Cad Cam Solutions GmbH

Gamybos metai: 2025, būklė: naujas, New Machine Year of manufacture: 2025 Features and technical data: Complete in standard configuration with: - Robust, torsion-resistant steel frame, manufactured as a welded and bolted structure - Top lamellar pressure beam with 6 elements, side lamellar pressure beam with 5 elements - Lamellar pressure beams with field-proven tolerance compensation (Ganner system) for tightly clamped carcass joints - Counterpressure surfaces (side pressure wall, base) made from 38 mm thick, coated, continuous support panels Lhodpfxsw Nafko Apnon - Continuous pressing area with a height of 95 mm at the lower vertical pressure beam - Electromotive adjustment of the two pressure beams via precision trapezoidal threaded spindles (with enhanced lead and runout accuracy) and high-performance slide nuts with grease reservoir - Pressing is performed electromotively, using 2 separate worm gear motors (2 x 0.75 kW each) - The pressure force of the beams can be steplessly adjusted electronically with 2 potentiometers and is regulated via frequency converters, ensuring completely wear-free pressure control - Pressing force for horizontal pressure beam: min. 500 daN (kg) up to stepless max. 2200 daN (kg) - Pressing force for vertical pressure beam: min. 300 daN (kg) up to stepless max. 2200 daN (kg) - Pressing and adjustment speed of the pressure beams with fine positioning, selectable via 3-step switch: 5 / 10 / 25 mm/sec - Jog function for precise positioning of both pressure beams, e.g., for low pressing forces, drawers, and carcasses at 45° - Simple operation via 6 separate push buttons; 8 movement cycles can be selected via control panel - Freely adjustable press time preselection 0–30 min (switchable to seconds or hours) with individually programmable opening dimensions of the two pressure beams - Re-press function to increase or decrease pressing force during the pressing process - Working height/loading height: 300 mm - Working dimensions: Length min. 150 mm, max. 2500 mm; Height min. 150 mm, max. 1400 mm; Depth: 700 mm Including surcharge for rapid traverse speed for fast positioning of the pressure beams, controlled via automatic workpiece detection with sensors in the pressure beams. Press speed: 5 / 10 / 25 mm/sec and rapid traverse speed: 50 mm/sec. Sensors can be disabled for pressing special components. Including set of machine feet for 500 mm working height Location: Flörsheim Availability: Short-term

Gamybos metai: 2025, būklė: naujas, New machine Year of manufacture: 2025 Features and technical data: Standard equipment: - Robust machine base - Dowel system for: dowel diameter 8 mm Dowel length 35 mm (factory setting, adjustable from 30 to 40 mm) Dowel projection 12 mm (factory setting, adjustable from 7 to 20 mm) - Recoil-free dispensing gun - Vibratory feeder for dowel transport - Dowel diameter and length control with Auto-DL-Select system - Water supply system for pre-glued dowels Water tank (stainless steel container 7.5 l) Closed water system with 6 bar water pressure and spray nozzle - Electronic control featuring: main power switch On / Off Program selector switch Water / Water + Injection Potentiometer for dowel feed via vibratory feeder Potentiometer for water injection volume Indicator light for minimum water level in water tank - Chassis - Compressed air: 6 bar / Electrical: 230V, 1Ph, 50Hz HoKuTech DowelJet with option for through-hole processing: 1 unit HoKuTech | DowelJet with expansion kit for GlueJet incl. mounting devices for integration/connection with DowelJet incl. height-adjustable suspension for glue hose/ including: 1 HoKuTech | GlueJet Glue dosing unit for through-hole processing Suitable for PVAc glues up to 75,000 mPas viscosity Incl. dowel nozzle for Ø 8 mm, pointed nozzle Location: Flörsheim Ljdpjwx Aadofx Apnehn Availability: Immediately

Gamybos metai: 2016, būklė: naudotas, Various aluminium saw machines in stock Ljdof Rihvepfx Apnehn
