo: 110 mm Besiskaidė greičio reguliavimas: 80–2250 aps./min. (2 pavarų pakopos + 2 variklio pakopos) Automatinis padavimo mechanizmas: 0,1 / 0,2 mm/aps. Elektroninis verpstės apsaugos valdymas Avarinis išjungimo mygtukas Greitai užspaudžiamas gręžtuvo čiaupas Bedpfezi A Nkjx Aa Djdf Svoris: apie 280 kg Reikiamas plotas: 1000 x 600 x 1800 mm (ilgis x plotis x aukštis) Techniniai duomenys gali būti keičiami be išankstinio įspėjimo.

Gamybos metai: 1987, būklė: naudotas, 1 column drilling machine ALZMETALL AX 3SV, serial no. 5739, year of manufacture 1987 Bedpfx Aaji Apu To Dedf

Būklė: beveik kaip naujas (parodų įrenginys), Column Drilling Machine Manufacturer: ALZMETALL Model: AX 3s iTRONIC Condition: New machine Speed range: 100 – 1,800 rpm Bjdpfx Aaoiypz Eo Dsdf Standard equipment includes: - 7” TFT LCD display with touch function: Manual input of target spindle speed, Actual speed display, Integrated drilling depth display with touch zeroing function, Virtual drilling depth scale shown in the display, Machine status indicators and warning messages in the display, Service information, Selectable operating language: DE/EN/FR/ES/IT/NL/RU. - Tapping device - Infinitely variable speed adjustment via lever - Digital speed display - Three separate buttons for clockwise - counterclockwise - stop - Clockwise/counterclockwise control via contactor - Spindle guard - Operating manual Further key technical data: - 30 mm drilling capacity in ST 60 - 140 mm quill stroke - Spindle taper MT 3 - 115 mm column diameter - 1.0 / 1.6 kW motor power - 515 x 360 mm table dimensions With the following options: - LED machine lamp - Automatic spindle stop - Technology calculator on display - Workpiece counter

Būklė: naujas, Column Drilling Machine Bdedoh I N Trepfx Aa Dsf Manufacturer: ALZMETALL Model: AX 3 iTRONIC-V Year of Manufacture: 2023 Condition: New machine Speed range: 80 - 1,125 rpm Standard equipment includes: - 7” TFT LCD touch display: Manual input for target spindle speed, Digital display of actual spindle speed, Integrated drilling depth indicator with touch zero-point transfer, Virtual drilling depth scale on the display, Machine status displays and warning messages on the display, service information, Selectable operating languages: DE/EN/FR/ES/IT/NL/RU. - Tapping device - Infinitely variable speed adjustment via lever - Digital speed display - Three separate buttons for clockwise rotation, counterclockwise rotation, and stop - Direction control (CW/CCW) via contactor control system - Automatic feed with overload protection for the feed - Spindle guard - Operating manual Further important technical data: - 40 mm drilling capacity in ST 60 - 120 mm quill stroke - Spindle taper: Morse Taper 3 (MK 3) - 115 mm column diameter - Feed rates: 0.1 / 0.2 mm/rev - Motor power: 1.45 / 1.9 kW - Table dimensions: 515 x 360 mm With the following options: - LED machine lamp - Footswitch (additional, for use with tapping unit) - Technology calculator integrated into the display - Fine adjustment and fixed stop for drilling depth

Būklė: naujas, Pillar Drilling Machine Manufacturer: ALZMETALL Model: AX 3/SV Bjdpfeb Archox Aa Dsdf Condition: New machine Speed range: 80 - 1,125 rpm Standard equipment includes: - Stepless speed adjustment - Digital speed display - Feed overload protection - Spindle guard - Operating manual Further important technical data: - 40 mm drilling capacity in ST 60 - 120 mm quill stroke - Spindle taper MT 3 - 115 mm column diameter - Feed 0.1 + 0.2 mm/rev - 1.0 / 1.6 kW motor power - Table dimensions: 515 x 360 mm

