Briketavimo presas

Aymas Recycling Machinery BP 80 Chip Briquetting Press

Sąlyga: geras (naudotas), Gamybos metai: 2007, Funkcionalumas: visiškai funkcionalus, gręžimo gylis: 1 150 mm, bendras svoris: 12 000 kg, gręžimo skersmuo: 32 mm, Heidenhain iTNC530 CNC control 12-position tool changer Technical specifications: Kedpowcldajfx Af Ijdg Travels: X-axis longitudinal (table): 1800 mm Z-axis transverse (column): 1700 mm W-axis transverse (drilling unit): 1150 mm Y-axis vertical (drilling unit): 1200 mm B-axis (rotary table): 360° A-axis (drilling unit): -25° to +15° Deep drilling area (ELB): Diameter range: 6–32 mm Max. drilling depth: 1150 mm Drive power: 40 kW Approximate machine weight: 12,000 kg Technical data, accessories, and machine description are not binding. For further technical data, refer to the photos.

Sąlyga: naudotas, Gamybos metai: 2018, System: Decanter Model: Flottweg C4E-4/454 Complete Dewatering Unit in Container Year of manufacture: 2018 Sludge throughput: approx. 0-40 m³/h Solids capacity: max. 1.2 t DS/h Equipment: double doors on face side, side entrance door, fan heater, lighting, power sockets, etc. Bowl: max. rotational speed 3,650 rpm Bowl diameter: 470 mm System: Containerized unit with swap body system for integration of subsequent plant components. Fully piped and wired, operational as a functional unit. Container unit design: Frame construction, clad with sandwich panels and fittings for swap body system transport. Accessories: FHM PolyMix 4000SP polymer make-up station, measurement equipment, control panel Feed pump: Seepex BN 52-6LS Discharge conveyor: Double trough screw conveyor SS D320 Dimensions: L 7,820 mm x W 2,500 mm x H 3,880 mm Empty weight: 14,500 kg Operating weight: 15,000 kg Voltage: 400 V Current consumption: 142 A Maximum power consumption: 70 kW Kodpfx Aou R Icmef Iodg Fuse protection: 250 A Frequency: 50 Hz Sludge inlet: DN 100 Centrate outlet: DN 200 Solids discharge: Screw conveyor Further information: see photos.

Sąlyga: naudotas, Gamybos metai: 2003, Technical Details: Pressure: 40 t Box opening: 1200 x 730 mm Material: Cardboard, plastic – cardboard bottles Kodpsu Nw Ezofx Af Ijdg Voltage: 400 / 50 V / Hz Total power requirement: 16.4 kW Transport dimensions (machine): 6.5 x 6.2 x 2.7 m Fully automatic hydraulic CHANNEL BALER for recycling with feed unit/conveyor belt LxW: 4500x1000 mm, motor-driven with automatic 3-fold tying unit Bale counter/indicator Press chamber LxWxH: 1800x800x800 mm with 1.2 m³ volume Bale size LxWxH: 300–1500 x 800x800 mm Bale weight: 250 – 450 kg depending on material and bale length Filling opening LxW: 1200x730 mm, filling height 1200 mm Hopper size LxWxH: 1200x1200x1400 mm; filling height 2500 mm

Sąlyga: labai geros būklės (naudotas), The SB-10 grinding machine enables precise grinding of boring bars, threading tools, grooving tools, or boring bar steels in HSS or carbide for jig boring machines or lathes. By applying the correct rake angle adapted to the respective material, you achieve optimal efficiency and longer tool life. Nowadays, these boring bar tools are mostly ground by hand before being used on high-quality machine tools. On the SB-10, steels are ground with a profile-grinding wheel mounted on the circumference. The profile is easily achieved using a dressing diamond and a template attached to the machine. For excellent stability and surface finish, the horizontal slide is mounted on cross-roller guideways. Grinding wheel (ØxWxB): 125 x 20 x 20 mm Kodpfx Afsfqicxj Isdg Speed: 2800 rpm Longitudinal adjustment: 130 mm Cross adjustment: 80 mm Height adjustment: 65 mm Rake angle: +25° to -10° Dimensions (WxDxH): approx. 550 x 450 x 650 mm Weight: approx. 70 kg

