Darbo tvirtinimo sistema

Microloc MVB.6550

Būklė: beveik kaip naujas (parodų įrenginys), Gamybos metai: 2026, Centre height: 181 mm Centre distance: 1000 mm Maximum grindable workpiece diameter: 360 mm Maximum load, cantilevered: 1000 N / 100 kg Maximum load between centres: 3000 N / 300 kg Z-axis Table swivel range: 10° Table drive, hydraulic: 0–4 m/min X-axis Longitudinal travel (infeed spindle): 80 mm Rapid traverse (hydraulic): 50 mm Coarse adjustment (air cushion): 280 mm Infeed drive via DC motor Rapid infeed speed: 48 mm/min/Ø Infeed cycle: plunge grinding / longitudinal grinding 4 presettable feed rates: mm/min/Ø: 0.01–48 4 presettable infeed amounts: mm: 0.001–0.1 Spark-out during stop grinding: s: 0–99 / 0–99 strokes Jog infeed: mm/Ø: 0.001 Universal swivelling grinding spindle head: 0–180° Grinding wheel (external): D x width x bore: 500 x 100 x 127 or 203.2 mm Grinding wheel (face, optional): D: 250 x 32 x 76.2 mm Grinding wheel (internal, optional): D: (2–250) mm Drive power (external, face): 5.5 kW (7.5 kW) Drive power (internal): 2.2 kW Peripheral speed (external): 35 (50) m/s Grinding wheel wear (external): mm/Ø: 160 Guard width: 100 mm Grinding spindle diameter: 60 mm Internal spindle mounting: 80 (100) mm Workpiece spindle head: Infinitely variable drive: Mk 4, 1/min: 30–270 / 50–450 Workpiece spindle lockable Spindle mounting: MK 4/24 mm Spindle nose for flange attachment: MK 4, cylindrical Ø63H6 x 6 mm Workpiece headstock swivels on rotary part: 0–90° Tailstock: Quill mounting / quill diameter: MK 4 / 750 mm Quill stroke: 45 mm Gsdpjtqf Rzefx Ac Dsbk Quill force: 100–800 N / 250–1400 N adjustable Quill operation: manual (foot switch) Quill fine adjustment: ±40µ Connections: Total connected load: 6.5–10 kW Grinding spindle head: 5.5 (7.5) kW Workpiece spindle head: 0.55 (1.1) kW Coolant filtration: 0.75–2.2 kW Guideway lubrication pump: 0.1 kW Hydraulic pump: 1.5 kW Hydraulic tank: 80 litres Pneumatics: 6 bar Comparable to Weiss, EMAG, GP cylindrical grinding machines, Studer, Kellenberger, Schaudt, Tschudin, Tacchella, Dannobat.

Būklė: labai geros būklės (naudotas), Gamybos metai: 2001, veleno greitis (maks.): 10 000 aps./min, Spaustuvai nepridedami prie komplektacijos! Gedpfx Aexb Dyhjc Debk

Būklė: naudotas, TECHNICAL DATA - Distance between centres: 650 [mm] - Centre height: 175 [mm] - Max. workpiece weight between centres: 80 [kg] - Travel X/Z axis: 285 / 800 [mm] - X-axis programmable feed rate: [mm/min] - Resolution: 0.0001 [mm] - Z-axis programmable feed rate: [mm/min] - Resolution: 0.0001 [mm] - Table swivel range: 0 - 8.5 [degrees] GRINDING WHEEL HEADSTOCK - T1 grinding wheel dimensions: 500 x 63 x 203.2 [mm] - Speed: 50 [m/s] - Power: 9 [kW] - Manual swivel range: -15 / +195 [degrees] - Minimum resolution: 2.5 [degrees] Godpfx Aeylc R Uec Debk - Internal grinding speed: 40,000 [rpm] - Power: 3 [kW] WORKHEAD - Taper type: MT5 - Speed: 1 - 1500 [rpm] - Power: 1.8 [kW] - Bore diameter: 30 [mm] - Minimum C-axis resolution: +/- 0.5 [degrees] TAILSTOCK - Taper type: MT4 - Quill diameter: 50 [mm] - Quill stroke: 35 [mm] ELECTRICAL SUPPLY - Supply voltage: 400 [V] - Total connected load: 20 [kVA] WEIGHT AND DIMENSIONS - Footprint: 2,670 x 2,050 [mm] - Machine height: 1,900 [mm] - Machine weight: 4,000 [kg] MACHINE HOURS - Power-on hours: 190 [h] EQUIPMENT - Control: FANUC Oi-TD - Electronic handwheel - 3-color status lamp - Oil mist extraction system - Direct position measuring systems axes: X / Z - Dynamic grinding wheel balancing: MPM - Automatic touch detection: SENSITRON 6 - Fixed dressing device - Workpiece probe system - Coolant tank: 375 [l] * with paper filter