Būklė: naujas, Drilling capacity in St 60: 40 mm Thread cutting in St 60: M 24 Thread cutting in GG 20: M 30 Spindle speeds – stepless: 160–2,250 rpm Short taper: MK 3 Spindle stroke: 120 mm Throat depth: 293 mm Column diameter: 115 mm Machine table – usable surface: 515 x 360 mm Spindle/table distance min./max.: 117/701 mm T-slots number – width – spacing: 2 x 14 x 224 mm Feed: 0.1 + 0.2 mm/rev Machine height: 1,840 mm Weight: 270 kg Standard equipment: - Lockable main switch Bdjdpfx Aaeyvvp Tj Def - Motor with thermal protection contact - Mushroom-head emergency-stop button (latching) - Right-hand rotation via contactor control - Infinitely variable speed adjustment - Digital speed display - Feed overload protection - Motor insulation class “F” (155°) - Terminal connections in control cabinet - Protection class IP 54 - Spindle guard with electrical interlock - Initial fill of machine oil: supplied in container, loose delivery Pos. 20.1 Thread cutting device with foot switch, for thread cutting with mechanical stop, max. 6 threads/min (thread cutting capacity depends on spindle speed)

Būklė: naujas, Drilling capacity in steel St 60: 25 mm Drilling capability in St 60: 30 mm Thread cutting in ST 60: M 16 Thread cutting in cast iron: M 20 Short spindle: MK 3 Spindle stroke: 140 mm Throat depth: 293 mm Column diameter: 115 mm Machine table – usable area: 514 x 360 mm T-slots – quantity/width/spacing: 2 x 14 x 224 mm Distance spindle to column min./max.: 132/724 mm Manual feed Infinitely variable drive Spindle speed: 225–4300 rpm Motor: 1.0/1.6 kW Operating voltage: 400 V Standard equipment: – 7" TFT LCD display with touch function: * Manual input of spindle speed (set value) * Actual speed display * Integrated drilling depth display with touch zero-point setting * Virtual axis on display * Machine status indicators and warning messages on display * Service information * Selectable operating languages: DE/EN/FR/ES/IT/NL/RU – Thread cutting unit for tapping with stop, max. 6 threads/min (thread cutting capacity depends on spindle speed), thread depth adjustable via depth stop and TFT LCD display (4 tools) – Infinitely variable speed adjustment using control lever – Spindle guard with electric interlock – Three separate pushbuttons for forward, reverse, and stop – Mushroom-type emergency stop button (latching) – Main switch, lockable – Forward/reverse operation via contactor control – Control voltage 24 V, protection class IP 54 – Finish: DD structured paint, signal white RAL 9003, PANTONE 4545c, black Special equipment: Pos. 20.5 Foot switch supplementing the tapping unit, for reversing spindle direction during operation Pos. 25. Coolant system B, consisting of: separate tank (33 l), pump with motor protection switch, complete fittings Bdodjyvvpgepfx Aa Def Pos. 37.5 Technology calculator on display The technology calculator guides users through the machining task by determining cutting data based on the following parameters: – Manufacturing process – Tool diameter – Cutting speed – Material table – Transfer function of spindle speed as set value

Būklė: naujas, Drilling capacity in steel (diameter): 40.0 mm Tapping capacity: M 24 Throat depth: 293 mm Drilling stroke: 120 mm Morse taper: 3 short spindle MK Table size: 515 x 360 mm Spindle speed: 80 – 1125 rpm Feed: 0.10 + 0.20 mm/rev Column diameter: 115 mm Distance spindle / table: 117 / 701 mm Total power requirement: 1.0 / 1.6 kW Weight: 270 kg Machine height: 1840 mm Bdsdpfx Aoxaar Rea Def Features: - Main switch with lockable motor protection switch - Mushroom-head pushbutton (latching) for EMERGENCY STOP - Infinitely variable speed adjustment - Digital speed display - Feed overload protection - Protection class IP 54 - Spindle guard with electrical interlock - Operating manual in German Including special equipment: - Tapping device Pos. 20.0 (tapping with stop) - Coolant system "B" Pos. 25.

