Pjovimo keitiklis

TEMATEX (Italien) TT.T64

Būklė: naudotas, Gamybos metai: 1992, veleno greitis (min.): 7 500 aps./min, veleno greitis (maks.): 24 000 aps./min, 4 motor-driven grinding spindles (liquid-cooled, with sealing air / oil mist lubrication) including REFU HF frequency converter, e.g., for supplying the spindles of a Voumard 400 CNC T4. Grinding spindle GMN TSSV 170-7500 7,500 rpm, 350V, 19.3A, 7.5kW, 250 Hz Grinding spindle Voumard BM15-170 15,000 rpm, 350V, 35A, 18kW, 250 Hz Grinding spindle Voumard BM18-15032 18,000 rpm, 350V, 28.5A, 12kW, 600 Hz Grinding spindle Voumard BM24-150 24,000 rpm, 350V, 27A, 12kW, 800 Hz REFU HF Converter 316/25 High-frequency converter (inverter, frequency inverter) Frequency converter / inverter for the power supply of motor spindles GMN tool spindle, motorized grinding spindle The spindles are fully functional, sold as-is – year of manufacture approx. 1992. A collection of various grinding spindle shafts / arbors for grinding wheels are available for these grinding spindles and can be purchased separately. Price / details on request. All technical details are subject to errors or omissions. Lrodpfxel Tn Afe Af Hjr We sell exclusively to countries within the European Community.

Būklė: labai geros būklės (naudotas), Gamybos metai: 1997, Indeksuojamas stalas 400 mm rankinis Komplekte yra įrankiai Stalo skylė: 10 - 130 mm Raktų plotis: nuo 2 iki 32 mm Padavimo greitis: 0,5 - 5 m/min; Stalo skersmuo Ø: 690 x 460 mm Stalo apkrova: 2000 kg Stūmoklio eiga: 0 - 425 mm Ilgis: 1300 mm Lredpfoxclfzsx Af Hjr Plotis: 1100 mm Aukštis: 1400 mm Svoris: 1800 kg

Būklė: naudotas, Gamybos metai: 2010, Technical details: X-axis travel: 800 mm Y-axis travel: 685 mm Z-axis travel: 630 mm C-axis: 360° (rotary table) Control system: Siemens 840D Power Line Spindle speed: 10,500 – 20,000 rpm Spindle torque: 180 Nm Tool holder: HSK-A63 DIN 69893 Tool magazine with: 40 positions Number of tables: 2 Swiveling table +/-: 120° each (A-axis) Table clamping surface: 280 x 275 mm Table load capacity: 320 kg Interface: RS232 Spindle operating hours: 38,700 h Total power requirement: 37 kW Lsdpfoytcf Uex Af Hsrr Machine dimensions approx. LxWxH: 4.0 x 4.4 x 3.0 m Dimensions LxWxH: Chip conveyor: 2.1 x 1.05 x 1.5 m Dimensions LxWxH: Coolant system: 1.3 x 1.6 x 1.95 m CNC machining center – 5-axis machining center Clamping table for 4th and 5th axis (swivels 120° right/left, rotation speed 50 rpm, and rotates with faceplate Ø 280 mm/200 rpm). Max. workpiece size 940 x 650 mm for/on table. Equipped with chip conveyor, manufacturer Knoll, 750 K-1/150; year 2009. Coolant system by Bürener with paper band filter, belt width 700 mm; year 2009. Both control cabinets equipped with Rittal cooler. A range of accessories such as various clamping devices by HILMA and Chick, etc., can be offered exclusively. In good condition. *

Būklė: labai geros būklės (naudotas), Dvigubo veleno versija su C ašimi, su Y ašimi Su varomaisiais įrankiais FANUC/MORI MSX 501 valdymas Sukimosi skersmuo – 190 mm Sukimosi ilgis – 235 mm Veleno sūkių skaičius 50–5 000 aps./min Revolverinis įrankių laikiklis 1+2 su 16 varomų pozicijų C ašis 0,001° FMB Turbo 8–80 strypų padaviklis Detalių nuėmimo įrenginys Įrankių išankstinio nustatymo įranga Įvairi priedai MARCELS MASCHINEN CH Lrodpfx Afox I A Awo Hjr

Būklė: naudotas, Gamybos metai: 1961, Darbinio skersmuo - maks. 100 mm Darbinio skersmuo - min. 10 mm Lrjdpfx Afswwl I Io Hjr Darbinio ilgis 1000 mm Bendra galios poreikis 16 kW Staklių svoris apie 3 t Užimama vieta apie 0 m Vadeliai buvo perrinkti prieš 10 metų.

