Paviršiaus šlifavimo staklės

JUNG JF 600

JUNG JF 600
Surface Grinding Machine Jung JF 600 Year of Manufacture 1996 Overhauled 2018 Excellent CONDITION
This machine comes from the training workshop of a renowned German mechanical engineering company.
Technical Data:
Year of Manufacture: 1993 / 2018
Technical Specifications:
Table Length: 600 mm
Table Width: 250 mm
Axis Travel:
Longitudinal Travel (X-axis): 600 mm
Cross Travel (Z-axis): 280 mm
Maximum Distance between Table and Spindle Center: 500 mm
Grinding Length: 600 mm
Table Speed:
Continuously variable from 1 m/min to 24 m/min
Creep Feed: from 0.03 m/min to 0.40 m/min
Automatic Cross Feed:
Gedpoyxdalsfx Af Deua
Continuously variable from 0.010 mm/min to 10,000 mm/min
Connection 50 Hz 3x: 380 Volt
Grinding Spindle Motor: 9.5 kW
Total Power Requirement: 13 kVA
Machine Weight approx.: 2,500 kg
Machine Dimensions:
Length: 2,910 mm
Width: 2,320 mm
Height: 1,840 mm
Various Accessories:
Coolant system
About the Machine:
For sale is a Jung JF 600 surface grinding machine. This universal surface grinding machine is in excellent original condition. It comes from an operation where it was only used occasionally for training purposes. The machine features a very user-friendly control system. A grinding travel of 600 mm on the longitudinal axis as well as a cross travel of 300 mm make it particularly suitable for toolmaking, fixture construction, and small batch production. Its comprehensive standard equipment and easy operation distinguish this machine series. The robust spindle head and the double V-guideways in both longitudinal and cross axes ensure long-lasting precision. The intuitive layout of the controls simplifies operation and significantly increases productivity. The guideways are regularly lubricated via central lubrication. The Jung has been mechanically and electrically inspected by us. Take the opportunity to view and test the Jung machine under power at our premises. More surface grinding machines from well-known manufacturers can be found on our website.
