Frezavimo stalas

GANRO Taiwan GCT 1201 72D

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 2014, Funkcionalumas: visiškai funkcionalus, X ašies eiga: 6 612 mm, Y ašies eiga: 5 645 mm, Z ašies eigos atstumas: 1 250 mm, stalo ilgis: 7 000 mm, stalo plotis: 2 500 mm, veleno greitis (maks.): 4 500 aps./min, atstumas tarp stulpų: 3 800 mm, Technical Data • Table clamping surface: 7,000 × 2,500 mm • X-axis (longitudinal travel): 6,000 + 612 mm • Y-axis (cross travel): 4,670 + 975 mm • Z-axis (vertical travel): 1,250 mm • W-axis (vertical travel): 1,200 mm • Distance between columns: 3,800 mm • Distance table clamping surface – spindle nose: 2,015 mm • Drive power AC motor: 60 kW • Speed in 2 stages, digital spindle drive: 60 – 4,500 rpm • Feed rate in CNC mode (rapid traverse): up to 10,000 mm/min • X-axis: 20,000 mm/min • Y and Z-axis each: 25,000 mm/min • C-axis rotary table: ±180° • 45° milling head rotation: 360° Main components of the machine • Heidenhain iTNC 530 path control with 15" screen • Tool changer with 60 positions • Rotary table for operating multiple milling heads with automatic milling head change, including collet system for accommodating various milling heads, quick couplings for hydraulics, coolant and power supply, as well as the corresponding electrical safety switches • Centering of the milling heads on the rotary table via Hirth face gearing (on mounting plate and respective milling head) • 2 x milling heads: straight extension milling head (direct spindle), 45° milling head automatic • Crossbeam motorised traversable (for positioning only) • Operator platform: 2 operator platforms with safety enclosure and integrated control panel, traversing in X-direction, each with 2 doors • Chip conveyors on both sides of the table as well as a cross conveyor • Longitudinal drive X-axis and cross drive Y-axis by rack and pinion and 2 servo motors (electronically preloaded backlash-free, master-slave principle) • Vertical adjustment Z-axis via ballscrew (Ø 80) and preloaded double nut • Zayer guideway system consisting of inserted or bolted, hardened steel strips • All axes equipped with INA roller recirculating shoes on each running surface Kjdpfxoxgr Epe Afpond • Counter guides for all axes additionally coated with plastic for optimum damping • Anchoring and leveling elements • The machine complies with the currently applicable EC directives The above information is taken from the machine documentation. The seller assumes no liability for the completeness or correctness. The actual technical specifications and functions of the machine are binding.

Sąlyga: naudotas, Gamybos metai: 2004, Technical Details: Swing diameter over bed: 850 mm Swing diameter over cross slide: 580 mm Turning length: 4000 mm Distance between centers: 4000 mm Faceplate diameter: 800 mm Control: Siemens 810D Spindle speed: 1 - 1,600 rpm / 2-step Spindle torque: 6,000 Nm Feed drive AC: X = cross + Z = longitudinal: 16,000 / 20,000 N Ksdeu Ix Izepfx Afpend Rapid traverse in X-direction: 4 m/min Rapid traverse in Y-direction: 7 m/min Spindle bore: 130 mm (Spindle nose DIN 55027 Size 11) Operating hours / On-hours: to be read out Tailstock quill: ISO MT 6 Tailstock quill stroke: 350 mm Max. workpiece weight between centers: 5,000 kg Max. workpiece weight – unsupported: 1,800 kg Interface: RS 232 / V24 Operating voltage: 400 V / 50 Hz Control voltage: 24 V DC Total power requirement: approx. 52 kW Machine weight approx.: 14.0 t Machine dimensions (LxWxH): approx. 2.6 x 9.1 x 2.5 m Cycle turning lathe with Siemens cycle control Motor: 37 kW, rated speed 1,500 rpm; max. speed 6,500 rpm; torque 235 Nm two gearbox stages Stage II: Spindle torque 258.9 to 1,364.6 Nm Stage I: Spindle torque 1,050.4 to 5,536.1 Nm Feed drive: three-phase servo drive 2x chip conveyors Double electrical cabinet Parat quick-change tool post Coolant system Including various accessories (see photo), as well as steady rest and 3-jaw chuck Ø 500 mm Rota-S plus