Būklė: labai geros būklės (naudotas), Funkcionalumas: visiškai funkcionalus, Commissioning: as Okuma stock machine 09.2017 Control system: OSP P300S Machine Equipment ▪ Enlarged main spindle KK size 11 Front bearing Ø 160 mm Speed range 3,000 rpm Bore Ø 112 mm Motor power 32 kW Torque 955 Nm ▪ Hollow clamping cylinder Ø 127 mm SMW VNK 320-127 with bore Ø 127 mm ▪ Pressure reducing valve Adjustment range 8-70 bar ▪ Tailstock ▪ Turning length approx. 1500 mm ▪ H1 turret (1 station) ▪ Y-axis ▪ B-axis 0.001° ▪ 40-position tool magazine ▪ Additionally: lower turret with 12 stations ▪ Tool spindle 12,000 rpm ▪ Hinge belt chip conveyor: High-performance chip conveyor with low-maintenance self-cleaning functionality ▪ Drum pocket filter TMF300 with clean tank 980 l ▪ Supply pump TC160/740, 8 bar ▪ Supply pump RSP 20/32-070-1-1-0, 70 bar ▪ Self-centering steady rest on the lower turret (not possible in combination with driven tools on lower turret) ▪ Automatic door ▪ Robot interface Type E for the integration of other loading/unloading systems on single-spindle machines ▪ 3D machine model for simulation in a CAM system Technical Details ▪ Main drive (Okuma motor spindle): 22 kW / 700 Nm / 50-4,200 rpm Spindle nose KK size 8 Front spindle bearing Ø 140 mm Lodpfx Afsyviige Hsrr Spindle bore Ø 91 mm Speed range: 2 steps Range shift at full speed ▪ Lower turret: 12 stations ZB-axis with cylindrical roller guide XB-axis with slideway ▪ Collision avoidance system CAS in real time ▪ 19'' color LCD TFT (1280x1024) with 3D color graphics as touch screen/panel with vertical display and tiltable keyboard (adjustable inclined) ▪ Second operating system Windows 7 for operation and data communication, open and freely available for Windows 7 compatible applications ▪ Programmable tailstock on W-axis with hydraulic quill ▪ Tool magazine 40 stations ▪ C-axis 360° Positioning in 0.001° ▪ Y-axis with travel +150 / -150 = 300 mm ▪ B-axis 240° Positioning in 0.001° ▪ Tool spindle (Okuma motor spindle): 22 kW / 120 Nm / 12,000 rpm ▪ Internal coolant supply for rotating tools, pump with max. 20 bar pressure Including bag filter, external cooling for tool spindle, pump with max. 3 bar pressure ▪ Tool system HSK-A63 ▪ Tool monitoring system for tool life and breakage ▪ Tool measurement device (when using standard chuck) for safe setup ▪ Machine management MacMan with integrated production data acquisition (PDA) ▪ Part program memory 2 GB ▪ Max. length single part program 2 MB ▪ 2x USB 2.0 ports ▪ Ethernet interface with browser and DNC-T1 for program transfer ▪ Harmonic speed vibration by periodic speed variation ▪ Tool height correction on the Y-axis for turning tools ▪ Circular thread milling X/Z/Y/B (helical interpolation) Including eccentric milling X/Y/C ▪ Hi-Cut Pro high-speed control for rotary tools ▪ 10 workpiece zero points (coordinate system selection function) ▪ Coordinate transformation (shift, rotate) ▪ Electronic spindle orientation +/- 0.1°