Būklė: naujas, Drilling capacity in steel (diameter): 40.0 mm Throat depth: 293 mm Drilling stroke: 120 mm Morse taper: MT 3 Table: 515 x 360 mm Spindle speed: 80 – 1125 rpm Column diameter: 115 mm Thread M 24 ST60 Thread M 30 GG20 Feed rate: 0.10 + 0.20 mm/rev Distance spindle/table: 117 / 701 mm Motor power: 1.0 / 1.6 kW Weight: 270 kg Machine height: 1840 mm NEW ALZMETALL MODEL SERIES 7" TFT LCD display with touch function: * Target spindle speed * Actual speed display * Integrated drilling depth display * Touch zero point transfer * Virtual drilling depth scale on display * Machine status indicators and warning messages on display * Service information * Selectable operating language: DE/EN/FR/ES/IT/NL/RU Equipment: - Tapping device * for tapping with depth stop * max. 6 threads/min (tapping performance depends on spindle speed) * Thread depth adjustable via depth stop * in TFT LCD display (3 tools) - Stepless speed adjustment via adjustment lever - Automatic spindle feed with overload protection Bedpfxoxabyij Aa Dodf - Spindle guard with electrical interlock - Three separate push buttons for right rotation – left rotation – stop - Mushroom push-button (latching) for EMERGENCY STOP - Main switch, lockable - Right- and left-hand rotation via contactor control - Control voltage 24 V - Protection class IP 54 - Finish: DD texture paint Signal White RAL 9003, PANTONE 7545c, black - Initial machine oil fill: oil bottle supplied loose Including special accessories: - 25. Coolant system B.

Būklė: naujas, Drilling capacity in steel (diameter): 40.0 mm Throat depth: 293 mm Drilling stroke: 120 mm Morse taper: 3 MT Table: 515 x 360 mm Spindle speed: 160 - 2250 rpm Column diameter: 115 mm Thread M 24 ST60 Thread M 30 GG20 Feed: 0.10 + 0.20 mm/rev Distance spindle/table: 117 / 701 mm Motor power: 1.0 / 1.6 kW Weight: 270 kg Machine height: 1840 mm NEW ALZMETALL MODEL SERIES 7" TFT LCD display with touch function: * Set value display for spindle speed * Actual spindle speed display * Integrated drilling depth display * Touch-based zero point setting * Virtual drilling depth scale on display * Machine status displays and warning messages on display * Service information Bdodpfxjxab Nwe Aa Dof * Selectable operating language: DE/EN/FR/ES/IT/NL/RU. Features: - Thread cutting device * For tapping with stop * Max. 6 threads/min (thread cutting performance speed-dependent) * Thread depth adjustable via depth stop * Within the TFT LCD display (3 tools). - Infinitely variable speed adjustment via lever - Automatic spindle feed with overload protection - Spindle guard with electrical interlock - Three separate buttons for clockwise - counterclockwise - stop - Mushroom-head emergency stop button (latching) - Main switch, lockable - Clockwise and counterclockwise via contactor control - Control voltage 24 V - Protection rating: IP 54 - Paint: DD textured paint, signal white RAL 9003, PANTONE 7545c, black - Initial fill of machine oil: oil bottle supplied loose Including special accessories: - 25. Coolant system B.

