Dviejų velenų smulkintuvas

Mayfran MSA

Gamybos metai: 1998, būklė: labai geros būklės (naudotas), NEUE HERBOLD Granulator Rjdpsh Rwc Eefx Adzecb Universal Mill – Heavy-Duty Design - Year of manufacture: 1998 - Made of stainless steel - From technical center (machine was used exclusively for testing/demonstration purposes) - Rotor diameter: 300 mm - Working width: 500 mm - 3 knife rows

Gamybos metai: 2011, būklė: geras (naudotas), Shredding plant, single-shaft shredder, shredder, chipper, cutting mill, single-shaft crusher, rotor mill -Shredding plant: fully made of stainless steel, suitable for frozen meat or other materials -Motor power: 4 kW -Speed: approx. 60 rpm Rsdpfxeh Di H Do Adzecb -Number of cutting blades: 10 pieces -Dimensions of cutting blades: 250 mm -Feed hopper: 500 x 895 x H480 mm -Dimensions: 880/1390/H2060 mm -Weight: 640 kg

Būklė: labai geros būklės (naudotas), The plant essentially consists of: Rcsdpelxzl Esfx Adzeb - 2 feeding units (walking floor bunkers) - 2 silos, each with 55 cbm, equipped with discharge screws - 2 screw conveyors - 4 mixing and homogenization chambers - 5 transport conveyor belts - 2 parallel-operated twin-shaft extruders for processing woody biomass - 1 twin-shaft paddle mixer - twin-shaft extruder for homogenization - laboratory container with mixing and dosing system for liquid extracts

Gamybos metai: 1987, būklė: naudotas, Kehren Rotary Table Type RS 7C, used Manufacturer: Kehren, Honneff Ref.: 4179 Year of manufacture: 1987 Control: Siemens 3G PLC: Siemens S5 Grinding motor: BBC QUB 200 Rotary table diameter: 750 mm Grinding head diameter: 460 mm Operator panel with screen Coolant system Rcodpfx Adshgmwgozeb Flush pump Coolant pump Automatic paper band filtration system Control cabinet

Būklė: naudotas, Funkcionalumas: visiškai funkcionalus, Daugiafunkcinis suvirinimo aparatas (MIG, TIG, elektrodai) Gamintojas: Kemppi Modelis: Pro 3000 / Promig 500 Vandeniu aušinamas aparatas su Kemppi PRO Cool 10 šaldytuvu. TIG/elektrodinis suvirinimo įrenginys Kemppi PRO TIG 410 - Kemppi TL valdymo pultas - TIG suvirinimo funkcijos: dujų tiekimas prieš ir po suvirinimo, lanko valdymas, aukštas dažnis Rjdoxf Hv Hspfx Adzocb TIG generatorius Kemppi Pro 3000 MIG vielos suvirinimo įrenginys Kemppi PRO MIG 500 - Darbo ciklas: 500A – 60% - Kemppi ML SYNERGIC valdymo pultas - 4 tempimo volai - Pulsinės srovės lanko suvirinimas su synerginiu pultu - Specialios funkcijos plieno, nerūdijančio plieno ir aliuminio suvirinimui Komplekte: - TIG suvirinimo degiklis - MIG suvirinimo degiklis - Masės laikiklis - Dujų reguliatorius

Gamybos metai: 2011, būklė: paruoštas naudoti (naudotas), A Gross Apparatebau GmbH shredder, previously used in the wood industry, is available. Feed opening X/Y: 600mm/800mm, hopper volume: 0.6m³, rotor diameter: 252mm, rotor length: 600mm, rotor speed: 90 rpm, drive power: 18.5kW, number of blades: 14, screen perforation: 10mm–40mm, extraction port diameter: 160mm, machine dimensions X/Y/Z: approx. 1800mm/1200mm/1650mm, weight: approx. 1300kg, operating hours: 4578h. Documentation available. On-site inspection possible. Rcjdpfju Nlkxox Adzsb