Sąlyga: naudotas, Gamybos metai: 2010, X-axis travel: 730 mm Kjdpfx Afeup H Drspend Y-axis travel: 730 mm Z-axis travel: 730 mm Control system: Matrix Nexus Mazatrol Main spindle: Speed range - Main spindle: 35 - 18,000 rpm Drive power - Milling spindle: 35 / 26 kW Tool holder: ISO 40 DIN 69871A Number of gearbox stages: 2 Pallet changer: Number of pallets: 6 (5+1) Pallet size: 500 x 500 mm Max. workpiece weight: 700 kg Max. workpiece diameter: 800 mm Max. workpiece height: 1,000 mm Pallet change time: 7 sec B-axis (table): 0.001° Tool changer: Number of tool stations: 160 pos. Tool holder: ISO 40 DIN 69871A Max. tool diameter: 95 mm Max. tool diameter with empty adjacent station: 150 mm Max. tool length: 420 mm Max. tool weight: 12 kg Tool-to-tool change time: 2.7 / 3.2 sec Feed rates: Rapid traverse: 60 m/min Feed rate max.: 60,000 mm/min Total power requirement: 78.5 kVA Machine weight approx.: 16.4 t Space requirements approx.: 7.5 x 3.5 x 3.0 m CNC Horizontal Machining Centre MAZAK - Nexus 5000 II - Pallet changer: 6 (5+1) positions - WITHOUT tools

Sąlyga: naudotas, Gamybos metai: 2011, Mazak HC Nexus 6000-II Mazatrol Matrix Nexus Rok produkcji: grudzień 2011 Ksdpov Tvivofx Afpend Rozmiar palety: 500 mm x 500 mm Przesuwy: - Oś X: 800 mm - Oś Y: 800 mm - Oś Z: 800 mm Maks. wymiar detalu: Ø 900 mm x 1000 mm Maks. obciążenie stołu: 1000 kg Prędkość obrotowa wrzeciona: 10 000 obr./min (2 zakresy) Moc wrzeciona: 30/37 kW Stożek wrzeciona: CAT 50 Prędkość posuwów szybki X/Y/Z: 60 m/min Magazyn narzędzi: 80 szt.

Sąlyga: naudotas, Gamybos metai: 2016, x-travel 6,500 mm y-travel 4,250 mm z-travel 1,500 mm Control HEIDENHAIN iTNC 530 HSCI Table size 7,500 x 3,000 x 300 mm Distance between columns 3,800 mm Rapid traverse x/y/z 30,000 mm/min Tool holder HSK 100 Spindle speed 6,000 rpm Gear stages 2 Motor power 37 kW Operating hours 28,475 h Spindle hours 12,629 h Tool changer 60-fold Knsdsxb Ed Uspfx Afpsd Internal coolant supply 36 bar Chip conveyor double Milling head 5-axis milling head OAD Total power requirement 80 kVA Machine weight approx. 85 t Milling head OAD fully water-cooled. - 6,000 rpm without time limitation. - The patented rotation system by Correa with fixed double toothing allows an indexing every 0.02º. As the gearing is not free-moving, maximum rigidity and precision are ensured. - Negative angles up to 45 degrees can be achieved. - Milling spindle mod. FCT (4,000 rpm / 1,893 Nm / HSK 100) - Head extension mod. AL600 (1,500 rpm / 1,298 Nm / ISO 50) - Head changer station for 3 heads - M&H 20.41

