Paviršiaus šlifavimo staklės / ELB

ELB-Schliff SWN 5 VA II

Būklė: visiškai atnaujintas (naudotas), Gamybos metai: 2025, Funkcionalumas: visiškai funkcionalus, mašinos/transporto priemonės numeris: 510-1986, CYLINDRICAL GRINDER JOTES SCHAUDT A440X1500 Specifications Maximum longitudinal travel: 1500 mm Grinding diameter: 298 mm External grinding: Yes Internal grinding: Yes Dimensions (L x W x H): 5400 x 2400 x 1600 mm Weight: 4800 kg Operating hours: Powered-on hours: Condition: Rebuilt Compliant with local standards: ----- Status: Under power Technical Characteristics - Grinding length [mm]: 1500 - Grinding diameter [mm]: 300 - Manual table feed [mm/rev]: 10 - Table speed range [mm/s]: 0.01-5 - Smallest table stroke [mm]: 3 - Wheelhead swiveling angle [°]: ±90 Iedpfsw T Ti Dsx Agfetd - Morse taper in tailstock sleeve: 4 - Grinding wheel dimensions [mm]: 500x63x203 - Spindle speed [rpm]: 32-500 - Grinding wheel drive motor power [kW]: 5.5 - Workpiece drive motor power [kW]: 0.75 - Hydraulic pump drive motor power [kW]: 1.5 - Grinding attachment drive motor power [kW]: 0.75 - Overall dimensions [mm]: L=5400 / W=2400 / H=1580 - Machine weight [kg]: 4800

Būklė: beveik kaip naujas (naudotas), Funkcionalumas: visiškai funkcionalus, Gamybos metai: 2017, veikimo valandos: 2 600 h, valdymo tipas: CNC valdymas, valdiklio modelis: Fanuc 32 C, Įranga: dokumentacija / vadovas, Standard programs such as parameter setting - Dressing settings - Speed settings - Program management settings - Limitation of X and Y travel distances - Basic parameter settings Grinding wheel management program Warming-up cycle program Flat plunge grinding program Measuring program 15 kVA transformer Meister G3 full enclosure Spindle upgrade to 3.7 kW, wheel 225 ETHER interface for network connection Control module with expanded memory Fanuc Macro B option Batch program creation Programmable spindle speed WinWop contour creation program for Windows WINWop error compensation program WinWop postprocessor CGS Complete Grinding Solutions software Option: Dressing Swiveling profile dressing device Diamond dressing wheel Pre-dressing unit VPA 100 L 100 mm diamond wheel for pre-dressing unit Regrinding package Diamond Grade G3 / W Option – Clamping and Balancing Magnetic chuck 400 x 200 Stop bar 400 mm with prism Fully automatic balancing device, size 1 Grinding wheel flange for G3, bore 51 Option: Filtration systems Belt filter system 175 l Emulsion mist extraction system 500 Enquiries only from Europe – EU preferred Isdew I Tt Sjpfx Agfstd

Būklė: visiškai atnaujintas (naudotas), Gamybos metai: 2013, Funkcionalumas: visiškai funkcionalus, GF AgieCharmilles CUT 300 Year of manufacture: 2013 Charmilles Millenium Control Travel paths (X / Y / Z): 550 x 350 x 400 mm Travel paths (U / V): 550 x 350 mm Itjdjw D Accopfx Agfod Max. taper angle: +/- 30° at 400 mm height Integrated Collision Protection (ICP) on all 5 axes automatic drop-door tank Maximum workpiece dimensions: 1200 x 700 x 400 mm Maximum workpiece weight: 1,500 kg Cutting speed of 340 mm²/min Best surface finish: Ra 0.10 µm Available wire diameters: 0.15 to 0.33 mm Dimensions of the complete system: 2600 x 2600 x 2340 mm Total weight of the system: 3,300 kg The machine will be cleaned, fully overhauled, and tested on all functions after receipt of order. You will receive a 6-month warranty on the machine. We are happy to offer you machine commissioning as an additional service.

Būklė: geras (naudotas), Gamybos metai: 1988, šlifavimo ilgis: 1 000 mm, šlifavimo plotis: 550 mm, šlifavimo aukštis: 400 mm, šlifavimo disko skersmuo: 400 mm, šlifavimo ratuko plotis: 100 mm, Manufacturer: ELB-SCHLIFF Model: SWBE 010 ND Year of manufacture: 12-1988 Delivery time: immediately Electro-permanent magnetic chuck SAV 1000 x 400 mm Fine pole pitch 45-5 mm Iodpfxou Rqyne Agfjtd Electronic straight dressing device with compensation Vertical digital readout Mounting for grinding wheel max. 400 x 100 x 127 mm Spindle motor 7.5 kW 1435 rpm Wedge-shaped leveling pads Coolant system with universal paper band filter Complete documentation

Gamybos metai: 1987, būklė: naudotas, Kehren Rotary Table Type RS 7C, used Manufacturer: Kehren, Honneff Ref.: 4179 Year of manufacture: 1987 Iedpohgmwgjfx Agfotd Control: Siemens 3G PLC: Siemens S5 Grinding motor: BBC QUB 200 Rotary table diameter: 750 mm Grinding head diameter: 460 mm Operator panel with screen Coolant system Flush pump Coolant pump Automatic paper band filtration system Control cabinet

