Universalus apdirbimo centras

Z-MaT U630 5-Achs simultan Siemens ONE

Z-MaT U630 5-Axis Simultaneous Machining Center
Csdpswku Evjfx Ahvshc
Siemens ONE, 15" LCD Screen
Double Torque Direct Drive

Travel (X/Y/Z): 750 / 800 / 600 mm
Rapid traverse (X/Y/Z): 36 / 36 / 36 m/min
Feed rate: 1-10,000 mm/min

Spindle
Spindle speed: 18,000 rpm, built-in
Spindle taper: HSK63 (HSK100)
Spindle motor: 30 kW, Siemens
Air blast through spindle
Spindle air curtain
Spindle oil cooler
Double arm tool changer, 30 tools (40/60/200 optional)
Max. tool weight: 8 kg
Max. tool length: 300 mm
Max. tool diameter: 75/120 mm

Table
Table diameter: Ø 630 mm
Max. workpiece diameter: 650 mm
Max. table load: 850 kg
T-slot (width x number x pitch): 18H8 x 7 x 80 mm
Distance spindle center to table surface: 120-720 mm
A-axis travel (tilting): +/-120°
C-axis rotation: 360°
Max. rapid traverse A/C axes: 60/100 rpm
A/C axes encoder

Standard Equipment
End-of-operation lamp, 3-color status light
Electronic handwheel (MPG)
Work area lighting
Roller linear guideways
Automatic lubrication system (grease)
3-axis glass scales, air-purged (XYZ)
Automatic tool changer
Air blow gun
Coolant gun
Coolant tank
Coolant flushing system (chip flush)
Full enclosure
Transformer: 400V, 50Hz
Cabinet heat exchanger
Automatic power-off
Leveling bolts and blocks
Tool box
CE conformity
Hinged belt chip conveyor

Machine Size and Weight
Machine dimensions (L x W x H): 2728 x 3760 x 3726 mm
Machine weight: approx. 19,500 kg

Subject to errors and prior sale

A wide range of automation options available
