Hidraulinis presas

Kojima 1000ton

Sąlyga: naudotas, Description: Main Spindle: Technology: Belt-driven spindle with gearbox Speed: 1,000 rpm Power: 45 kW Torque: 4,008 Nm Bar Capacity: 205 mm Workpiece Clamping I: 3-jaw chuck, Autogrip AP-230 ø535 mm Workpiece Clamping II: Manual 3-jaw chuck, Chandox SK20 (rear of the spindle head) Tool Turret (X/Y/Z): Technology: 12-station turret Tool Interface: BMT 75 Driven Tools: 3,000 rpm, 7 kW, 83 Nm Travel in X/Y/Z: 340/160/3,250 mm Rapid Traverse in X/Y/Z: 20/7/12 m/min Tailstock: Technology: Programmable quill, dragged tailstock Ndsdpfowt Iwqjx Ac Asd Stroke: 150 mm Taper: MT5 Equipment/Accessories: Chip Management: Chip conveyor Coolant Management: High-pressure coolant pump (IKZ) Tool Measurement: Measuring arm, Renishaw RP3 Oil Mist Extraction: Mechanical separator, manufacturer AR Filtrazioni ARNO 3VF YF Shaft Machining: Manual steady rest, ø150-300 mm Tool Holders: Various fixed and driven holders Setup Operation: Electronic handwheel Additional Features: Automatic door (pneumatic), transformer, oil skimmer Other Accessories: Various jaws and EWS quick-change adapters

Sąlyga: naudotas, Gamybos metai: 1988, aukščio reguliavimo tipas: hidraulinis, 1x Used KAHL C39 - 1000 Pellet Mill Including hydraulic nut Including 4-roller head Including 5-roller head Including various spare parts Including base frame 110kW 1500rpm electric motor Nodpfxsv N Rdas Ac Aodd

Sąlyga: naudotas, Gamybos metai: 1981, Plokštuminio disko skersmuo: 3200 mm Apdirbimo skersmuo: 5100 mm Sūkių aukštis: 2505 mm Skersinio balkio reguliavimas: 1500 mm Didžiausias stūmoklio eiga: 1250 mm Atramos reguliavimas: 2000 mm Valdymas: Siemens 8 T Įrankių keitiklis: 16 vnt. Stalo apkrova: 60 t Plokštuminio disko sukimosi greičio diapazonas (be pakopų): 0,8-100 aps./min Padavimas: 0,0 mm/min Greitaeiga: 6000 mm/min Pagrindinio veleno pavaros galia: 75 kW Staklių svoris apie 70 t Reikalinga erdvė apie 9,3 x 6,1 x 6,0 m Ndjdpfx Aeu Sbdgjc Aod Staklės puikios būklės! Pageidaujant staklės gali būti pristatytos su nauja elektros įranga, įskaitant Siemens CNC valdymą SINUMERIK 840D sl. Modernizavimą atliks specializuota įmonė, suteikiama 12 mėn. garantija dalims ir 6 mėn. personalo aptarnavimui.

Sąlyga: naudotas, Gamybos metai: 1995, Wheel diameter - max. 80 mm Wheel width 120 mm Module - max. 3 Module - min. 1 Control: SIEMENS 840 C Total power requirement: 30 kW Machine weight approx. 7,500 kg Footprint approx. [space missing] m LIEBHERR CNC-controlled gear hobbing machine Type: LC 82 Year of manufacture: 1995 # 0836 --- Wheel diameter max. 80 mm Module 1 – 3 Helix angle +/- 45° Distance table center to tool center: 15 – 160 mm Vertical travel of milling slide: 250 mm Shift range/tool traverse: 180 mm Min. number of teeth: 3 Nsdpfet Hw R Dex Ac Asdd Cutter Ø x length approx.: 90 x 200 mm Cutter speeds up to max.: 800 rpm Feeds in axial/radial/tangential: 20/4/5 mm/rev Max. workpiece clamping length: 250 mm Spindle drive approx.: 8 kW Total drive approx.: 30 kW - 400 V – 50 Hz Total weight approx.: 7,500 kg Accessories / Special equipment: • SIEMENS CNC control type 840 C for 6 axes (i.e. cutter drive/Table drive/Swivel angle of the milling head/axial feed/radial feed/tangential feed) with gear-specific user interface and diagnostic functions for rapid troubleshooting. • With device for automatic insertion of the hob into the tooth gap • Automatic shifting of the cutter axis • Automatic workpiece loading unit SSL = quick swivel loader using a mechanical step transmission and cam disk for fast loading times, with 3-way rotary gripper for blank gripping/working position/unloading. Current workpiece size Ø 30 x 120 mm, helical gearing (pinions) • Workpiece feeding by means of plate chain conveyor (PKB) for workpieces with positive-fit carrier. Additional feed belt for raw and finished parts • Chip conveyor, complete working area enclosure, intermediate coolant tank with pump Complete working area enclosure with sliding door and oil mist extraction, etc. The machine can also be used for dry gear cutting. Condition: satisfactory to good – under power and ready for demonstration, compact design! Delivery: ex-stock – as inspected Payment: net cash – on receipt of invoice

