CNC tekinimo-frezavimo centras

DMG Gildemeister GMX 200 Linear

Gamybos metai: 2009, Sąlyga: paruoštas naudoti (naudotas), Turning diameter: 200 mm, passage diameter: 330 mm, passage diameter over cross slide: 260 mm, travel X/Z: 160 mm/460 mm, feed X/Z: 24 m/min, spindle speed: 5000 rpm, spindle bore: 51 mm, spindle power: 16.5 kW/11 kW, torque: 1665.5 Nm/112 Nm, tailstock: 400 mm, tool stations: 12. Machine dimensions X/Y/Z: approx. 4200 mm/1700 mm/2300 mm, weight: approx. 3500 kg, control: Siemens Sinumerik 810D. Includes chip conveyor. Documentation available. On-site inspection possible. Itodpfov Dkb Iex Abdjp

Sąlyga: paruoštas naudoti (naudotas), Gamybos metai: 2005, Measuring dimensions X/Y/Z: 800mm/1000mm/700mm, max. workpiece weight: 800kg, measuring accuracy: 0.0005mm, repeatability: 0.002mm, granite table dimensions X/Y/Z: 1040mm/1780mm/250mm, rotary swivel head: Renishaw PH 10T Plus. The PH 10T was replaced in 2023. Documentation available. Inspection on site is possible. Ijdpfxeu Ur Sqo Abdotp

Gamybos metai: 1997, Sąlyga: paruoštas naudoti (naudotas), Turning diameter: 200 mm, turning length: 400 mm, swing diameter: 420 mm, bar capacity: 60 mm, max. chuck diameter: 160 mm, spindle speed: 5,000 rpm, turrets: 2, stations: 2x14, rapid traverse X/Z: 20 m/min / 30 m/min. Machine dimensions X/Y/Z: approx. 7,500 mm / 2,100 mm / 2,100 mm, weight: approx. 4,500 kg. Documentation available. On-site inspection possible. Itsdpfxou T Rgke Abdsp

Sąlyga: naudotas, Gamybos metai: 1995, Turning diameter 300 mm Turning length 710 mm Control SIEMENS SINUMERIC 840 Total power requirement 40 kW Machine weight approx. 6000 kg Space requirement approx. ... m INDEX CNC lathe with 1 turret and tailstock and CNC control type C 200 - 4 SIEMENS Type G 300 Year of manufacture 1995 # 5000 65 _____ Spindle bore approx. 90 mm Workpiece swing diameter approx. 400(590) mm Turning diameter with chuck operations approx. 300 mm Turning length / distance between centers approx. 710 mm Turret slide travel Z1 (longitudinal) / X1 (cross) 710 / 140 mm Rapid traverse tool carrier 1: 20 m/min 12-position tool turret, ISO/DIN 30 mm Feed force for Z/X axis: 8/13 Nm Spindle speeds / Tool speeds up to max. 5,000 rpm Torque at spindle at 100% duty cycle max. 275 Nm Spindle drive / Tool drive approx. 28 kW Total drive approx. 40 kW - 400 V - 50 Hz Weight approx. 6,000 kg Accessories / Special features: • SIEMENS CNC 3-axis path control model SINUMERIC 840 C resp. INDEX C 200 - 4, for the following axes: Turret 1 = X/Z as well as C-axis = spindle orientation, swiveling control unit mounted on left side. • Alignment and switching device for the main spindle • Mounted hydraulic 3-jaw chuck FORKHARDT KFD – HS 250 with numerous jaws, max. speed 5,000 rpm. • INDEX turret with 12 tool stations for DIN 30 tool holders, approx. 40 different tool holders included as accessories. The turret positions are prepared for driven tools, powered by the switching device motor. • Hydraulic tailstock with eccentricity correction, quill 60 mm, controlled by foot switch, • KNOLL mobile chip conveyor with coolant system and high-pressure pump, • Front sliding door, otherwise fully enclosed. Oil skimmer Ideal machine for shaft machining and also suitable for chuck workpieces. Robust construction! INDEX (Germany) CNC Controlled Slant-Bed Chuck Lathe with Turret and Tailstock and INDEX CNC Control C 200 – 4 (SIEMENS) Model G 300 Year 1995 S/N 5000 65 _____ Turning – Ø, with chuck, max. 300 mm Iodpfot Hw Suox Abdstp Spindle bore 90 mm Max. Workpiece Swing dia. 400 / 590 mm Turning length / travel of turning slide, (X-Axis) max. 710 mm Turret head slide cross movement (Z-Axis) max. 140 mm Turret with 12 tool holder positions DIN 30 mm Feed range of turret slide / Rapid traverse 0.1 - 20 m/min Feed force of X/Z-Axis: 8 – 13 kN Steplessly adjustable spindle speeds up to 3,500 rpm Torque force on main spindle approx. 275 Nm Spindle drive 28 kW Total electrical load approx. 40 kW - 400 V - 50 Hz Weight 6,000 kg Accessories / Special Features: * INDEX CNC Control Model C 200-4 or SIEMENS 840 C for 3 Axes: X/Z Axis and Main spindle as C-Axis (Spindle Orientation) Control panel...