Būklė: naudotas, High-Performance Drilling Machine ALZMETALL Type Abomat 20 Production Drilling Machine Serial No.: 452 Year of Manufacture: 1996 Drilling capacity in steel ST 60: 25 mm Drilling capacity in cast iron GG 20: 30 mm Spindle taper: SK 40 - M16 Arm length: 280 mm Drill slide stroke: 500 mm Distance spindle nose to table: 185 - 685 mm Table size: 490 x 400 mm Spindle speed: 50 - 500 rpm, stepless Drill slide feed: 20 - 224 mm/min, stepless Drill slide rapid traverse: 4.5 m/min Feed motor power: 0.18 kW Rapid traverse motor power: 0.75 kW Drill spindle motor power: 1.1 kW (speed: 1000 rpm) Power supply: 400 V, 50 Hz - Stepless spindle speed via frequency converter - Stepless drill slide feed via frequency converter - 2 operating modes: setup and automatic - Centralized lubrication - Control cabinet at the rear of the machine - Swivelling control panel - Mounted on steel plate (700 x 650 x 40 mm) with precision height adjustment Space requirement (L x W x H): 1200 x 700 x 2530 mm Bdedoikrtqspfx Aa Djf Weight: approx. 1000 kg Good condition

Būklė: geras (naudotas), Gręžimo galia 32 mm Verpstės tvirtinimas MK 3 Išsikišimas 290 mm Verpstės eiga 160 mm Stalo matmenys 510 x 300 mm Kolonos skersmuo 115 mm Pašarvas per sukamo rato mechanizmą Verpstės greitis 55–1450 aps./min., reguliuojamas be pakopų Variklio galia 0,9 ir 1,3 kW, galima perjungti polius Maitinimo įtampa 380 V, 50 Hz Verpstės greitis reguliuojamas dviem pavarų laipsniais, dviem variklio greičiais ir be pakopų per variatoriaus pavarą Stalo aukščio reguliavimas rankiniu būdu Nedideli įbrėžimai ant dangtelio (žr. nuotraukas) Bsdpfezp Nfxex Aa Dsdf Reikalingas plotas (ilgis x plotis x aukštis) 1200 x 650 x 1900 mm Svoris 400 kg

Būklė: geras (naudotas), Gamybos metai: 2015, Gręžimo našumas pliene (skersmuo) 40,0 / 50,0 mm Bdodeznng Ejpfx Aa Dsf Išsikišimas 300 mm Gręžimo eiga 160 mm Sūkių skaičius 100–1600 aps./min. Stalas: 615 x 430 mm Gręžimo veleno „Morse“ kūgis 4, trumpas velenas MK Stulpo skersmuo 145 mm Padavimas 0,1–0,2–0,3–0,4 mm/aps. Atstumas nuo veleno iki stalo 147 / 688 mm Variklio galia 1,8 / 2,9 kW Svoris 450 kg dabartinė nauja kaina apie 20 000 eurų speciali kaina – pagal užklausą Įranga: – tvirta stulpinė gręžimo staklė * Pavara: klininis diržas – VARIO – automatinis veleno padavimas * su elektromagnetine padavimo jungtimi * ir elektriniu kryžiniu valdymo rankenos perjungikliu – 4 padavimo greičio lygiai 0,1–0,2–0,3–0,4 mm/aps. – bepakopė sūkių skaičiaus reguliavimas – skaitmeninis sūkių skaičiaus rodiklis – polius perjungiamos krypties variklis – gręžimo veleno dešinės / kairės sukimo kryptis – veleno apsauga su elektrine apsauga – aušinimo skysčio sistema su atskiru bakeliu – naudojimo instrukcija (PDF)

Būklė: geras (naudotas), Funkcionalumas: visiškai funkcionalus, Data: Tool holder MK 5 Drilling capacity in ST60 steel 50 mm Infinitely variable speed ranges approx. 40 - 180 rpm + 180 – 800 rpm Bdjdpszp Dr Hofx Aa Djf 5 feeds 0.1 / 0.14 / 0.2 / 0.28 / 0.4 mm/rev Table surface 880 x 670 mm Throat depth: 385 mm

