Assembly robot XGR800.3

Befard XGR800.3

Assembly robot
BEFARD XGR 800.3

Specification:
* full remote control - both operation and drive of the device
* three hydraulic extensions with a vertical range of 5.55 m
Bwedoibqr Topfx Ai Esw
* power supply by a combustion engine (optional additional power supply by a 230 V electric engine or Li-ion batteries)
* possibility of simultaneous operation from the 230 V mains and battery charging (for the Li-ion version)
* two-circuit vacuum system
* maximum lifting capacity 800 kg
* 8 vacuum suction cups
* rotating frame with suction cups (hydraulically) - controlled by the remote control
* lateral shift of the frame with suction cups (right, left 10 cm - hydraulically)
* tilting frame with suction cups to the sides (relative to the device - manually or hydraulically)
* tilting frame with suction cups (possibility of lifting the element from the horizontal plane and verticalizing it - hydraulically)
* non-marking tracks
* two working modes - fast and slow
* color to choose from

Optional additional equipment:
* HS spacers
* valves
* frame tilt with suction cups (hydraulic - remote control)
* forks
* anti-overload system
* hook
* LED lamp
* 230V wired power supply (for the combustion version).

Other models available:
XGR800.1 with one hydraulic extension, with a vertical reach of 3.9m
XGR800.2 with two hydraulic extensions, with a vertical reach of 4.75m

Gasoline engine - VANGUARD brand 10 HP / 5.5 KW