Būklė: geras (naudotas), Gamybos metai: 2000, Įranga: dokumentacija / vadovas, COLCHESTER TORNADO 200 LATHE FANUC GE Series CNC SELF-CENTERING CHUCK DIAMETER: 250 mm TRAVELS: X: 215 mm Z: 400 mm Gjdjtuut Uopfx Ac Debk TOOL TURRET: 12 POSITIONS INCLUDES VARIOUS TOOL HOLDERS AND ASSORTED TOOLS BAR CAPACITY: 65 mm PROGRAMMABLE TAILSTOCK CHIP CONVEYOR COMPLETE WITH ALL DOCUMENTATION

Būklė: naudotas, Gamybos metai: 1994, Cutting diameter: 520 mm Saw blade length: 7239 mm Cutting width: 1.3 mm Control: POSIMOD Cutting area (square): 520 x 520 mm Feed length: 500 mm Multiple feed length: 4500 mm Minimum cut-off length: 6 mm Residual piece length min./max.: 10 / 100 mm Cutting speed: 20 - 130 m/min Saw blade dimensions: 7239 x 50 x 1.3 mm Saw motor: 5.5 kW Total power requirement: 10.0 kW Machine weight approx.: 3.8 t Machine dimensions (L x W x H): 3.42 x 2.30 x 2.40 m Godpfswm Rm Iox Ac Debk - 2-column guided - Accessories: Infeed roller conveyor, 2500 mm long, chip conveyor, coolant system

Būklė: geras (naudotas), Gamybos metai: 1985, Dimensions L-W-H 400x300x200 mm Saw blade diameter 420 mm Machine weight approx. 3500 kg Manufacturer: KASTO Gjdpfjvf N Suex Ac Djbk Model: HBA 420U Year of manufacture: 1985 Dimensions (width x height x depth): approx. 400x200x300 cm Fully automatic NC horizontal band saw 1 chip conveyor, 1 external chip conveyor, 1 powered roller conveyor approx. 450 cm.

Būklė: paruoštas naudoti (naudotas), Gamybos metai: 2003, Weiler E50 x 1000 Precision Lathe (2003) Manufacturer: Weiler Model: E50 x 1000 Gbodpfxjyucf Rs Ac Dsk Year of manufacture: 2003 Condition: good, used, powered Operating hours: 43,000h Technical data: see images. Scope of delivery: - Original documentation - Rota S Plus 250-62 chuck - Steady rest - Parat 4-position tool turret

Būklė: naudotas, Grinding diameter: 250, 350, 450 mm Grinding length: 1000 mm Centre height: 125, 175, 225 mm Grinding wheel diameter: 400 mm Grinding wheel width: 50 mm Bore: 127 mm Workpiece spindle taper: MT5 Workpiece spindle speed: 20–400 rpm Workpiece headstock swivel range: 360° Grinding headstock swivel range: 180° ± Grinding spindle speed: 1500, 1700, 2200 rpm Gbodsuxftxjpfx Ac Dek Incremental infeed per stroke: 0.001–0.030 mm/Ø Continuous infeed: 0–0.95 mm/Ø Table swivel range: ±8° Longitudinal table travel: 1300 mm Table speed: 0.02–6 m/min Workpiece weight between centers: 130 kg Max. cantilevered workpiece weight: 130 kg incl. clamping Internal spindle mounting: 70 mm Total power requirement: 6.5 kW Machine weight approx.: 2.5 t Space required approx.: 4.2 x 2.0 m As a global leader in Kellenberger overhauls/retrofits, we not only deliver machines in as-new condition and with warranty, but can also provide service for your machines, including recently delivered machines, with additional options such as: - Splash guard doors - X-axis enclosure - Grinding headstock swivel angle display Available at extra cost. Geometrically overhauled and newly painted with original electrics. The machine features central lubrication and roller guides in the flat bed of the X-axis as well as pneumatic lift-off in the grinding headstock as standard. - Digital readout in 2 axes. X-axis resolution: 0.5 μm Options: - Rotary encoder with digital display in the workpiece headstock - Rotary encoder with digital display in the grinding headstock (no height adjustment with spindle possible) - New, robust internal grinding attachment, diameter 80 mm or 100 mm with height adjustment - Increased centre height up to a maximum of 225 mm - Variable speed control for the grinding spindle Includes: - Operating tools - Clamping tube for chuck Further accessories available on request. The machine tool does not currently comply with the basic safety and protection requirements as specified in the 2015 Industrial Safety Regulation (BetrSichV). The necessary minimum safety objectives must be determined by means of a risk assessment in accordance with BetrSichV.