Sąlyga: naudotas, Gamybos metai: 1980, Wheel diameter – max. 2,500 mm Wheel width 1,200 mm Module – max. 32 Module – min. 3 Total power requirement 25 kW Machine weight approx. 60 t Space requirement approx. __ m Year of manufacture: 1980 Overhauled: 1990 Wheel Ø min./max. 180 – 2,500 mm Module 3 – 32 Maximum helix angle 10 – 35° Wheel width for spur gearing 1,200 mm Stroke length approx. 100 – 1,200 mm Number of strokes 80 – 350 strokes/min Adjustable stroke position 300 mm Stroke speed 4–40 m/min Ndodpfot Hwqqsx Ac Asd Max. workpiece weight approx. 18,000 kg Max. number of teeth 16–576 Table size Ø x bore 1,400 x 500 mm Grinding wheel Ø approx. 500 mm Grinding wheel peripheral speed 34 m/s Total drive approx. 25 kW – 380 V – 50 Hz Weight approx. 15 t Accessories / Special features: • Hydrostatic guides on the grinding slide, table, and all other guideways • Complete grinding enclosure with sliding doors • Automatic grinding cycle in multiple passes as well as settings for roughing, finishing, fine finishing, and automatic dressing cycle after preset number of teeth • Profile correction possible by corresponding dressing and additional movement of the grinding slide (crown and flank correction in height and side) • Approx. 50 change gears, angle measuring device • Large coolant system with band filter and oil mist extraction • Separate control cabinet, separate hydraulic unit, separate oil cooling system

Sąlyga: naujas, Working area approx. 360 mm Working area (quadrant) 360 x 360 mm Working area (bundle) W x H 180 - 280 x 50 - 160 mm Cutting speed 20 - 100 m/min (stepless adjustment) Saw band dimensions 4,420 mm x 34 mm x 1.1 mm Saw band tension hydraulic Multiple feed 500 mm Drive power 3.7 kW Machine size L x W 2,500 x 2,200 mm Machine weight 2,300 kg Standard equipment - Hydraulically controlled full-stroke double-vice clamping system - Drive via IE3 motor with inverter (PMSM, equivalent to IE4) - User-friendly NC touch screen control with high-end system (NCIII CONTROL) - Display of feed rate on HMI (10" HMI screen) - Automatic chip conveyor - Automatic shuttle feed - IC board control for all electrical and hydraulic functions - Floating pendulum vise - Split front vise - Stepless speed control via inverter - Hydraulic blade tension - Roller bearings with hydraulically controlled carbide blade guide system - Automatic work height control via quick-start sensor - Preset cut counter with auto shut-off - Nesting device for bundle cutting (hold-down device) - Power-driven blade cleaning brush Nodpfx Ajqrqvhjc Aodd - Saw band monitoring for standstill and blade breakage - Rinse hose for machine cleaning - Work light - Roller table, 2 m in length - One M42 bimetal saw blade - One set of tools and a toolbox

Sąlyga: naudotas, Toolholder Interface Type: HSK-A 100 Nedpfsg Nqliox Ac Asdd Toolholder Type: Wohlhaupter Toolholder Type: Fine Boring Tools, Boring Head / Precision Turning Wide selection of Wohlhaupter HSK-A 100 toolholders, boring heads, adapters, and extensions available for sale. Itemized list with prices will be provided upon request.