Būklė: geras (naudotas), Gamybos metai: 1972, Drilling capacity in steel: 70 mm Drilling capacity in cast iron: 80 mm Spindle taper: MT 5 Spindle throat: 400 mm Spindle stroke: 240 mm Column diameter: 250 mm Infinitely variable speed range: 45 – 1325 rpm 5 feeds: 0.1, 0.14, 0.2, 0.28, 0.4 mm/rev Bdodst Uzk Ropfx Aa Dsf Table size: 880 x 660 mm Motor power: 3 kW Dimensions (L x W x H): 880 x 1200 x 2500 mm Machine weight: 1400 kg Equipment / Special features: • Infinitely variable speed adjustment via PIV gearbox and intermediate gear • Large clamping table 880 x 660 mm • Feed via cross lever • Large drilling depth adjustment with end stop 240 mm • Swivelling table • Emergency stop switch • Coolant system Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Būklė: geras (naudotas), Gręžimo našumas pliene (skersmuo) 40,0 mm Išsikišimas 293 mm Gręžimo eiga 140 mm Morzės kūgis 3 MK Stalas: 510 x 360 mm Sūkių skaičius 160–2 250 aps./min. Bedpfxjzl E Uze Aa Djdf Stulpelio skersmuo 115 mm Bendrasis vardinis galingumas 1,45 / 1,90 kW Svoris 270 kg Matmenys (ilgis x plotis x aukštis) 500 x 800 x 1920 mm Įranga: - tvirta stulpelinis gręžtuvas - tolygiai reguliuojamas greitis (klininis diržas) - variklis, kurio sukimosi kryptį galima keisti - gręžimo gylio ribotuvas - staklių stalas su 2 T formos grioveliais * aukštis reguliuojamas rankiniu būdu - grybeliškas mygtukas (užfiksuojamas) AVARINIAM SUSTABDYMUI - perjungiamas jungiklis dešiniajai ir kairiajai sukimosi krypčiai - kojinis jungiklis dešiniajai ir kairiajai sukimosi krypčiai - naudojimo instrukcija (PDF)

Būklė: geras (naudotas), Gamybos metai: 1995, Gręžimo našumas pliene (skersmuo) 35,0 / 40,0 mm Išsikišimas 300 mm Gręžimo eiga 180 mm Sūkių skaičius 65,0–1750 aps./min. Stalo matmenys 615 x 420 mm Kolonos skersmuo 155 mm Pašarvas 0,1 / 0,2 / 0,3 mm/aps. Veleno tvirtinimas MK 4 Variklio galia 0,9 / 1,5 kW Svoris 450 kg Matmenys (ilgis x plotis x aukštis) 800 x 650 x 1850 mm Įranga: - tvirtas koloninis gręžtuvas - bepakopinis greičio reguliavimas (klininis diržas) - automatinis veleno pašarvas * su elektromagnetiniu įjungimu - poliaritetą keičiantis variklis - dešiniojo / kairiojo sūkio gręžtuvo velenas - gręžimo gylio fiksatorius - staklės su 2 T formos įpjovomis * aukštis reguliuojamas rankiniu būdu - AVARINIS STOP mygtukas priekyje Bdodpfozl E Uhex Aa Djf - naudojimo instrukcija (PDF)

Būklė: geras (naudotas), Gamybos metai: 1997, Gręžimo našumas pliene (skersmuo) 40,0 mm Išsikišimas 293 mm Gręžimo eiga 140 mm Morzės kūgis 3 MK Stalas: 415 x 350 mm Bdedpfxjzl E T Re Aa Dof Sūkių skaičius 160–2250 aps./min. Kolonos skersmuo 115 mm Bendrasis galių poreikis 1,45 / 1,90 kW Svoris 285 kg Matmenys (ilgis–plotis–aukštis) 500 x 800 x 1920 mm Įranga: - tvirta kolona gręžtuvas - bepakopė greičio reguliavimas (klininis diržas) - poliarizuojamas variklis - gręžimo gylio fiksatorius - staklių stalas su 2 T formos įpjovomis * aukščio reguliavimas rankiniu būdu - grybeliškas mygtukas (užfiksuojamas) AVARINIAM SUSTABDYMUI - perjungiamosios svirties jungiklis, skirtas gręžti į dešinę ir į kairę - naudojimo instrukcija (PDF)