Būklė: paruoštas naudoti (naudotas), Gamybos metai: 2009, veleno greitis (maks.): 2 500 aps./min, bendras aukštis: 1 785 mm, bendras svoris: 3 850 kg, ašių skaičius: 2, Šis "Weiler E50" pagamintas 2009 m. Tvirtos horizontalios tekinimo staklės, kurių pasukimo skersmuo virš lovio yra 570 mm, o suklio skylė - 83 mm. Staklių lovio plotis - 350 mm, o tekinimo įrankio skerspjūvis - 32 x 25 mm. Idealiai tinka tikslioms ir efektyvioms tekinimo operacijoms atlikti. Susisiekite su mumis ir gaukite daugiau informacijos apie šias stakles. Mašinos privalumai Kokybiškos mašinos privalumai • Priekinio guolio veleno skersmuo: 120 mm • Veleno kiaurymė: 83 mm • Pagrindinio veleno vidinis kūgis: metrinis 90 • Padavimo diapazonas išilginis ir plokštuminis: 0–20 mm/aps. • Išilginė padavimo jėga: 10000 n • Plokštuminė padavimo jėga: 7000 n • Įvesties greitis išilginis/plokštumas: 10/7 m/min arba 5/3,5 m/min • Metriniai sriegiai: 0,1–400 mm • Colinis sriegis: 1/4" - 56 g/1" • Modulio gijų skaičius: 0,125–28 Techninės mašinos privalumai • Pavaros galia (60 % / 100 % apsukos): 20/17 kw • Maks. Sukimo momentas ties besisukančiu velenu: 1600 nm • Pavarų dėžės etapas i: 1–625 min-¹ • Ii pavarų pakopos apsukų skaičius: 4–2500 min-¹ • Lovos plotis: 350 mm • Plunksnos skersmuo: 80 mm • Plunksnos eiga: 200 mm • Vidinis plunksnos kūgis: mk 5 Gjdpfx Aex D Ibboc Dsbk • Tekinimo įrankio skerspjūvis (aukštis/plotis): 32 x 25 mm • Veleno galvutė pagal din 55027: dydis 8 Papildoma informacija Staklės vis dar maitinamos / DP sriegiai: 1–224 / Fiksuoto atramos užspaudimo diapazonas: 12–150 mm / 120–270 mm / Judančio atramos užspaudimo diapazonas: 12–125 mm / Staklės efektyviai veikia vienos pamainos režimu nuo pat įsigijimo / Griebtuvas su kietais ir keliais minkštų žandikaulių komplektais ir uodegos atrama gali būti tiekiami kaip priedai / Visi susiję įrankiai gali būti aptarti užsakymo atveju / Staklės matmenys yra 2,8 m x 5,2 m, 2,8 m jau apima 600 mm kaip darbo vietą / Visos instrukcijos yra prieinamos. Dimensions Machine Depth 3250 mm

Būklė: naudotas, Gamybos metai: 1981, Cutting diameter: 320 mm Saw band length: 4670 mm Cutting width: 580 mm Total power requirement: 7.4 kW Machine weight approx.: 3 t Cutting range, round max.: 100 - 320 mm Rectangular max.: 100/100 x 320/460 mm Cut-off lengths min/max.: 0 - 580 mm Throat depth (stand to saw band) max.: 690 mm Infinitely variable cutting speed: 16 - 160 m/min Saw band dimensions L x Ø approx.: 4,670 x 38 mm Remnant piece length automatic/single cut: 100/10 mm Saw blade drive approx.: 4.4 kW Total drive: 7.4 kW - 380 V - 50 Hz Weight approx.: 3,000 kg Accessories / Special equipment: - Infinitely variable speed control of the saw band motor via actuator and STÖBER gearbox, with cutting speed display on the control panel - Infinitely adjustable saw feed with display of the current cutting speed - Piece counter with preset quantity selection, selector switch for single or multiple cuts - Indicators for band tension and feed rate - Automatic, motorised material feed, controlled via position processor type PP 160, input of required lengths; supplied with roller conveyor approx. 1,500 mm (extendable to approx. 2,000 mm) and a more stable roller conveyor approx. 3,500 mm for outdoor use - Integrated chip conveyor with coolant system - Attached control cabinet Condition: Good – ready for demonstration shortly Delivery: Ex stock – as inspected Gedpfx Ajt Hwrnoc Dobk Payment: Net – upon receipt of invoice We look forward to your order. Further saws available from stock – please enquire.