Sąlyga: naudotas, Gamybos metai: 2001, Grinding length: 4200 mm Grinding width: 1300 mm Workpiece height: 550 mm Control system: Siemens 840D Passage width: 1300 mm Electromagnetic table: 4200 x 1300 mm Grinding height: 550 mm Grinding motor: 306 kW Grinding motor speeds: up to 370 rpm Grinding motor feed rate, infinitely variable: 0.5-35 m/min Coolant flow rate: 2000 l/min Iedpfothumuox Abdotp Machine weight: approx. 50 t Required space: approx. 11.21 x 5.25 x 3.85 m Equipment / Accessories: - Segment head - Diameter: 1400 mm - For segment dimensions: 120/106 x 41 x 250 mm - Number of segments: 1 set = 26 pcs - Grinding motor infeed - In steps: 0.002 - 1 mm - Continuous: up to 5 mm/min, steplessly adjustable

Gamybos metai: 2000, Sąlyga: paruoštas naudoti (naudotas), Makino EU 64 Wire EDM Machine X = 600 mm Y = 400 mm Z = 260 mm Maximum workpiece dimensions (W x D x H): 940 x 650 x 260 mm Itodpfxsgwp Eqo Abdop Maximum workpiece weight: 1,500 kg Service required before commissioning! The current Makino service report can be provided upon request.

Gamybos metai: 1962, Sąlyga: naudotas, mašinos/transporto priemonės numeris: 1790, Manufacturer: Karl Klink Model: RW 5 Year of manufacture: 1962 Weight: approx. 2,500 kg Machine No.: 1790 General / Technical Data: Hydraulic horizontal internal broaching machine in good, operational condition Broaching stroke: 1,320 mm Broaching stations: 1 unit Tensile force: 5,000 kg at 3 m/min (3,000 kg at 7 m/min) Broaching tool clamping: Universal pull head for flat shanks Through-hole in clamping table: Ø 100 mm Workpiece diameter: max. 420 mm (limited by oil and chip tray) Cutting speed: hydraulically adjustable, stepless from 1 m/min to 7 m/min Return speed: hydraulically adjustable, stepless from 7 m/min to 25 m/min Machine dimensions (W x D x H): approx. 4,600 mm x 600 mm x 1,900 mm (without working area) Power supply: 380 V / 50 Hz / 15 A Itjdpfx Absdl Uzkjdep Hydraulic motor: 4 kW Accessories / Special Features: • The machine is equipped with a universal pull head for flat shanks • Refrigerant / lubrication system • Without tool feeder • Short oil and chip tray (approx. 900 mm) Remarks: The machine is ideal for manufacturing keyway slots. On request, broaching needles and mandrels can also be supplied. The machine is connected and ready for demonstration under power in our warehouse.

Sąlyga: labai geros būklės (naudotas), Gamybos metai: 2006, 5-axis CNC machining centre Year: 2006 Control system: Heidenhain iTNC 530 Technical specifications: X-axis travel: 880 mm Y-axis travel: 630 mm Z-axis travel: 630 mm Ijdpjwn A Slofx Abdetp Max. torque: 130 Nm Tool holder: SK 40 (ISO 7388IIB) Swivel range: B: 103° Worktable: Clamping surface: 1,250 x 700 mm Rotary table diameter: 700 mm Rotational axis: C: 360° Max. table load: approx. 500 kg T-slots: 11 x 14 mm x 63 mm Tool magazine: Number of tool stations: 32 (2 x 16 positions) Tool holder: SK 40 (ISO 7388IIB) Max. tool diameter: 80 / 130 mm Max. tool diameter with free adjacent pocket: 160 mm Max. tool length: 315 mm Max. tool weight: 8.0 kg

Sąlyga: geras (naudotas), Gamybos metai: 2007, - SIEMENS 840 D control system - Bar passage: 65 mm - Main and sub-spindle, max. speed 5,000 rpm - C-axis, Y-axis - 3 turrets with 12 stations each (all driven) - Driven tool speed: 4,000 rpm - Tool holder: VDI 30 with drive DIN 5480 Iodpfxjuw Izvo Abdjtp TRAVEL PATHS X1 = 165 mm, Z1 = 220 mm X2 = 165 mm, Z2 = 150 mm X3 = 165 mm, Z3 = 650 mm, Y3 = 80 mm (+50/-30) ACCESSORIES Coolant system Chip conveyor Bar loader TOP Automazioni XF 375

Sąlyga: naudotas, Gamybos metai: 2007, Spindle speed: 6,000 rpm Tool holder: BT50 Number of tool changer positions: 121 Control unit: FANUC 31iMA Horizontal machining center | TOYODA - FH630SX Equipped with through-spindle coolant (IKZ) and chip conveyor. Additional equipment: + NC rotary table 360,000 x 0.001° Isdst I Ec Dopfx Abdstp The machine is in well-maintained condition. Technical specifications of the machine will follow shortly. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: FH 630SX | FH630 | FH-630 | FH 630 SX