Sąlyga: naudotas, Gamybos metai: 2008, Technical details: X-axis travel: 6500 mm Y-axis travel: 1400 mm Z-axis travel: 1000 mm Table size: 7000 x 1100 mm Milling spindle speed range: 15 – 4000 rpm Spindle taper ISO: 50 Rapid traverse speed: 20 m/min Kedpfevmz I Rex Afpsnd Feed rate: 1 – 10,000 mm/min Total power requirement: 75 kW Machine weight approx.: 30 t Equipped with: - CNC SIEMENS 840 D - Automatic indexing milling head, 0.001 x 0.001° increment - Automatic tool changer, 100 positions - Coolant system with internal coolant supply (IKZ) 30 bar - Chip conveyor

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 2014, X ašies eiga: 6 000 mm, Y ašies eiga: 3 500 mm, Z ašies eigos atstumas: 1 600 mm, Gamintojas: ZAYER, Tipas: 30 KCU 6000-AR Pagaminimo metai: 2013 Serijos Nr.: 77257 5 ašių -45° universali galva - Tiesi galva Judėjimo eiga (X/Y/Z) apie 8000/3500/1600 mm, Įrankio laikiklis SK50 Knedpfxsw U E Uns Afpsd 8 vietų įrankių keitiklis Valdymo pultas HEIDENHAIN iTNC 530 Drožlių konvejeris TECNIMETAL Aušinimo agregatas EURO COLD Stalinis DEMMELER Aušinimo skysčio sistema Apsauginė tvora su šviesos užtvara LENZE

Sąlyga: naudotas, Gamybos metai: 2015, mašinos/transporto priemonės numeris: 5319, X ašies eiga: 8 000 mm, Y ašies eiga: 2 600 mm, Z ašies eigos atstumas: 1 300 mm, BASE MACHINE PowerSpeed 5 WITH FORK HEAD – TECHNICAL KEY DATA Travel distances: X-axis: 8,000 mm Y-axis: 2,600 mm Z-axis: 1,300 mm Machine bed (X-axis): Flat bed design with 1,000 mm guideway width. Two electric motors drive via a centrally mounted rack. Hardened compact roller guides ensure high precision. Machine column (Y-axis): Welded steel construction with 900 mm guideway width. Two liquid-cooled feed motors and two measuring systems ensure dynamics and accuracy. Protected by telescopic steel covers. Spindle carriage and headstock: Manufactured from GGG 60 cast iron, guided via compact roller guides. Optimum power transmission thanks to long guides and close arrangement of Y- and Z-axes. Dual spindle drive: Two vertical ball screws with separate drives and measuring systems for high dynamics and long-term accuracy. Drive system: Digital individual drives with AC motors. Feed and rapid traverse range: 2–30,000 mm/min. Acceleration: 3.5 m/s². Measuring system: Direct, contactless linear measuring systems for high production accuracy. Automatic 2-axis fork head with motor spindle: Knedpfx Aswdub Dsfpsd A-axis: 764 Nm (100% duty cycle), ±105°, clamping torque 2,160 Nm, accuracy ±5″ C-axis: 810 Nm (100% duty cycle), ±200°, clamping torque 3,024 Nm, accuracy ±3″ Motor spindle: HSK-A 63, up to 18,000 rpm, 89 Nm (100% duty cycle), internal/external coolant supply up to 70/20 bar, liquid-cooled Electrical equipment: 400/230 V, 50 Hz, 80 kVA connected load. Control cabinet (IP54) with control and switching devices. Cable length machine–cabinet: 5 m. Control cabinet cooling: Dual-chamber system with automatic internal air cooling and dehumidification. Lubrication: Central lubrication for guides, permanent grease lubrication for main spindle, oil mist lubrication in milling head. Energy supply: Compressed air 4–6 bar, connection G ¼, with pressure regulator and condensate separator. Control system: Siemens 840D sl with swiveling operating panel. Wireless handwheel with LCD display, potentiometers and buttons for axes, feed, and spindle. Remote maintenance: Fault diagnosis via alarm manager, notification by e-mail/SMS (SIM card and network required). TightBlock base frame (X = 8,000 mm): Heavy composite construction for vibration damping. Foundation recommendation: ≥100 mm thickness per 1,000 mm X-travel, statically verified. Coolant system: 500 l tank, filtration unit