Būklė: naudotas, Gamybos metai: 1988, Technical details: Swing diameter over bed: 360 mm Swing diameter over cross slide: 160 mm Lodpfx Aju Rqabef Horr Turning length: 800 mm Longitudinal travel (Z-axis): 810 mm Cross travel (X-axis): 205 mm Control: TX-8 Spindle bore: 60 mm Spindle speed: 63 - 3150 rpm (2-step) Feed rate: 10,000 mm/min Tool turret - number of stations: 8 Operating hours (power-on hours): 8,834 h Tailstock quill taper: SK30 DIN 2080 Tailstock quill stroke: 105 mm Operating pressure: 40 bar Total power requirement: 38 kW Machine weight approx.: 3.1 t Machine dimensions (LxWxH) approx.: 1.8 x 3.3 x 1.8 m Hydraulic system dimensions: 580 x 400 x 750 mm Equipment: 200 mm hydraulic chuck (without jaws) Feed force Z-axis = 8 kN and X-axis = 5 kN Coolant system Control panel Accessories: Fine adjustment device for tool setting

Būklė: labai geros būklės (naudotas), Gamybos metai: 2001, veikimo valandos: 4 500 h, Funkcionalumas: nepatikrintas, mašinos/transporto priemonės numeris: 090119, Country of Manufacture: CE - Germany Voltage: 400V Net Weight: 7,500 kg Dimensions: 2.9 x 2.3 x 2.3 m Operating hours: 29,731 h, Working hours: 4,500 h TECHNICAL DATA AXES Maximum travel X-axis: 400 mm Maximum travel Y-axis: 300 mm Maximum travel Z1-axis: 475 mm Maximum travel Z2-axis: 475 mm B-axis rotary position: 0.0001 – 360° C1/C2-axis rotary position: 0.0001 – 360° WORKPIECE Maximum cubic dimension: 80 x 80 x 80 mm Maximum workpiece weight: 5 kg TURRET HEAD Number of positions: 24 Number of controlled positions: 18 Number of fixed positions: 6 Maximum tool holder (round): Ø 20 mm Maximum tool holder (square): 16x16 mm (20x20) Max. turret head movement above tool tip: 500 mm Rotating tool speed: 1–9,000 rpm Lodpfx Afsht Hg Ds Herr SPINDLE Maximum spindle speed: 6,000 rpm Maximum bar diameter: Ø 42 mm Maximum clamping chuck diameter: 140 mm BAR MACHINING Maximum bar length (bar feeder): 1,000 mm Maximum workpiece size for bar gripper: Ø42 x 100 mm Maximum gripper diameter: 42 mm Clamping cylinder tensile and compressive force: 20,000 N FEED Feed force X-axis: approx. 895 daN Feed force Y-axis: approx. 895 daN Feed force Z1-axis: approx. 895 daN Feed force Z2-axis: approx. 895 daN Rapid traverse X/Y/Z axes: 20 m/min Tool control motor torque: 2.4 Nm Spindle S1 / Spindle S2: 70 Nm COOLING (Performance Values) Chip conveyor immersion pump output: approx. 10 l/min at 4.5 bar / 80 l/min at 3.2 bar / 150 l/min at 0.7 bar High-pressure pump output in conveyor: 10 l/min at 13.2 bar / 50 l/min at 9 bar / 90 l/min at 1 bar Lubricant volume in chip conveyor: approx. 134 L Coolant volume in cooling unit: 45 L CONTROL: Siemens 840D WORKING PRECISION Resolution X/Y/Z: 0.1 µm Resolution B-axis: 0.0001° Resolution C-axis: 0.0001° Positioning accuracy: 5 µm Accuracy: 0.6 µm Maximum run-out error: 0.5 µm ELECTRICAL Spindle 1 / Spindle 2 (at 100%): 11 kW Spindle 1 / Spindle 2 (at 40%): 15 kW Feed motor axes X/Y/Z1/Z2: 1.3 kW B-axis: 1.3 kW Tool control: 2.3 kW Hydraulic pump: 7.5 kW Hydraulics return stroke: 0.75 kW Cooling unit fan 1 / 2: 0.18 kW Circulating pump (cooling unit): 1.1 kW Cooling unit compressor: 2.2 kW Chip ejector: 0.25 kW Emulsion pump 1: 1.1 kW Emulsion pump 2: 2.2 kW Operating voltage: 400 V Mains frequency: 50 Hz (60 Hz optional) Control voltage: 24V DC Total power: 35 kW Rated current: 63A Connection: Network TM / TT / IT PNEUMATICS Maximum operating pressure: 10 bar Normal operating pressure: 6 bar Minimum operating pressure: 5 bar Air output: approx. 150 L/min Solenoid voltage: 24V DC Oil mist tank capacity: 12 L Quality standard: 2 as per Pneurop 6611 NOISE EMISSIONS Normal operation: 78—80 dB Technical data subject to change or error, information provided without obligation. Inventory No. 2321018, Machine consisting of: - Chip conveyor - Preparation for bar feeder Tool holders: 6 fixed drill holders ER32 8 turning tool holders 5 driven tool holders ER32 4 driven tool holders ER25 6 driven tool holders ER20