Sąlyga: naudotas, Gamybos metai: 2006, Technical Details: Maximum bending angle: 75° Working height: 850 mm Operating voltage: 380 V Machine weight approx.: 1.0 t Machine dimensions (LxWxH): 1.9 x 2.6 x 1.0 m Transport dimensions: 2.6 x 1.8 x 1.0 m Kdjdsu Ibu Ropfx Af Isg Single and double bending of reinforcing steel possible. Number of bending formers: 2 units Bending angles: 40°; 60°; 75° Bar diameter: Single bend = Ø 12–50 mm, Double bend = Ø 12–35 mm Operation via control panel with touch screen Bending table: - Ø 480 mm - Rotational speed: 7.5 / 15 rpm - Bending pin hole: Ø 48 mm (16 positions) - Center pin: Ø 50 x 94 mm Counter-holder bars: - 2 units, length = 840 mm - Manual travel adjustment: 100 mm - 13 holes, size Ø 48 mm Accessories: Bending attachments: 2x Ø 60 mm; 2x Ø 78 mm; 1x Ø 96 mm; 1x Ø 122 mm; 1x Ø 160 mm; 1x Ø 200 mm 1x pin for table 8x counter-holders, various shapes 1x bending tray

Gamybos metai: 2024, Sąlyga: naujas, Zigzag Air Separators Application Description: The ZIGZAG type air separator is a machine designed for cleaning materials in recycling processes. The separator pneumatically separates light fractions from heavy ones. It is suitable for a wide range of waste materials sized 0-150 mm. This type of air separator is used for pre-shredded, shredded, or very fine materials. Thanks to our unique design, the separator provides multi-point adjustment at critical locations to ensure high purity of recovered fractions. Kdjdpfxjua D Alo Af Iog ZIGZAG separators are utilized in various fields: - Weight-based classification of metal granulates - Cleaning shredded scrap from light fractions (films, plastics, paper) - Removal of floating/light fractions during WEEE recycling - Cleaning plastics and rubber - Cleaning municipal waste and glass - Dust removal Construction Description: The ZIGZAG separator consists of several components mounted on a common support frame. The first section features the ZIGZAG module, equipped with an inspection hatch and adjustable feed gap for material flow. The second section houses the cyclone, which extracts the light fraction. Beneath the cyclone is a variable-speed rotary airlock for discharging the separated materials. At the top of the assembly, there is a fan with electronic speed control. The design is partially adapted for belt conveyor loading and unloading. The separator is fitted with a control cabinet with a safety system.

Sąlyga: naujas, The SSB F 60 Super VT PRO is a powerful column drilling machine, perfectly suited to the demands of workshop applications. This machine combines modern technology with robust design—ideal for single-part and small-batch production, as well as for drilling, countersinking, reaming, and thread cutting. Featuring electronically controlled servo quill feed and a large touchscreen operating display, operators benefit from user-friendly controls and flexible adjustment of processing parameters. Its stable construction from high-quality cast iron and a motorized, height-adjustable table that can be swiveled ±45° make the SSB F 60 Super VT PRO an excellent choice for structural steel and industrial hall fabrication. Additionally, the machine offers an impressive drilling capacity of up to 60 mm and an automatic thread-cutting cycle, optimizing efficiency. Take the opportunity to acquire the SSB F 60 Super VT PRO for your projects—request a quote and experience KNUTH quality firsthand! Kjdpfx Afeq Rdqne Isdg

Gamybos metai: 1972, Sąlyga: geras (naudotas), Power generator, emergency generator, generator set, genset, electricity generator, power generator, backup generator, power generation unit - Manufacturer: PILLER/MWM - Output: 730 kVA 50 Hz - Engine: MWM type TbRHS 518V16, output 850 HP, speed 1500 rpm - Generator: PILLER NKTB 4-1158 Kodpfjivql Isx Af Iodg - Note: without control unit - Individual components: see photos - Transport dimensions: 6 loading meters - Total weight: 8600 kg

Sąlyga: beveik kaip naujas (naudotas), Gamybos metai: 2023, veikimo valandos: 3 000 h, Funkcionalumas: visiškai funkcionalus, Parduodamos mobilios Lefort metalo laužo žirklės. Įrenginys labai geros būklės, galima apžiūrėti bet kuriuo metu. Kdsdex Elyaspfx Af Ieg

Sąlyga: naujas, Gamybos metai: 2025, Working width: 400 mm Working height: 300 mm Minimum workpiece length: 250 mm Units: 2 brush units, individually adjustable Brush lift height: 25 mm with pneumatic damping 1st brush: Metal brush, diameter 220 mm 2nd brush: Tynex brush, grit 80, diameter 220 mm Reversible direction: for both brushes Height adjustment: Handwheel Height display: Mechanical counter Feed speed: 4 - 12 m/min Brush motor power: 2 x 3 kW Feed motor power: 0.37 kW Machine length: 1400 mm Kdjdpfx Aoi Ezrzjf Ijg Machine width: 900 mm Weight: 500 kg