Sąlyga: geras (naudotas), Gamybos metai: 2003, X ašies eiga: 3 900 mm, Y ašies eiga: 920 mm, Z ašies eigos atstumas: 820 mm, greitas poslinkis X ašimi: 100 000 m/min, greitas poslinkis Y ašis: 60 000 m/min, greitasis eiga Z ašyje: 60 000 m/min, ruošinio svoris (maks.): 2 200 kg, stalo plotis: 900 mm, stalo ilgis: 4 200 mm, 5 ašių apdirbimo centras DECKEL MAHO – DMF 360 Linear HSK-A63 velenas Švytuoklinis ekranas Gamybos paketas IKZ 40 bar Filtro našumas: 23 l/min Aušinimo skysčio bakas: 900 l Paskutinis DMG remontas 2023 m., 11 000 EUR vertės X ašis: 3900 mm Y ašis: 920 mm Z ašis: 820 mm B ašis: 108° Stalo ilgis: 4200 mm Stalo plotis: 900 mm Stalo apkrova: 2200 kg X ašies pastūma: 100 000 mm/min Y ašies pastūma: 60 000 mm/min Z ašies pastūma: 60 000 mm/min Įrankio tvirtinimas: 63 ISO/Bt/Mk Veleno galia: 35 kW Sukimosi greitis: 18 000 aps./min Įrankių keitiklis: 30 vnt. IKZ: 40 Kodpfxow Rdyhj Afpond Valdomų ašių skaičius: 3+1 Drožlių transporterio: Taip Aušinimo įreng: Taip Ilgis: 8 500 mm Plotis: 3 450 mm Aukštis: 2 910 mm Svoris: 30 700 kg

Gamybos metai: 2007, Sąlyga: paruoštas naudoti (naudotas), - NAUDOTAS - 8 AŠIŲ CNC TEKINIMO STAKLĖS SU FREZAVIMO GALVA, APATINE REVOLIUCINE GALVA IR PRIEŠSPINDELIU MAKSIMALUS SUKIMOSI SKERSMUO: 660 mm MAKSIMALUS TEKINIMO ILGIS: 1495 mm MAKSIMALUS TEKINIMO SKERSMUO: 660 mm ŽALIAVOS TALPA: 65 - 65 mm PAGRINDINIS VELENAS: 35-5000 aps./min; 22 kW; 254 mm PRIEŠSPINDELIS: 35-5000 aps./min; 18,5 kW; 254 mm GALVA: CAPTO C6; -30°+195°; 15-12000 aps./min; 18,5 kW X AŠIES EIGA: 580 mm X2 AŠIES EIGA: 150 mm Knjdpfxow Ey R Hs Afpod Y AŠIES EIGA: 160 mm Z AŠIES EIGA: 1545 mm Z2 AŠIES EIGA: 1490 mm B AŠIES EIGA: 1550 mm GREITO EIGOS MAITINIMAS X-Y-Z: 38 - 26 - 38 m/min REVOLIUCINĖ GALVA: 9 PADĖTYS ĮRANKIŲ MAGAZINAS: GRANDININIS; 80 PADĖČIŲ AUKŠTO SLĖGIO AUŠINIMAS: 18 Bar VALDYMO BLOKAS: MAZATROL MATRIX SVORIS: 11800 kg BENDRI MATMENYS: 5090 x 3270 x 2830 mm PRIEDAI: DROŽLIŲ TRANSPORTERIS; POPIERINIS FILTRAS; ĮRANKIŲ NUSTATYMO ĮTAISAS