Būklė: visiškai atnaujintas (naudotas), Gamybos metai: 2025, Funkcionalumas: visiškai funkcionalus, mašinos/transporto priemonės numeris: 1315/451, Completely overhauled: Mechanics, geometry, hydraulics, and electrical components (checked and/or replaced) Grinding wheel headstock Disassembly, cleaning of parts, replacement of worn and defective parts, motor overhaul, bearing replacement, belt replacement, spindle disassembly, replacement of seals and O-rings + adjustment. Newly painted. Workpiece headstock Disassembly, cleaning of parts, replacement of worn and defective parts, motor overhaul, belt replacement. New spindle bearings. Newly painted. Tailstock Disassembled, inspected, overhauled. Hydraulics Disassembled, motor check, replacement of hoses, defective and worn parts. Hydraulic block inspected. X Axis Disassembly, replacement of worn parts such as O-rings, seals, rings, etc., overhaul of hydraulic piston, grinding of tables. Z Axis Disassembly, grinding of tables, replacement of worn and defective parts, hydraulic piston overhaul, newly painted. Electrical cabinet Complete inspection, various relays replaced. Painting Colors: White RAL 9003 and Grey RAL 7011 Geometry according to manufacturer’s protocol. Inspection and cleaning of various accessories. Origin CH Voltage 380 / 50 / 3 Net weight approx. 2200 kg Customs tariff number 8460.2920 TECHNICAL SPECIFICATIONS Nominal centre distance 600 mm Max. centre distance (extended headstock) 750 mm Centre height, standard 125 mm Centre height with interchangeable shoes for headstocks 175 to 250 mm Max. workpiece diameter (125 mm centre height) 250 mm Max. workpiece diameter with interchangeable shoes 350 to 500 mm Table swivelling in either direction 10° Max. length for surface grinding (max. width = 200 mm) 900 mm Table speed with continuously variable hydraulic control up to approx. 6 m/min Table reversal dwell time 0-5 sec. Wheel for external grinding, diameter-width-bore 400x50x127 mm Wheel for surface grinding 250x13x76 mm Grinding spindle speeds 1500/1700/2200/3600 rpm Grinding headstock swivel 270° With index every 90° Vertical movement of grinding headstock, centre height 125-350 mm Cross travel of grinding headstock 285 mm Hydraulic rapid advance/retract stroke 40 mm Intermittent feed of the wheel by table reversal 0.001-0.03 mm/dia Continuous plunge grinding feed 0-0.9 mm/dia Itsdpjw U Ry Nefx Agfod Micrometric feed stop, graduated 0.001 mm/dia Workpiece headstock swivel 360° Continuously variable workpiece spindle speed, standard/special 20-400 / 10-400 rpm Workpiece headstock/tailstock internal taper 5/3 Morse Grinding headstock motor, approx. 4 HP All technical details are given without obligation and subject to errors or omissions.

Būklė: naudotas, Funkcionalumas: visiškai funkcionalus, Grinding length: 973 mm Itsdpfx Agjwhp Dnsfed Centre height: 250 mm Maximum swiveling of workpiece table: +6° / -9° Centre taper: MT5 Maximum travel of grinding spindle headstock: 100 mm Maximum swiveling of grinding spindle headstock: +45° / -30° Maximum grinding wheel diameter: 500 mm Speed range: 32 - 600 rpm Maximum workpiece weight between centres: 400 kg Internal grinding device, maximum grindable bore: 160 mm Machine weight: approx. 5,000 kg

Būklė: labai geros būklės (naudotas), Gamybos metai: 1983, Funkcionalumas: visiškai funkcionalus, Used CNC cylindrical grinding machine Make: FORTUNA Model: T23 S1000 ASW 45 CNC Year of manufacture: 1980 Itedpfx Agsv Eyr Sefsd

Būklė: geras (naudotas), Magnetic table 455 x 170 mm Digital readout Water tank Dressing device Wet grinding unit Itedpfjtu Il Tox Agfjd

Būklė: geras (naudotas), Gamybos metai: 1991, Funkcionalumas: visiškai funkcionalus, mašinos/transporto priemonės numeris: C4655, šlifavimo ilgis: 5 000 mm, šlifavimo plotis: 500 mm, Grinding length: 5000 mm Grinding width: 500 mm Workpiece height: 250 mm Itsdpfoq U Ihvsx Agfed Spindle diameter in front bearing: 190.5 mm Swivel range: 0.7° Max. torque: 1771 Nm Max. speed: 593 rpm Feed rate: stepless, 20–35,000 mm/min Segment head diameter: 800 mm with trapezoidal segments: 94/103x38x200mm Marposs measuring system Hydraulic upper part clamping and swiveling Grinding mist extraction system: hydrocyclone cleaning system Machine weight approx. 27.6 t Space requirement approx.: 11.2 x 4.3 x 3 m