Būklė: beveik kaip naujas (naudotas), The MSP 120 ZK is ideally suited for the shredding and subsequent briquetting of various types of metal chips. The MSP 120 ZK briquetting press with integrated shredder consists of a hydraulic chip press and a preceding shredder, which are precisely matched to each other. The system allows for the reduction in size and compaction of chips generated during turning/milling processes. The volume is significantly reduced, and the briquettes are separated from coolants (coolant emulsion, oil) that may have been absorbed during prior machining stages. The system consists of a feed hopper into which the material to be processed is introduced, and an integrated shredder that reduces the length of the chips. A conveyor system continuously and gradually transports the shredded chips via a conveyor belt into the hopper of the chip press. Here, two screw conveyors transport the material into the compaction chamber. The system includes a monitored liquid collection tank and a pump. The coolants can be returned to the production process. Cycle control is managed via a PLC and an electronic level sensor for monitoring the fill level in the hopper. Optionally, a tipping device for manual filling of the system can be added if required. Briquetting Press: Throughput (Aluminium): 15-20 kg/h Throughput (Steel, Copper): 45-60 kg/h Ø Briquettes: 60 mm Productivity: 120-180 pcs/h Specific pressure on briquette: 1,050 kg/cm³ Motor pump power: 7 kW Total installed power: 10 kW Voltage: 400V / 50 Hz Oil tank capacity: 80 l Dimensions: 1,400 x 1,200 x 1,050 mm Weight: 800 kg Shredder: Cutter shaft: 1 pc Motor power: 5.5 kW Number of cutters: 16 pcs Cutters replaceable: yes Cutter size: 25 mm Cutter material: Hardened steel Shaft length: 400 mm Screen size: 20 mm Ø Feed hopper dimension: 1,000 mm Redpfew R Ranjx Adzscb Hopper volume: 1 m³ Weight: 280 kg Power connection: 380V Overall system dimensions: 2,820 x 1,862 x 2,065 mm Colour: Textured paint RAL 7035 light grey

Gamybos metai: 1999, būklė: paruoštas naudoti (naudotas), Darbinis plotis: 230 mm, darbinis aukštis: 160 mm, velenų skaičius: 5, veleno diametras: 50 mm, veleno galia: 4x 5,5 kW / 2x 11 kW, padavimas: 24 m/min, padavimo stalo ilgis: 3000 mm, vertikalaus veleno ašinė eiga: 80 mm, horizontalaus veleno ašinė eiga: 45 mm. Bendras pajungimo galingumas: 126 kW, oro poreikis: 8400–9600 m³/val., staklių matmenys (X/Y/Z): apie 3500 mm / 2000 mm / 1800 mm, svoris: apie 3500 kg. Į komplektą įeina Weinig EM-11 įstūmimo įrenginys ir tinkamas ištraukimo paskirstytuvas. Dokumentacija yra. Galima apžiūrėti vietoje. Redpfxsu Damde Adzscb

Būklė: labai geros būklės (naudotas), Gamybos metai: 1997, galia: 1,5 kW (2,04 AG), Tria plastic mill, shredder, granulator for sale in excellent condition Make: TRIA 20-15/BL-T Power: 1.5 kW, 50 Hz, 380 V Year of manufacture: 1997 Feed opening: 200 x 230 mm Rotating knives: 3 pcs Fixed knife: 1 pc Rodpsra N A Nofx Adzecb Discharge opening: 60 mm Final product size: 3–5 mm Capacity: approx. 30 kg/h.

Būklė: beveik kaip naujas (parodų įrenginys), Gamybos metai: 2025, veikimo valandos: 500 h, Funkcionalumas: visiškai funkcionalus, mašinos/transporto priemonės numeris: 25-029, bendras plotis: 800 mm, bendras ilgis: 4 700 mm, bendras aukštis: 1 900 mm, įvesties srovės tipas: trifazis, energijos suvartojimas: 2 kWh, Very good metal separator for separating all metals (including stainless steel, V2A) from a material stream. Can be used before or after a non-ferrous separator (eddy current separator) or as a stand-alone machine. Separation of all metals from approximately 1 mm particle size. Suitable for metal content up to 60%. Unique flap technology (flipper), no compressed air required. The machine is immediately operational, can be inspected and tested. Camera option available upon request! If the machine is too small, we can also manufacture larger models. This is our demonstration machine. Maximum throughput depends on material and application. Rjdjqabm Ejpfx Adzjcb Price negotiable!