Gamybos metai: 1995, būklė: naudotas, mašinos/transporto priemonės numeris: 18891, Tractive force: 10 tons. Stroke: 1000 mm. 3 ejector stations. With chip conveyor and platform for above-ground installation, including safety door. Lrjdjbrcmkopfx Af Hsr

Būklė: naudotas, Gamybos metai: 2005, Turning diameter: 275 mm Turning length: 900 mm Control system: TRAUB TX8i Spindle bore: 65 mm Drive power, 100% duty cycle: 25.20 kW Drive power, 40% duty cycle: 30.20 kW Torque at 40% / 100% duty cycle: 180 / 135 Nm Spindle speeds, stepless: 1 - 5,000 rpm Spindle diameter in front bearing: 110 mm C-axis: 1 - 500 rpm Tool turret No. 1 X-axis: 290 mm Lrodpfx Afow E Nnbo Hjr Y-axis: 165 mm Z-axis: 600/950 mm B-axis: 360° Rapid traverse X/Y/Z: 18 / 18 / 30 m/min Feed force X/Y/Z: 10 / 10 / 7 kN Number of tools: 2x2 + 2x2 Number of driven tools: 2x2 + 2x2 mm Tool speeds: 8,000 / 2,000 rpm Drive power, 25% duty cycle: 5.80 kW Torque at 25% duty cycle: 4x18.6 / 4x74 Nm Tool holder: TRAUB Ø60 Tool turret No. 2 / No. 3 / No. 4 X-axis: 170 mm Z-axis: 600/950 mm Y-axis: +/- 60 mm Rapid traverse X/Y/Z: 18 / 15 / 30 m/min Feed force X/Y/Z: 10 / 10 / 7 kN Turret - number of stations: 10 Number of driven tools: 10 mm Tool speeds: 1 - 6,000 rpm Drive power, 25% duty cycle: 5.80 kW Torque at 25% duty cycle: 18.60 Nm Tool holder: DIN 69880 Ø40x63 Bar feeder: DNH61 / 3000 Bar lengths: 1,000 - 3,200 mm Bar diameter: 18 - 63 mm Max. hexagon: 45 mm Total power requirement: 95.00 kW Machine weight approx.: 16.00 t Installation dimensions approx.: 10.00 x 3.50 x H3.00 m Equipped with TRAUB TX 8i control, main and counter spindle with C-axis, 3 turret tool carriers, 1 vertical tool carrier with B-axis, extraction system, chip conveyor, coolant system with coalescence separator. Bar loader: TRAUB Stamag DNH61 / 3000 2 pcs. 3-jaw chucks SMW KNCS-N 170-43 2 pcs. HAINBUCH collet chucks 40 pcs. various static tool holders 6 pcs. various driven tool holders Spare parts package The machine can be inspected under power.