Sąlyga: naudotas, Gamybos metai: 2006, CNC Heidenhain TNC530 X/Y/Z travel: 1,500/800/1,000 mm Swivel axis: 0-180° A-axis C-axis B-axis Max. workpiece weight: 1,500 kg Machine weight: 18,000 kg Ndodpswutxijfx Ac Ajd

Sąlyga: dilaminuotas dirbtuvėje (naudotas), Gamybos metai: 2015, Funkcionalumas: visiškai funkcionalus, X ašies eiga: 10 000 mm, Y ašies eiga: 3 000 mm, Z ašies eigos atstumas: 1 500 mm, greitas poslinkis X ašimi: 25 000 m/min, greitas poslinkis Y ašis: 25 000 m/min, greitasis eiga Z ašyje: 25 000 m/min, veleno greitis (maks.): 4 000 aps./min, RepairFIT+ by Dornhöfer The Difference. Including installation & commissioning! TECHNICAL MAIN DATA Year of manufacture: 2015 Capacities / Travel distances: Longitudinal (X): mm 10,000 Vertical (Y): mm 3,000 Cross (Z): mm 1,500 Paintwork: graphite grey RAL 7024 / agate grey RAL 7038 Tool holder: ISO 50, DIN 69871 AD Pull stud: DIN 69872 Type A Taper: DIN 69871 Main drive: Motor / Make: Siemens main spindle drive Type 1PH7 Maximum drive power: from 198 rpm 100% duty cycle 41 kW Maximum torque: Constant up to 198 rpm 100% duty cycle 1,920 Nm Speed control / Gearbox: 3-stage (oil-cooled) with automatic changeover Spindle speeds 4,000 rpm: Low range rpm: 0 – 516 Medium range rpm: 460 – 1,288 High range rpm: 1,200 – 4,000 Axis drives / Feed rates: Axis drive motors: Rapid traverse max.: (X/Y/Z axis) 25,000 mm/min Feed rate max.: (X/Y/Z axis) 15,000 mm/min Feed force max.: (X axis) 35,000 N (Y/Z axis) 32,000 N Axis drive systems: X axis (longitudinal): Pinion / rack (Make: Atlanta) Y axis (vertical): Pre-tensioned ball screw Ø 63 x 20 Z axis (cross): Pre-tensioned ball screw Ø 50 x 20 Weight: (without clamping table / plate field) approx. 49,500 kg Power supply: approx. 60 kVA Innotrol HBG wireless handwheel Automatic tool changer with 60 magazine slots BIG Plus tool spindle Operator platform, height-adjustable by 1,800 mm and cross-travel by 800 mm Interface for adapter milling heads Njdpfxov R Hwro Ac Ajdd What does RepairFIT+ mean? With RepairFIT+ we offer you a profitable and safe entry to our product lines. Our machines undergo a strict selection process, are subject to a thorough deep-dive inspection and receive intensive cleaning from our experts. All identified defects, both technical and cosmetic, are professionally repaired to ensure the machine is delivered in excellent condition.

Sąlyga: paruoštas naudoti (naudotas), Gamybos metai: 2000, Funkcionalumas: visiškai funkcionalus, GEBRAUCHTE Taiwan Takisawa EX-108 Hochleistungs-CNC-Drehmaschine mit 2 Achsen. Seriennummer: CA11E80453, Baujahr 2000. HINWEIS: Dies ist ein 2-Achsen-Modell EX108, KEIN 3-Achsen-Modell EX308. • Schwere Schrägbettkonstruktion aus Gusseisen • Fanuc 21iT CNC-Steuerung • 4-fach Schwerlast-Linearführungen • Hochgeschwindigkeits-Servorevolver • Werkzeugmesseinrichtung • 8" 3-Backen-Hohlspannzylinder mit hydraulischem Futter • Stückzähler • Werkzeughalter inklusive Max. Umlaufdurchmesser über Bett: 400 mm Max. Umlaufdurchmesser über Support: 320 mm Spitzenweite: 645 mm Standard-Drehdurchmesser: 216 mm Max. Drehdurchmesser: 320 mm Max. Drehlänge: 530 mm Stangendurchlass: 52 mm X-Achsen-Verfahrweg: 180 mm Z-Achsen-Verfahrweg: 530 mm Spindeldrehzahl: 60–4000 U/min Spindelaufnahme: A2–6 Ndsdpst E Hvgsfx Ac Ajd Spindelbohrung: 63 mm Revolverkopf: 12-fach Reitstock-Verfahrweg: 435 mm Reitstockpinolenhub: 100 mm Reitstockpinole, Konus: MK 5 Eilgang (X & Z): 20 & 24 m/min Rücklaufvorschub (X & Z): 0–1260 mm/min Spindelmotor: 7,5 / 11 kW Elektrik: 415 V, 3 Phasen, 50 Hz Aufstellfläche: 2240 mm x 1645 mm Maschinengewicht: 4300 kg
